Save These Instructions. This manual will help you to obtain efficient,
dependable service from the heater, and enable you to order repair
parts correctly. Keep in a safe place for future reference.
SAFETY NOTICE: If this heater is not properly installed, a house fire
may result. For your safety, follow the installation instructions. Never
use make-shift compromises during the installation of this heater.
Contact local building or fire officials about permits, restrictions
and installation requirements in your area.
CAUTION! Please read this entire manual before you install or use
your new room heater. Failure to follow instructions may result in
property damage, bodily injury, or even death. Improper Installation
Could Void Your Warranty!
ALL PICTURES SHOWN ARE FOR ILLUSTRATIVE PURPOSES ONLY.
ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENT.
This manual is subject to change without notice.
Defender II
Owner's Manual Model: US1100E
United States Stove Company
PO Box 151, 227 Industrial Park Rd.,
South Pittsburg, TN 37380
PH: (800) 750-2723
www.usstove.com
Report Number: F19-473
Tested Per EPA Methods ALT-125, ASTM
E2515, ASTM E3053 and CSA B415
Certified to UL 1482-2011 (R2015) and
ULC-S627-00 (R2016)
Approved for mobile home installation
in USA and Canada
U.S. Environmental Protection Agency
Certified to comply with 2020
Ce produit peut vous exposer à des agents chimiques, y compris au monoxyde de
particulate emissions standards.
carbone, lesquels sont reconnus dans l'État de la Californie comme causant le cancer et
des malformations congénitales ou autres dommages au fœtus. Pour obtenir plus de
renseignements, veuillez consulter le site www.P65warnings.ca.gov
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon monoxide, which
is known to the State of California to cause cancer, birth defects and/or other
reproductive harm. For more information, go to www.P65warnings.ca.gov
R
853362C-1004J
Advertisement
Table of Contents
Related Manuals for United States Stove Defender II
Summary of Contents for United States Stove Defender II
- Page 1 State of California to cause cancer, birth defects and/or other This manual is subject to change without notice. reproductive harm. For more information, go to www.P65warnings.ca.gov United States Stove Company PO Box 151, 227 Industrial Park Rd., South Pittsburg, TN 37380 PH: (800) 750-2723 www.usstove.com...
- Page 2 This manual describes the installation and operation of the Defender II, US1100E wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s cordwood emission limits for wood heaters sold after May 15, 2020. Under specific test conditions this heater has been shown to deliver heat at rates ranging from 15,196 to 40,594 Btu/hr with 1.7 g/hr and 69% efficiency.
- Page 3 Assembly UNPACK AND INSPECT Remove the packing from the appliance and inspect for any damage. Your appliance is packed with the door handle spring not installed. Ensure that the bricks are positioned correctly and not broken (see illustration for proper brick arrangement). Make sure that the baffle board, above the air tubes, is in place and undamaged. (DO NOT REMOVE).
-
Page 4: Installation
Installation SAFETY NOTICE • IF THIS STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. • CONSULT YOUR MUNICIPAL BUILDING DEPARTMENT OR FIRE OFFICIALS ABOUT PERMITS, RESTRICTIONS AND INSTALLATIONS REQUIREMENTS IN YOUR AREA. •... - Page 5 CLEARANCES TO COMBUSTIBLES It is of utmost importance that the clearances to combustible materials be strictly adhered to during installation of the stove. Refer to the provided tables: Backwall Ceiling Backwall CORNER INSTALLATION CORNER INSTALLATION CLEARANCE TO CLEARANCE TO WALLS CLEARANCE TO WALLS WALLS &...
- Page 6 • Your stove does not draw steadily, smoke rollout occurs, wood burns poorly, or back-drafts occur whether or not there is combustion present. • Existing fuel-fired equipment in the house, such as fireplaces or other heating appliances, smell, do not operate properly, suffer smoke roll-out when opened, or back-drafts occur whether or not there is combustion present.
