TR-910
Multipurpose VHF Airband Radio
Operator, Installation and Technical Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR-910 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for jotron TR-910

Summary of Contents for jotron TR-910

  • Page 1 TR-910 Multipurpose VHF Airband Radio Operator, Installation and Technical Manual...
  • Page 2 Only qualified personnel should work inside the equipment. Disclaimers The informa on in this paper has been carefully checked and is believed to be accurate. However, Jotron AS assumes no responsibility for inaccuracies. Jotron AS reserves the right to make changes without further no ce to any products or modules described herein to improve reliability, func on or design.
  • Page 3 — Increase the separa on between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...
  • Page 4 ISED Canada Compliance Statement CAN ICES-3(B) / NMB-3(B) This radio transmi er [TR-910 IC: 2131A-TR910] has been approved by Innova on, Science and Economic Development Canada to operate with the antenna types listed below, with the maximum permissible gain indicated. Antenna types not included in this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device.
  • Page 5 For op mum performance and compliance with RF exposure limits, mount the antenna in the center area of the roof as shown in figure 2. Figure 1: Opera on of Man Portable Figure 2: Installa on of vehicle antenna jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...
  • Page 6 40 cm aux passagers. Pour une performance op male et une conformité aux limites d’exposi on RF, monter l’antenne au milieu du toit comme illustré sur la figure 2. jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...
  • Page 7 Document Revision Log 17.11.2021 Revised FCC/ISED statements 15.10.2021 Ini al Issue BA / GAJ Rev. Issue Date Reason for Issue Author (DD.MM.YY) jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...
  • Page 8 The so ware that performs the naviga on in the MIB database is a MIB browser. The MIB database is Jotron proprietary and contains descrip ons and defini ons for all parameters in the radio. The MIB database is updated each me a new radio parameter is added or changed.
  • Page 9 Simple Network Management Protocol is a UDP-based network protocol. It is used mostly in network management systems to monitor and control network connected devices like the Jotron radios. SNMP is a component of the Internet Protocol Suite as defined by the Internet Engineering Task Force (IETF). It consists of a set of standards for network management, including an applica on layer protocol, a database schema, and a set of data objects.

  • Page 10: Table Of Contents

    4.4 Installa on of TR-910 ........
  • Page 11 Ext connector ........jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...
  • Page 12 8.4 TR-910 Ba ery indicator ........

  • Page 13: Introduc On

    1.1 Design The TR-910 is a compact, high-quality radio available in a variety of configura ons to meet the high demands of the ATC and Oil and Gas industries where a small, rugged and durable radio unit is needed. The radio has an all metal housing, making it very robust but s ll light enough to be carried as a manpack.
  • Page 14 1.3 Models covered by this manual TR-910 Offshore Radio (OF) 103400OF 10 Wa 118-137 MHz TR-910 Mul purpose VHF Airband Radio (no accessories) 103400 10 Wa 118-137 MHz Table 8: Accessory list Accessory list Supplied accessory Part TR-910 TR-910 TR-910...

  • Page 15: Op Ons

    Extended opera ng frequency to 144.000 MHz 84360 G.729 Adds the possibility to use G.729 codecs for the 81432 audio streams in addi on to G.711 to reduce bandwidth. Requires VoIP op on jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 16: Technical Specifica Ons

    Ethernet ports 1 x 100 Mbit network Protocols UDP/IP: SNMP (v.1, 2 and 3), RTP, SIP, NTP, TFTP, DHCP, RTSP TCP/IP: Remote control (Jotron), RTP, SIP, HTTP, RTSP Serial: USB 2.0 BITE monitoring All relevant parameters for transceiver. Ref. BITE below.

  • Page 17: Transmi Er Specifica Ons

    Signal/Noise (Hum and noise) > 40 dB Timeout 5 s to 5 min (300 s) in 5 s. steps (1 s from SNMP) Duty cycle 30 % Tx/Rx opera on @ ambient below 40 °C jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 18: Receiver Specifica Ons

    8 to 32 Ω, > 100 mW Headset 5 W @ 8 Ω External speaker amplifier 600 Ω, -46 to 0 dBm @ 90 % modula on, single ended Monitor output Permissible RF input level 5 V EMF jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 19: Applicable Standards

    ETSI EN 300 019-2-2 V2.4.1: Transporta on ETSI EN 300 019-2-5 V3.1.1: Ground Vehicle Installa ons ETSI EN 300 019-2-7 V3.0.1: Portable and non-sta onary use Safety IEC 62368-1:2014 + A11:2017 RoHS EN 50581 jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 20: Func Onal Descrip On

    Indicates that the SWR on the antenna is above the threshold value (app. 3:1). The transmi er will reduce the output power to the predefined low power level in order to protect the output stage. jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 21: Scroll/Select Knob

    This condi on normally requires that there is another (spare) transceiver that can take over the func onality of the transceiver. Indicates the ba ery status if used with BU-872. See TR-910 Ba ery indicator chapter for details on ba ery icons.

  • Page 22: Shortcut Keys

    The connector also has an USB interface. This interface can be used for configura on of the radio through the Jotron MDT program. To use this interface a specific cable is required with the following connec ons to a standard Type A USB connector:...

