Summary of Contents for Greenlee GATOR CSG50GL
- Page 1 CSG50GL Cutting Tool 120 Volt and 230 Volt 99945045 GATOR Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. © 2006 Greenlee Textron Inc. Serialnummer ® IM 1513 REV 1 4/06...
-
Page 2: Table Of Contents
Replacement manuals are available upon request at no charge. All specifications are nominal and may change as design improve- ments occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. GATOR is a registered trademark of Greenlee Textron Inc. -
Page 3: General Safety Rules
Hazards or unsafe practices which, if not avoided, MAY result in injury or property damage. Greenlee / A Textron Company CSG50GL Cutting Tool Work area safety: • Keep work area clean and well lit. Cluttered or dark areas invite accidents. - Page 4 Failure to observe these warnings could result in severe injury or death. Greenlee / A Textron Company CSG50GL Cutting Tool Power tool use and care: • Do not force the power tool. Use the correct power tool for your application.
- Page 5 Failure to observe this warning could result in serious injury, gangrene, or death. Greenlee / A Textron Company CSG50GL Cutting Tool Do not use solvents or flammable cleaners to clean the tool body. Solvents could ignite, causing serious injury or property damage.
-
Page 6: Identification
Hz ... hertz Hydraulic Oil ... 50 ml (0.1 pint) of Shell Tellus Cutting Capacity Maximum Cable Cutting Diameter ... 45 mm (1-3/4") Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070 CSG50GL Cutting Tool ®... -
Page 7: Operation
Keep hands away from closing blades. Failure to observe this warning could result in severe injury or death. Greenlee / A Textron Company CSG50GL Cutting Tool • Do not cut steel or ACSR. Cut only copper and aluminum cable. • This tool is not designed for continuous use. -
Page 8: Maintenance
3. Oil the bolt joints. Annually or Every 8000 Cutting Cycles 1. Change the hydraulic oil. 2. Return the tool to an authorized Greenlee service center for inspection. Checking the Oil Level 1. Remove the two screws that retain the tank housing cover. -
Page 9: Troubleshooting
Troubleshooting Problem Tool is inoperative. Cutting blades stop during operation. Tool loses oil. Greenlee / A Textron Company Probable Cause Dirt, contaminants, etc., in ram area of tool. Tool components worn or damaged. Oil level is low. Air in hydraulic system. -
Page 10: Service Center Information
13. Unscrew the shoulder bolt (99) and remove the release lever (107). 14. Remove screws (108) and separate the gear housing/motor subassembly from the pump housing. Greenlee / A Textron Company CSG50GL Cutting Tool Pump 1. Use a hooked tool to remove the reservoir O-ring (80). -
Page 11: Assembly
Using a hooked tool, carefully slip the O-ring over the lip of the pump housing. 7. Insert the plug (76) into the reservoir. Greenlee / A Textron Company CSG50GL Cutting Tool Main Components 1. Remove the protective plastic bag from the electronics subassembly. -
Page 12: Illustrations
CSG50GL Cutting Tool Illustration Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... - Page 13 CSG50GL Cutting Tool Illustration Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
- Page 14 CSG50GL Cutting Tool Illustration Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070...
-
Page 15: Parts List
500 4207.6 500 1565.6 500 1567.2 500 1569.9 500 1571.0 500 1566.4 Greenlee / A Textron Company Description Decal, identification ... 1 Decal, safety, 120 volt ... 1 Decal, safety, 230 volt ... 1 Decal, pinch hazard ... 2 Plate with microswitch, 120 volt ... 1 Plate with microswitch, 230 volt ... - Page 16 500 5879.7 500 8403.8 500 8402.2 500 1573.7 500 1574.5 500 1580.0 Greenlee / A Textron Company Description Pump housing, reservoir assembly (includes items 70–83) Ring tie ... 1 Cable tie ... 1 Threaded bushing ... 1 O-ring ... 1 Hydraulic reservoir ...
- Page 17 501 0369.5 154* 501 0366.0 501 0367.9 501 0368.7 500 1407.2 500 1598.2 Greenlee / A Textron Company Description Relief valve assembly (includes items 120–130) Washer ... 1 O-ring ... 1 Seal ... 1 Valve seat ... 1 Plunger ... 1 O-ring ...
- Page 18 800-435-0786 Fax: 815-397-7070 Fax: Canada 800-435-0786 Fax: International +1-815-397-7070 Fax: +1-815-397-9247 4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070 An ISO 9001 Company • Greenlee Textron Inc. is a subsidiary of Textron Inc. www.greenlee.com 800-451-2632 815-397-1865 800-524-2853...
