- Page 1 Item # : BS68CLHUT Assembly Instructions Please visit our website for the most current instructions, assembly tips, report damage, or request parts. www.walkeredison.com Revised 02/12/2019 (E) Walker Edison ® Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
-
Page 2: General Assembly Guidelines
Concealed hinges are three-way adjustable. Horizontal In-and-Out Vertical by screw adjustment Via slots in the mounting by loosening the hinge-arm mounting screw or via cam plate or via cam adjustment adjustment Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. ©... -
Page 3: Parts List
Parts List Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. ©... -
Page 4: Hardware List
Ø4x32mm Screw Philips head screwdriver required for assembly (not included) The hardware quantities listed above are required for proper assembly. Some extra hardware may also have been included. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. ©... - Page 5 Philips head screwdriver required for assembly (not included) The hardware quantities listed above are required for proper assembly. Some extra hardware may also have been included. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 6 Step 1 Insert wooden dowel (A) into parts (3,4,19) as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 7 Step 2 Insert wooden dowel (A) into parts (5,7) , then secure cam bolt (B) into parts (5,7) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 8 Step 3 Slider arm Slider arm Slider bracket Slider bracket Separate the slide bracket from the slide arm as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 9 Step 4 Using screw(Y) secure drawer slider arm (Z) to parts (5,7) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. ©...
- Page 10 Step 5 Using screw(Y) secure drawer slider bracket (Z) to parts (16,18) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.10 ©...
- Page 11 Step 6 Secure cam bolt (B) into part (14) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.11 ©...
- Page 12 Step 7 Using screw (W) attach parts (16,18) to part (17) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.12 ©...
- Page 13 Step 8 Put part (15) as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.13 ©...
- Page 14 Step 9 Using screw (W) attach part (17) to part (19) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.14 ©...
- Page 15 Step 10 Using cam lock(D) secure part (14) to parts (16,18) ,cam lock (C) secure part (14) to part (19) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.15 ©...
- Page 16 Step 11 Using cam lock(C) secure part (3) to part (5) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.16 ©...
- Page 17 Step 12 Using cam lock(C) secure part (4) to part (5) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.17 ©...
- Page 18 Step 13 Using cam lock(C) secure part (7) to parts (3,4) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.18 ©...
- Page 19 Step 14 Put parts (8,12) as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.19 ©...
- Page 20 Step 15 Using screw (G) attach part (2) into parts (5,7) with hex key (J) as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.20 ©...
- Page 21 Step 16 Using bolt (H) attach part (9) into part (2) with hex key (J) as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.21 ©...
- Page 22 Step 17 Put part (11) as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.22 ©...
- Page 23 Step 18 Put part (6) as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.23 ©...
- Page 24 Step 19 Put parts (11) as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.24 ©...
- Page 25 Step 20 Using screw (F) attach part (1) into parts (5,7) with hex key (J) as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.25 ©...
- Page 26 Step 21 Using screw (R) secure plastic wedge (Q) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.26 ©...
- Page 27 Step 22 Place sticker (E) cover the holes as per diagram . Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.27 ©...
- Page 28 Note :If the drawer does not go in smoothly .Press or lift the plastic release lever . Pull out the slider bracket from the slider arm then re-assembled the drawer until they were going in smoothly well . Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.28 ©...
- Page 29 (K) in the same level. So the shelf is not titled .Put part(10) into unit as per diagram. Tilt and rest the adjustable shelf onto the shelf support pins . Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.29 ©...
- Page 30 Using screw (P) attach Europe hinge (N) into part (13) ,then using screw (M) attach handle (L) to part (13) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.30 ©...
- Page 31 Step 26 Using screw (P) attach Europe hinge (N) into part (7)with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.31 ©...
- Page 32 Step 27 Using screw (P) attach Europe hinge (N) into part (5)with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.32 ©...
- Page 33 Step 28 Using screw (S) attach Velcro strap (U) into part (1) with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.33 ©...
- Page 34 Wall (EN) Using screw (T) attach plastic strap (U) into nut (V) to wall with Philips head screwdriver as per diagram. Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.34 ©...
-
Page 35: Final Assembly
Step 30 Final Assembly Copyright 2019 b Walker Edison Furniture Co., LLC. All rights reserved. P.35 ©...