  • Page 23: Rear Connec Ons

    The radio operates from a DC supply of +12 V to +28 V +/-10%. Table 17: DC connector, pin out DC input connector Name Func on Connected to + DC voltage Black Connected to ground Green/Yellow Igni on key + DC voltage sense jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 24: Lan Connector (Rj45)

    Ethernet cable. The pin-out of the LAN connector are the standard pin-out used in most ethernet networks. This interface can be used for remote monitoring with the Jotron RCMS system. The LAN interface can also be used for recording and remote opera on with the VoIP op on enabled.
  • Page 25 Open = Squelch closed (not receiving) Closed = Squelch open (receiving / Rxbusy) Mode 3: TxKey. Key the transmi er by grounding this input (PTT). Mode 4: Open = ALARM Closed = NO ALARM Common ground jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 26: Installa On

    On receipt of the radio unit, remove all packaging and check that there is no damage to the equipment. If damage is evident, contact Jotron AS immediately and retain the original transit packaging. 4.3 Compass safe distance The compass safe distance for TR-910 is minimum 140 cm.

  • Page 27: Installa On Of Tr-910

    4.4 Installa on of TR-910 4.4 Installa on of TR-910 4.4.1 TR-910 Desktop Radio (DE) Figure 6: TR-910 DE jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 28: Tr-910 Man Portable Radio (Mp)

    4.4 Installa on of TR-910 4.4.2 TR-910 Man Portable Radio (MP) Figure 7: TR-910 MP jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...
  • Page 29 4.4 Installa on of TR-910 Figure 8: TR-910 MP jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...
  • Page 30 4.4 Installa on of TR-910 Figure 9: TR-910 MP jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...
  • Page 31 4.4 Installa on of TR-910 Figure 10: TR-910 MP jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 32: Tr-910 Vehicle Radio (Ve)

    4.4 Installa on of TR-910 4.4.3 TR-910 Vehicle Radio (VE) Figure 11: TR-910 VE jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 33: Tr-910 Last Resort Radio (Lr)

    4.4 Installa on of TR-910 4.4.4 TR-910 Last Resort Radio (LR) Figure 12: TR-910 LR jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 34: Tr-910 Subrack Radio (Sr)

    4.4 Installa on of TR-910 4.4.5 TR-910 Subrack Radio (SR) Figure 13: TR-910 SR jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 35: Tr-910 Last Resort Subrack Radio (Lr-Sr)

    4.4 Installa on of TR-910 4.4.6 TR-910 Last Resort Subrack Radio (LR-SR) Figure 14: TR-910 LR-SR jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 36: Tr-910 Offshore Radio (Of)

    4.4 Installa on of TR-910 4.4.7 TR-910 Offshore Radio (OF) Figure 15: TR-910 OF jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 37: Antenna Connec On

    • Ba ery communica on interface (Pin 5) is the communica on line between TR-910 and the BU-872 ba ery pack. TR-910 uses this interface to read the ba ery status from the ba ery unit and present this with a ba ery indicator on the front panel.
  • Page 38 • Rxbusy / GPIO (Pin 7) is a relay output, and the default func on is alarm indica on. It can also be configured to have other func ons if desired. This is done through the setup menu of the transceiver. jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 39: Opera Ng Instruc Ons

    8.33 kHz and 25 kHz environment. The frequency displayed does not always reflect the actual transmit or receive frequency but is the frequency used to orally communicate the frequency between jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...
  • Page 40 5.2 Note on frequency se ng controllers and pilots. Jotron radios automa cally adjust to the correct bandwidth when se ng a frequency as outlined in the table below: Table 23: Illustra on of auto bandwidth adjustment Displayed Actual Bandwidth...

  • Page 41: Basic Opera On

    . The fourth icon is display brightness/contrast and is described later in this sec on. The volume screen returns automa cally a er a few seconds of inac vity. jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 42: Volume Screen - Se Ng Display Brightness And Contrast

    • Press scroll/select or the RCL shortcut to select and return to the home screen, or; • Rotate scroll/select to the top of the list and press the BACK shortcut to return. jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 43: Func On Screen - Se Ng Squelch Level

    5.3.6 Func on screen - Se ng squelch level The TR-910 has a S/N squelch which automa cally adapts itself to the background noise, so normally there will be no need for adjustment during normal opera on. The value is in dB S/N and the default value is 12 dB. The value can be adjusted between 5 dB and 20 dB.

  • Page 44: Func On Screen - Show Radio Informa On

    • Press the MENU shortcut to open the main menu with advanced se ngs. • Navigate with scroll/select and shortcut keys. To go up/back in the meny tree navigate to the top of the list with the ... entry. jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 45: Advanced Se Ngs

    Bite system SysOp, Displays internal measurements and informa on about any Technician ac ve alarms. Configura on Displays informa on about firmware and hardware release, system up- me and radio iden fica on. jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...

  • Page 46: Configura On Group

    – Range: 30.0 - 40.0 dBm, 0.1 dB step – Default: 40.0 dBm (10 W) – Details: Set the output power. Max. level depends on radio model: 37.0 dBm for TR-910 MP, 40.0 dBm for TR-910 (All others). • Modula on % –...
  • Page 47 – Default: Speaker Mic – Details: This se ng selects the use of an external speaker mic, like the Jotron 81339, or a headset. Normally a headset has much higher sensi vity than the speaker mic, and this se ng adjusts the output power level of the Mic/headset connector on the front panel.

  • Page 48: Single Channel Mode

    – Range: Enabled | Disabled – Default: Disabled – Details: Set the radio to ‘Single channel mode’. In this mode it is not possible to change the frequency from the front panel. jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB...
