OPERATION, SERVICE AND PARTS
HYDRAULIC POWER PUMP
999 6465.1
INSTRUCTION MANUAL
950-M3 BASIC
Read and understand this material before
operating or servicing this tool. Failure to
understand how to safely operate the tool
could result in an accident causing serious
injury or death.
© 1997 Greenlee Textron
Current for all pumps
with Serial No. code LC
IM 848 REV 3
8/97
Advertisement
Table of Contents
Related Manuals for Greenlee 950-M3
Summary of Contents for Greenlee 950-M3
- Page 1 Failure to understand how to safely operate the tool could result in an accident causing serious injury or death. © 1997 Greenlee Textron Current for all pumps with Serial No. code LC IM 848 REV 3...
-
Page 2: Safety Alert Symbol
Safety is a critical factor in the design of Greenlee equipment. The best program starts with a safety-conscious operator. The information highlighted in this bulletin describes operating practices for the benefit of the workers who will use our equipment in their daily jobs. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS • Do not connect the pump to any system or system component other than those supplied by Greenlee and rated at less than 10,000 psi (68,950 kPa). • Do not alter the internal high-pressure relief valve setting. -
Page 4: Operating Instructions
Introduction The 950-M3 Hydraulic Power Pump is a high-pressure hydraulic power pump which is simple to operate, lightweight, durable and portable. This power pump has a built-in high volume / low pressure pumping feature which gives fast approach ram action and automatic changeover to low volume / high pressure when pressure exceeds 100 psi. -
Page 5: Motor Maintenance
Control Engine Model Valve Type H.P. 4 cycle 501 8601.9 Optional basic Greenlee Textron / Subsidiary of Textron 950-M3 Basic Hydraulic Power Pump Pumping Capacity Height cu/in/min 100 psi 1000 psi 21" 10-1/2" x 12" 4455 Boeing Dr., Rockford, IL 61109-2988... -
Page 6: Troubleshooting
If the above corrective measures fail to make the pump function properly, it is recommended that you send the pump back to the factory or to an authorized Greenlee service center. Under no conditions, allow unqualified personnel to attempt to repair the pump (particularly the pump block unit or control valve unit), as serious irreparable damage may result. - Page 7 9.25 11.43 Greenlee Textron / Subsidiary of Textron 950-M3 Basic Hydraulic Power Pump 15.50 SERIAL NO. LOCATION 10.75 4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070...
