  • Page 1 PZN2710Q LCD Monitor...
  • Page 2 The information contained in this document is subject to change without notice. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be reproduced, translated to another language or stored in a retrieval system, or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission.

  • Page 3: Table Of Contents

    PLUG AND PLAY ......................17 TECHNICAL SUPPORT (FAQ) ..................18 ERROR MESSAGE & POSSIBLE SOLUTION ............19 APPENDIX ..........................20 SPECIFICATIONS ......................20 FACTORY PRESET TIMING TABLE ................. 21 CONNECTOR PIN ASSIGNMENT ................22 WALL MOUNTING (OPTIONAL) ................24 PLANAR SUPPORT ......................25...

  • Page 4: For Your Safety

    | FOR YOUR SAFETY Before operating the monitor, please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 5: Precautions

    Disposal of waste equipment by user in private household in the European Union This symbol on the product or on its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
  • Page 6 • Do not attempt to service the monitor by yourself; opening or removing covers can expose you to dangerous voltages and other hazards. Please refer all servicing to qualified service personnel. • To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate configured receptacles marked between 100 - 240V AC, Min.

  • Page 7: Special Notes On Lcd Monitors

    SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. NOTES AND CLEANING • Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears.

  • Page 8: Package List

    Lay the monitor flat on an even surface –display facing up. Remove Styrofoam Remove the bag. PACKAGE LIST The product package should include the following items: Monitor PZN2710Q LCD Monitor User's Guide AC/DC Adapter DP cable Type-C cable Note: Use only the AC/DC adapter model: ADP-135KB T.

  • Page 9: Installation Instructions

    INSTALLATION INSTRUCTIONS Attach the base organizer.

  • Page 10: Controls And Connectors

    CONTROLS AND CONNECTORS POWER CORD Power Source: Make sure that the power cord is the correct type required in your area. Connect the power cord to the adapter, then the DC cord to the LCD Monitor. SIGNAL CABLE Connecting the Signal Cable : Plug one end of the signal cable to the LCD monitor and the other end to a computer or a video source (Type C, HDMI or DP).
  • Page 11 With USB Type-C/Displayport Multi-Stream Transport (MST) support, you can daisy chain to another monitor. Connect one end of a DisplayPort/USB Type-C cable to the PZN2710Q monitor and the other end to a computer. Next connect the Displayport output cable on the PZN2710Q monitor to the Displayport input of another monitor.

  • Page 12: Adjusting The Viewing Angle

    ADJUSTING THE VIEWING ANGLE • For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. • Hold the stand so you do not topple the monitor when you change the monitor’s angle. •...

  • Page 13: Operating Instructions

    | OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS The control buttons are located at the back of the monitor (See Figure 4). Press the power button to turn the monitor on or off. By changing these settings, the picture can be adjusted to your personal preferences. •...

  • Page 14: Front Panel Control

    FRONT PANEL CONTROL • Power Button: Press this button to switch ON/OFF monitor’s power. • Power Indicator: Blue — Power on mode. Orange —Power saving mode. • [1]: OSD / Exit: Activates OSD menu or exit selection. : Volume / Blue Light Reducer: •...

  • Page 15: How To Adjust A Setting

    HOW TO ADJUST A SETTING 1. Press the [1] button to activate the OSD window. 2. Press to navigate through the functions. Once the desired function is highlighted, press the [2] button to activate it. If the function selected has a sub-menu, press again to navigate through the sub-menu functions.

  • Page 16: Adjusting The Picture

    ADJUSTING THE PICTURE Main Menu Main Menu Description Item Icon Menu Item Luminance Contrast Adjusts contrast levels. Brightness Adjusts backlight levels. Eco Mode Picture Adjustment, Standard: Brightness = 70, Contrast = 50. Brightness, Contrast Adjustable Text: Brightness = 20, Contrast = 50. Brightness, Contrast Grayed.
  • Page 17 Main Menu Main Menu Description Item Icon Menu Item Color Warm Recall Warm Color Temperature . Temp. Normal Recall Normal Color Temperature . Cool Recall Cool Color Temperature . User Adjust R.G.B levels as desired. User-R:Red Gain from Digital-register. User-G:Green Gain from Digital-register. User-B:Blue Gain from Digital-register.

  • Page 18: Plug And Play

    PLUG AND PLAY Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. The DDC2B is a bidirectional data channel based on the I²C protocol.

  • Page 19: Technical Support (Faq)

    TECHNICAL SUPPORT (FAQ) Problem & Question Possible Solution Power LED is not on * Check if the Power Switch is in the ON position. * Power Cord should be connected. No Plug & Play * Check if the PC system is Plug & Play compatible.

  • Page 20: Error Message & Possible Solution

    TECHNICAL SUPPORT (FAQ) CLOCK (pixel frequency) controls the number of pixels scanned by one horizontal sweep. If the frequency is not correct, the screen shows vertical stripes and the picture has not correct width. PHASE adjusts the phase of the pixel clock signal. With a wrong phase adjustment the picture has horizontal disturbances in light picture.

  • Page 21: Appendix

    | APPENDIX SPECIFICATIONS LCD Panel Driving system TFT Color LCD Size 68.58 cm(27") Pixel pitch 0.2331 (H) x 0.2331 (V) mm Input Video Digital H-Frequency 30 – 99 kHz V-Frequency 48-75 Hz Display Colors 16.7 M Max. Resolution 2560 x 1440 @ 60 Hz Plug &...

  • Page 22: Factory Preset Timing Table

    FACTORY PRESET TIMING TABLE Preset HDMI/Displayport Modes Standard Resolution (Hz) HDMI 640 × 480 @ 60 640 × 480 @ 67 640 × 480 @ 72 640 × 480 @ 75 720 × 400 @ 70 SVGA 800 × 600 @ 56 SVGA 800 ×...

  • Page 23: Connector Pin Assignment

    CONNECTOR PIN ASSIGNMENT 20 - Pin Color Display Signal Cable PIN NO. DESCRIPTION PIN NO. DESCRIPTION ML_Lane 3 (n) ML_Lane 0 (p) ML_Lane 3 (p) CONFIG1 ML_Lane 2 (n) CONFIG2 AUX_CH(p) ML_Lane 2 (p) ML_Lane 1 (n) AUX_CH(n) Hot Plug Detect ML_Lane 1 (p) Return DP_PWR ML_Lane 0 (n)
  • Page 24 19 - Pin Color Display Signal Cable PIN NO. DESCRIPTION PIN NO. DESCRIPTION TMDS Data 2+ TMDS Clock Shield TMDS Data 2 Shield TMDS Clock- TMDS Data 2- TMDS Data 1+ Reserved (N.C. on device) TMDS Data 1 Shield TMDS Data 1- TMDS Data 0+ DDC/CEC Ground TMDS Data 0 Shield...

  • Page 25: Wall Mounting (Optional)

    WALL MOUNTING (OPTIONAL) Refer to the instructions that come with the base mounting kit. To convert your display from a desk-mounted to a wall-mounted display, do the following: 1. Verify that the power button is turned Off, then disconnect the power cord. 2.

  • Page 26: Planar Support

    | PLANAR SUPPORT Cables and Accessories To find cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touch screen drivers, warranty information and access to Planar's Technical Library for online troubleshooting.
  • Page 27 Planar Address: 1195 NE Compton Drive, Hillsboro, OR 97006 USA Q41G27M193501A...
