Empire Comfort Systems LK6-1 Installation Instructions

INSTRUCTIONS MUST BE LEFT WITH THE OWNER FOR FUTURE REFERENCE AFTER INSTALLATION
Tools Needed:
Phillips Screwdriver
Carton Contents:
Light Assembly
4 - #10 x 1/2" Screws
Bezel
Glass
Gasket
Light Bulb
f i r e - p a r t s . c o m
Installation
1. Remove the four screws securing the metal plate and gasket
to the top of the firebox and discard. See Figure 1.
2. Disconnect the two leads from the light assembly to the con-
trol assembly.
3. While wearing gloves, attach the light bulb to the light socket.
4. Feed the light kit wiring through the cut-out and down the right
side of the unit.
32752-1-0414
LK6-1 LIGHT KIT
INSTALLATION INSTRUCTIONS
For Use on Models
DVCP & DVCC
Figure 1
Empire Comfort Systems Inc. • 918 Freeburg Avenue • Belleville, IL 62220
GAS-FIRED
5. Secure the bezel, glass, gasket and light assembly to the
firebox with four screws. See Figure 2
6. Reconnect the wires disconnected in step two and connect
the power source to the wall outlet.
Figure 2
Page 1
