- Page 1 INSTRUCTION MANUAL Serialnummer GATOR ETS12 ® Single Use Lock Cutter and Bolt Cutter Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 52033632 REV 1 © 2008 Greenlee Textron Inc. 2/08...
-
Page 2: Table Of Contents
All specifications are nominal and may change as design improvements occur. Greenlee Textron Inc. shall not be liable for damages resulting from misapplication or misuse of its products. GATOR is a registered trademark of Greenlee Textron Inc. -
Page 3: Important Safety Information
Failure to observe this warning could result in severe injury or death. Greenlee / A Textron Company ETS12 Single Use Lock Cutter and Bolt Cutter 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070 Electric shock hazard: This tool is not insulated. When using... - Page 4 Failure to observe these precautions may result in injury or property damage. Greenlee / A Textron Company ETS12 Single Use Lock Cutter and Bolt Cutter Do not allow anything to contact the battery terminals. • Do not immerse the batteries in liquid. Liquid may create a short circuit and damage the battery.
-
Page 5: Identification
Aircraft Cable ...1/4" dia. Battery Charging Voltage ... 9.6 V Charging Time ... 60 min Not recommended for fine stranded cables. Greenlee / A Textron Company ETS12 Single Use Lock Cutter and Bolt Cutter 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070 T 15 ®... -
Page 6: Operation
• The cutting head of the ETS12 has been designed to turn 360° around the longitudinal axis in order to gain the best access to tight corners and other difficult working areas. -
Page 7: Maintenance
LED display glows continuously for 20 seconds. Tool loses oil. Greenlee / A Textron Company ETS12 Single Use Lock Cutter and Bolt Cutter After use: 1. Wipe all tool surfaces clean with a damp cloth and mild detergent. 2. Fully retract the ram. Place the tool in the carrying case. -
Page 8: Illustrations
ETS12 Single Use Lock Cutter and Bolt Cutter Illustrations Main Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 9: Motor Assembly
Illustrations (cont’d) Pump Housing Unit, Relief Valve Unit, and Piston Pump Assembly Motor Assembly Greenlee / A Textron Company ETS12 Single Use Lock Cutter and Bolt Cutter 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070... -
Page 10: Parts List
● Roll pin...1 ● Screw, socket head cap ...1 ● 50019295 Screw, hex head cap, m3x4 ...1 Spring, compression ...1 Head, cutter ...1 ETS12 Single Use Lock Cutter and Bolt Cutter Part No. 50018990 50019309 50109430 50042076 50019767 50043960 50019341...
