OPERATION, SERVICE AND PARTS
INSTRUCTION MANUAL
940 & 960-PO-PS
M3 Series
HYDRAULIC POWER PUMPS
For all pumps with Serial No. Code LE & MT
Read and understand this material before
operating or servicing this tool. Failure to
understand how to safely operate the tool
could result in an accident causing serious
injury or death.
999 5541.5
© 1997 Greenlee Textron
IM 841 REV 3 6/97
