INSTALLATION*
Preparing the Camera and Mounting Surface:
Before mounting the camera, please check the following:
1.
The mounting surface must be able to sustain five times
the weight of your camera.
Mounting the Camera:
Use the camera's mounting template or the camera's
1.
housing to mark the drilling holes in the mounting
surface.
2.
Drill holes into the drywall using the included dry wall
anchors.
3.
Pull wires through and make connections.
4.
Mount the camera to the wall or ceiling using the screws
provided with the camera.
To adjust the camera's pan and tilt, loosen the Pan/ Tilt
5.
stopper screw by rotating it counter clock-wise.
Once the camera's an and tilt angles have been adjusted,
6.
tighten the Pan/ Tilt stopper screw back to secure the
camera in its position by rotating it clock-wise.
7.
When the installation is complete and before powering
the camera, remove the protective cover sticker from the
camera's vent hole. The vent hole is located on the back
of the camera, above the reset button.
9
