STACKED WILDWOOD
LS24WRR Shown
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING
FIRE OR EXPLOSION HAZARD
If the information in these instructions is
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Leave the building immediately.
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
LOG SET FOR UNVENTED
GAS LOG HEATER OR VENTED
DECORATIVE APPLIANCE
MODELS
LS24WRR-1
If not installed, operated and maintained in
accordance with the manufacturer's instruc-
tions, this product could expose you to sub-
stances in fuel or from fuel combustion which
can cause death or serious illness.
Log sets comply with ANSI Z21.11.2 Unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid Fuel
Burning Fireplaces. State or local codes may
only allow operation of log sets in a vented
configuration. Check your state or local codes.
Please See Our Website For Log Assembly Videos.
LS30WRR-1
GAS-FIRED
WARNING
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS24WRR-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Empire Comfort Systems LS24WRR-1

  • Page 1 INSTALLATION INSTRUCTIONS AND OWNER’S MANUAL STACKED WILDWOOD LOG SET FOR UNVENTED GAS LOG HEATER OR VENTED DECORATIVE APPLIANCE MODELS LS24WRR-1 LS30WRR-1 GAS-FIRED LS24WRR Shown WARNING If not installed, operated and maintained in INSTALLER: accordance with the manufacturer's instruc- Leave this manual with the appliance.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Section Page Important Installation Guidelines ..........................3 General Information ..............................3 Requirements for Canada ............................4 LS(24,30)WRR - Log Sets ............................5 Log Indentification - LS24WRR ............................6 Log Indentification - LS30WRR ............................7 Log Placement - Stacked Wildwood ........................8 - 14 Ember Placement - LS(24,30)WRR ...........................15 Appliance Service History ...........................16 - 18 Master Parts Distributor List ............................19 How to Order Repair Parts ............................19...
  • Page 3: Important Installation Guidelines

    IMPORTANT INSTALLATION GUIDELINES Proper Log Placement Candles Log placement is critical to proper burner performance. Logs must Avoid the use of scented or decorative candles while the log set is be correctly positioned onto the burner. The photos in this manual in operation.
  • Page 4: Requirements For Canada

    REQUIREMENTS FOR CANADA WARNING; DO NOT OPERATE THIS GAS LOG SET This unit cannot be installed in a UNVENTED application, WITH GLASS DOORS CLOSED this unit can only be installed as a VENTED application with these requirements. • Clothing or other flammable material should not be placed on or near the appliance.
  • Page 5: Ls(24,30)Wrr - Log Sets

    LS(24,30)WRR - LOG SETS LS24WRR - LOG SET LS30WRR - LOG SET 38708-0-0618 Page 5...
  • Page 6: Log Indentification - Ls24Wrr

    LOG IDENTIFICATION - LS24WRR PART NUMBER TOP VIEW FRONT VIEW & DESCRIPTION R12565 Rear Left (Log A) R12566 Rear Right (Log B) R12477 Front Right (Log C) R12478 Front Left (Log D) R12569 Center (Log E) Page 6 38708-0-0618...
  • Page 7: Log Indentification - Ls30Wrr

    LOG IDENTIFICATION - LS30WRR PART NUMBER TOP VIEW FRONT VIEW & DESCRIPTION R12568 Rear Left (Log A) R12631 Rear Right (Log B) R12599 Front Right (Log C) R12600 Front Left (Log D) R12569 Center (Log E) 38708-0-0618 Page 7...
  • Page 8: Log Placement - Stacked Wildwood

    Apply glowing embers per the ember placement section of this Refer to Figure 1 for the following warning. manual on page 15. Replace glowing embers with appropriate part number from the table below from Empire Comfort Systems, Inc. WARNING Application of excess glowing embers may adversely affect perfor- mance of the heater.
  • Page 9 LOG PLACEMENT - STACKED WILDWOOD Place left rear Log (A) onto left rear pin on rear log support. TOP VIEW LS30WRR LOG SET ONLY: Tuck the "L" shaped knob on the bottom of the log behind the burner to lock the log into place. (See circled area in picture.) FRONT VIEW 38708-0-0618...
  • Page 10 LOG PLACEMENT - STACKED WILDWOOD Place right rear Log (B) onto right rear pin on rear log support. TOP VIEW FRONT VIEW Page 10 38708-0-0618...
  • Page 11 LOG PLACEMENT - STACKED WILDWOOD Place right front Log (C) onto two (2) right front pins on burner pan. TOP VIEW FRONT VIEW 38708-0-0618 Page 11...
  • Page 12 LOG PLACEMENT - STACKED WILDWOOD Place left front Log (D) onto two (2) left front pins on burner pan. TOP VIEW FRONT VIEW Page 12 38708-0-0618...
  • Page 13 LOG PLACEMENT - STACKED WILDWOOD Insert boss on center Log (E) into recess on right side of left rear Log (A) and on right side of left front Log (D). TOP VIEW FRONT VIEW 38708-0-0618 Page 13...
  • Page 14 1. Place left, rear (#1) log onto left, rear pin on rear log support. LOG PLACEMENT - STACKED WILDWOOD Log placement is completed. TOP VIEW FRONT VIEW Page 14 38708-0-0618...
  • Page 15: Ember Placement - Ls(24,30)Wrr

    EMBER PLACEMENT - LS(24,30)WRR 38708-0-0618 Page 15...
  • Page 16: Appliance Service History

    APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes Page 16 38708-0-0618...
  • Page 17 APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes 38708-0-0618 Page 17...
  • Page 18 APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes Page 18 38708-0-0618...
  • Page 19: Master Parts Distributor List

    For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equip- ment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing F.
  • Page 20 Empire Comfort Systems Inc. Belleville, IL If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.empirecomfort.com Page 20 38708-0-0618...
