WEBVIEWER*
S e t u p > V i d e o > S t r e a m S e t t i n g s
T h e M E G A p i x c a m e r a a l l o w s y o u t o s e t u p t w o d i f f e r e n t s t r e a m s t o
o p t i m i z e s t o r a g e a n d b a n d w i d t h u s a g e .
1. Name- Set a unique name to each stream to identify them.
2. Resolution- Set Resolution for each stream. The better the resolution, the more bandwidth it will
require to stream images.
3. Compression Type (Codec)- Select the type of compression to use when outputting the video. The
compression type affects the image quality, bandwidth, and file size of saved images. MJPEG, the
lowest Compression type, will provide the highest image quality, but also will cause the image size
to be the largest, and take up the most bandwidth. H.264 Baseline Profile is the default codec.
4. Data Transfer Speed- Set encoding bitrate if H.264 and MPEG4 compression type is selected.
Select from 1800 to 8000Kbps.
5. Frame-rate- Select from 0fps to 30fps. The camera is set by default to 28fps.
6. MJPEG Quality- Set MJPEG image quality. This is only available when the compression
is set to MJPEG. The higher the quality, the more bandwidth will be required to stream the image.
7. Select 'Apply' to save changes.
[1]
[2]
[3]
[4]
[5]
[6]
[7]
