0323-TP-DPST
Toilet Paper Holder
Installation Guide
Model Numbers
0323-TP-DPST
Toilet Paper Holder
Warranty
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Dimensions
A A
C C
B B
Note: Dimensions subject to change without notice.
Dia
®
D D
Specification
Toilet Paper Holder shall be made from metal construction,
plated in standard polished chrome finish.
Options/Modifications
☐
-STN
Satin Nickel finish
Note: Append appropriate -suffix to model number.
E E
F F
Measurements
A
6", 152 mm
B
(2x) Ø 1-7/8", 48 mm
(4x) Hole Size
C
Ø 5/16", 8 mm
D
(2x) 3/4", 19 mm
E
5/8", 16 mm
F
3-7/16", 87 mm
