SPECIFICATIONS*

NETWORK

LAN
Video Compression Type
Resolution
Frame Rate
Stream Capability
IP
Protocol
Maximum User Access
Memory Slot
ONVIF Conformance
Web Viewer
Video Management Software
ENVIRONMENTAL
Operating Temperature
Operating Humidity
IP Rating
Other Specifications
Electrical
Power Requirement
Power Consumption
Mechanical
Housing Material
Dimensions
Weight
All manuals and user guides at all-guides.com
802.3 Compliance 10/100 LAN
H.264, MPEG4, MJPEG (Super Fine ~ Low)
1920X1080 (16:9) ~ 320X240 (4:3)
Up to 30fps at All Resolutions
Dual-Stream at Different Rates and Resolutions
IPv4, IPv6
TCP/IP, HTTP, DHCP, PPPoE, ICMP, ARP, RARP, RTSP, NTP, UDP,
Multicast
5 Users
Local SDHC Card Backup- 24 hours recording to Micro SDHC Card (4GB-
32GB)
Yes, Profile S
Supported OS: Windows XP, Windows Vista, Windows 7, MAC OS
Supported Browser: Internet Explorer, Google Chrome, Mozilla Firefox, Safari
DW Spectrum
-10°C ~ 50°C (14°F ~ 122°F)
Less than 90% (Non-Condensing)
IP66 Certified (Protects against dust and high pressure water)
CE, FCC, RoHS
DV12V, PoE [IEEE802.3af, Class 2]
LED Off: 3.5W, 300mA
LED On: 5W, 430mA (Max 500mA)
Aluminum Die-Casting
161.7 x 67.5mm (6.36 x 2.66in)
0.93 lbs
