1
Introduction
BIOS
• Award BIOS, Windows
compatible
• Supports SCSI sequential boot-up
• Flash EPROM for easy BIOS upgrades
• Supports DMI 2.0 function
• 4Mbit flash memory
Desktop Management Interface (DMI)
The system board comes with a DMI 2.0 built into the BIOS. The
DMI utility in the BIOS automatically records various information
about your system configuration and stores these information in the
DMI pool, which is a part of the system board's Plug and Play
BIOS. DMI, along with the appropriately networked software, is
designed to make inventory, maintenance and troubleshooting of
computer systems easier. Refer to chapter 4 for instructions on
using the DMI utility.
Rear Panel I/O Ports (PC 99 color-coded connectors)
• One PS/2 mouse port
• One PS/2 keyboard port
• One DB-9 serial port
• One DB-25 parallel port
• One S/PDIF-out RCA jack
• Four USB 2.0/1.1 ports
• One RJ45 LAN port
• Three audio jacks: line-out, line-in and mic-in
I/O Connectors
• Two connectors for 4 additional external USB 2.0/1.1 ports
• One front audio connector for external line-out and mic-in
jacks
• One CD-in internal audio connector
• Two Serial ATA connectors
• Two IDE connectors
• One floppy connector
• Two ATX power supply connectors
• Two fan connectors
10
98/2000/ME/XP Plug and Play
®
