Baxton BBT6651 Assembly Instructions

MODEL : BBT6651 KING BED
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS
: 1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
Tool needed : Screwdriver (not provider).

STEP 1

D
E
A
3
8
G
STEP (B)
L
1
STEP (A)
4
5
Assembly Instructions
Loosely fit bolt (3) into Headboard (A) picture shown.
Loosely fit bolt (2) into Footboard (B) as picture shown.
R
2
B

PART LIST

ITEM DESCRIPTION
A HEADBOARD
B FOOTBOARD
C
SIDE RAIL (L&R)
D
CENTER RAIL
E
CENTER SUPPORT LEG
F
CENTER SUPPORT
G LEG (L&R)
H
BED SLAT

STEP 2

Don't screw tied
9
G

HARDWARE LIST

QTY
ITEM DESCRIPTION
1 PC
1 JCBC BOLT M6 x 20mm
1 PC
2 JCBB BOLT M8 x 16mm
2 PCS
3 JCBB BOLT M8 x 30mm
2 PCS
4 M6 SPRING WASHER
6 PCS
5 M6 FLAT WASHER
3 PCS
6 M8 SPRING WASHER
2 PCS
7 M8 FLAT WASHER
39 PCS
8 M4 ALLEN KEY (BALL SHAPE)
9 M5 ALLEN KEY (BALL SHAPE)
10 WOOD SCREW M3.5 x 16mm
11 BED SLAT CENTER FITTER
12 BED SLAT SIDE FITTER
B
C
R
1 of 2
QTY
8 PCS
4 PCS
6 PCS
8 PCS
8 PCS
2 PCS
2 PCS
1 PC
1 PC
12 PCS
26 PCS
26 PCS
C
L
