Summary of Contents for TEFAL ACCESS STEAM CARE DT9120
- Page 1 DT91XX www.tefal.com...
- Page 2 * Depending on model...
-
Page 3: Product Description
PRODUCT DESCRIPTION Control panel : On/Off and steam Cord exit level buttons Fabric brush Heated soleplate 10*. Steam cover Water tank locker 11*. Crease attachment Locker switch for continuous steam 12*. Door hook Steam trigger 13*. Travel Pouch Standing base Removable water tank * Depending on model... -
Page 4: Important Safety Instructions
Important safety instructions • Please read these instructions carefully before first use. • This product has been designed for indoor, domestic use only. Any commercial use, inappropriate use or failure to comply with the instructions, the manufacturer accepts no responsibility and the guarantee will not apply. •... - Page 5 • Never pull on the cord to disconnect the appliance from electrical outlet; instead, grasp plug and pull to disconnect on the plug to disconnect the appliance. • Do not allow cord to touch hot surfaces or come into contact with rough or sharp edges. Let the appliance cool completely down before putting away.
- Page 6 • To protect against a risk of electric shock, do not immerse the appliance in water or other liquids. • Do not direct steam at people, animals or clothes while they are being worn. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning...
- Page 7 Do not use pure demineralised or pure distilled water, water from clothes dryers, scented or softened water, rain water, filtered, bottled or boiled water, water from refrigerators, batteries or air conditioners as these may damage the appliance. These types of water contain organic waste, mineral elements that become concentrated when heated and cause spitting, brown staining, leaking or premature wear on your appliance.
-
Page 8: Before Use
BEFORE USE Unlock and remove the water tank. Remove the water inlet stopper. Fill the water tank with untreated tap water. Close the water inlet stopper. - Page 9 Return the water tank to its place on the appliance. Make sure that the water tank is fully set in place and locked. ASSEMBLY BOARD GUIDE View of the finished product and exploded view.
- Page 10 “CLICK” Lay down the three parts on a table and clip them together. Insert the cover over the board. Position the four bands around the four hooks. Band the cord and slip the stop element.
- Page 11 Tuck away the cord in the back of the cover. Deploy the hook. Hang the board on the door hook. Warning: never use the board and the product on a flat position.
- Page 12 ACCESSORIES / The door hook allows to hang your garment for steaming. Do not use the door hook on wooden on painted doors to avoid damaging the door. The fabric brush opens the weaves of the fabrics for better steam penetration. Before removing or attaching the steam brush, unplug your appliance and allow it to cool down, for one hour.
- Page 13 The travel pouch is used for transportation. Before storing your appliance in the travel pouch, unplug your appliance then empty the water tank and allow the appliance for approximately 1 hour until completely cool. The lint pad is a separate accessory and cannot be attached to the steam head. You can use the lint pad independently from the steamer.
- Page 14 Warning : Never steam a garment while it is being worn. Plug-in the appliance. Switch on the appliance. Wait until the light stops flashing (approximately 40 seconds). When the light is steady the appliance is ready to use.
- Page 15 Press the steam button with the steam brush facing away from you holding it in a vertical position. For optimal use, move the garment steamer over your garment from top to bottom. 3 levels of steam: adapt the steam output to your garment.
- Page 16 3 sec. Press and hold the On/Off button for 3 seconds to switch the appliance off. Unplug the appliance. Warning: Never touch the soleplate of the appliance. Warning: Never steam a garment with the board on your legs.
-
Page 17: Standby Mode
STANDBY MODE 1) For your safety, the appliance is fitted with a standby monitoring system, which is activated automatically after approximately 8 minutes without use. 2) Only the ‘On-Off ’button flashes slowly to indicate that the appliance is on standby 3) To reactivate the steambrush : a. - Page 18 Empty the water tank completely. Return the water tank to its place on the appliance. Wait for approximately 1 hour for your appliance to cool completely before storing or using the travel pouch.
- Page 19 DESCALING Do this operation in a well ventilated room. Unlock and remove the water tank. Remove the water inlet stopper. Water Water Fill the water tank with 50% untreated tap water and 50% white vinegar or citric acid. Do not use other descaling products. White Vinegar / Citric Acid...
- Page 20 Return the water tank to its place on the appliance. Make sure the water tank is fully set in place and locked. Plug-in the appliance. Switch on the appliance. Wait until the light stops flashing (approximately 40 seconds). When the light is steady the appliance is ready to use.
- Page 21 Put the steam trigger in the locked position using the locker. Place the product on a flat, stable, horizontal and heat resistant surface. Allow the appliance to run until the water tank has completely emptied. 3 sec. Press and hold the On/Off button for 3 seconds to switch the appliance off.
- Page 22 Remove the water inlet stopper and fill the water tank with untreated tap water. Return the water tank to its place on the appliance. Make sure the water tank is fully set in place. Plug in the appliance. Switch on the appliance.
- Page 23 Wait until the light stops flashing (approximately 40 seconds). When the light is steady the appliance is ready. Put the steam trigger in the locked position. place the product on a flat, stable, horizontal and heat resistant surface. Allow the appliance to run until the water tank has completely emptied.
- Page 24 CLEANING Wait for approximately 1 hour for the appliance to completely cool. Only use a soft sponge with water to clean. Do not use any detergent product. Never wash or rinse appliance directly over a sink.
-
Page 25: Troubleshooting Guide
Troubleshooting Guide PROBLEM POSSIBLE CAUSES SOLUTIONS There is no steam. The appliance is not plugged in, or not Check that your appliance is correctly switched on. plugged in and switched on. The water level is too low. Unplug your appliance and refill it. The steam pump has not been primed. - Page 28 1820000620...