-
Page 7: Chimney Connector (Stove Pipe)
CHIMNEY CONNECTOR (STOVE PIPE) The chimney connector and chimney must have the same diameter as the stove outlet (6”). If this is not the case, we recommend you contact your dealer to ensure there will be no problem with the draft. -
Page 8: Factory Built Chimney
FACTORY BUILT CHIMNEY When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, firestops (where needed), insulation shield, roof flashing, chimney cap, etc. Maintain proper clearance to the structure as recommended by the manufacturer. -
Page 9: Combustible Wall Chimney Connector Pass-Throughs
COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS METHOD A - 12” (304.8 mm) Clearance to Combustible Wall Member: Using a minimum thickness 3.5” (89 mm) brick and a 5/8” (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The clay liner must conform to ASTM C315 (Standard Specification for Clay Fire Linings) or its equivalent. -
Page 10: Fuel Recommendations
Fuel Recommendations WOODSTOVE UTILIZATION Your heating appliance was designed to burn wood only; no other materials should be burned. Waste and other flammable materials should not be burned in your stove. Any type of wood may be used in your stove, but specific varieties have better energy yields than others. -
Page 11: Do Not Burn
Operating Instructions CAUTIONS: HOUSE FIRE HAZARDS • Do not store wood on floor protector, underneath stovepipe(s) if applicable, or anywhere within clearances to combustible surfaces specified for this appliance. • Never operate with secondary tubes, fiber board, or insulation removed. OPERATING SAFETY PRECAUTIONS •... -
Page 12: Fueling Instructions
TAMPER WARNING This wood heater has a manufacturer-set minimum low burn rate that must not be altered. It is against federal regulations to alter this setting or otherwise operate this wood heater in a manner inconsistent with operating instructions in this manual. EFFICIENCIES Efficiencies can be based on either the lower heating value (LHV) or the higher heating value (HHV) of the fuel. -
Page 13: Adding Fuel
Pull the air control out fully (in the “HI” position). Light the newspaper and leave the door slightly open for about a minute. NOTE: You may have to leave it open a bit longer, depending on your chimney height and outdoor conditions. After one minute (or once the fire is well started) close HIGH the door and allow the kindling to ignite. -
Page 14: Blower Operation
6. Empty ashes regularly. Do not allow ashes to pile up. Properly dispose of hot ashes (see the “Ash Removal And Disposal” section of this manual). 7. Burn small, intense fires instead of large, slow burning fires when possible. Large slow burning fires can deposit creosote within the heating system. -
Page 15: Glass Care
• If a chimney or creosote fire occurs, close all dampers immediately. Wait for the fire to go out and the heater to cool, then inspect the chimney for damage. If no damage results, perform a chimney cleaning to ensure no more creosote deposits is remaining in the chimney. - Page 16 Optional B36 Blower Wiring Diagram DANGER: SHOCK HAZARD DISCONNECT CAUTION: MOVING PARTS CAN CAUSE POWER SOURCE BEFORE INSTALLATION AND INJURY. DO NOT OPERATE WITH COVER WHENEVER SERVICING BLOWER ASSEMBLY. REMOVED. WHITE / BLACK / BLACK / BLANC NOIR NOIR BLACK / BLACK / BLACK / NOIR...
-
Page 17: Replacement Parts
Replacement Parts Part # Description 29139 Air Deflector 891824 Heatshield Weldment 40292A 6” Flue Collar 88042 1/4” Rope Gasket 29055 Ashpan 610923 Pedestal Weldment (US1100E-BP) 610928 Damper Weldment 86709 Damper Rod 891987 Plastic Knob 610918 Access Panel (US1100E-BP) 610944 Ashpan Housing Weldment (US1100E-BL) 40566 Cast Iron Leg... - Page 18 Replacement Parts Part # Description 893241-US Complete Door Handle 40887 Medium Arched Door 88324 1” Rope Gasket 893159 Clear Glass 29229 Glass Retainer, Sides 29227 Glass Retainer, Top 29230 Gasket Clamp 29228 Glass Retainer, Bottom 892294 Hinge Pin Part # Description 29039 Brick Retainer...
-
Page 19: Service Provider
Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer's specified spare part when replacement is necessary. - Page 20 Notes -20-...
- Page 21 Notes -21-...
- Page 22 2. The PART DESCRIPTION / UNE DESCRIPTION DE LA PIÈCE ________________________ 3. The MODEL NUMBER / LE NUMÉRO DE MODÈLE ________________________________ 4. The SERIAL NUMBER / LE NUMÉRO DE SÉRIE ____________________________________ United States Stove Company PO Box 151, 227 Industrial Park Rd., South Pittsburg, TN 37380 PH: (800) 750-2723 www.usstove.com...
