3.4 Working with the Mix

IP 1 IP 2 IP 3 IP 4 IP 5 IP 6
ON
+ press Mix Assign Routing
Mix
Channel faders
Master Mix view
IP 1 IP 2 IP 3 IP 4 IP 5 IP 6
ON PRE
+ press Sel
+ press Mix Assign Routing
All sends to one master
Channel Mix view
IP 5
IP 4 IP 6 IP 7 IP 8
Pre/Post
Assign Routing
Channel faders
DCA and Audio Group assign
IP 4 IP 5 IP 6 IP 7
DCA
ON
+ press Mix Assign
CTi-1500 Surface Getting Started Guide
Main
IP 7 IP 8 Aux1 Aux2
hold
down
Master faders
Access Aux, FX, Matrix mix on faders
Aux2
IP 7 IP 8 Aux1
hold
down
Pre/Post all
all
Master faders
Aux1 Aux2 Aux3
hold
PRE ON
down


All sends from one input
DCA
IP 8 Grp1 Grp2
hold
down
all

13
Mix active
Press a Main Mix master strip
LR
Aux3
This is the normal mixing mode. The Input strips
present the channel faders. The Master strips
Mix
present the master mix faders.
Hold down the Assign key and press channel
Mix keys to assign or unassign them from the
main mix. Current ON status is displayed on the
lower part of the strip LCDs.
Press a Mix master strip
Aux3 Aux4
Use this to work with Aux and FX sends. The
Input strips present all the send levels to the
Sel active Mix. The Master strips present the master
mix faders.
Mix
Hold down the Assign key and press channel
Mix keys to assign or unassign them from the
active Mix.
Hold down the Pre/Post key and press channel
Sel keys to toggle each source pre or post fader.
Current PRE status is displayed on the lower part
of the channel strip LCDs.
You can quickly set all assignments on or off, or
all sources pre or post fader by pressing the
Master strip
Press an Input Channel strip
Aux4
Use this to work with Aux and FX sends. The Input
strips remain as Channel Faders. The Master
strips present all sends from the Input channel.
Sel
Hold down the Assign key and press master
keys to assign or unassign the channel from each
Mix
mix.
Hold down the Pre/Post key and press master
keys to toggle the channel pre or post fader to
each mix. Current PRE status is displayed on the
master strip LCDs.
Press a Group Master strip
Use this to assign channels to the Audio and DCA
1 DCA2
groups. The Input and Master faders are not
affected.
Mix
Hold down the Assign key and press channel
keys to assign or unassign the channels from the
group.
Mix key.
Mix key.
Mix or Sel key.
Mix key.
Mix key.
