User's Manual
OL8000RT3UTF
CyberPower Systems (USA), Inc.
4241 12th Avenue East Suite 400 Shakopee, MN 55379
Phone: 877-297-6937
Fax: 952-403-0009
www.CPSww.com
K01-0000195-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OL8000RT3UTF and is the answer not in the manual?

Questions and answers

Related Manuals for CyberPower OL8000RT3UTF

Summary of Contents for CyberPower OL8000RT3UTF

  • Page 1 User’s Manual OL8000RT3UTF CyberPower Systems (USA), Inc. 4241 12th Avenue East Suite 400 Shakopee, MN 55379 Phone: 877-297-6937 Fax: 952-403-0009 www.CPSww.com K01-0000195-02...

  • Page 2: Important Safety Instructions

    REQUIRED PRECAUTIONS. KEEP UNAUTHORIZED PERSONNEL AWAY FROM BATTERIES! CAUTION! Do not use an improper size power cord as it may cause damage to your equipment and cause fire hazards. Copyright © 2011 CyberPower Systems, Inc.
  • Page 3 Rackmount right rail * 2 sets Plastic washers (8) * 2 sets Phone line Screw hole dust covers (10) * 2 sets USB communication cable Power cords PowerPanel® Business Edition software CD Serial Interface Cable (RS-232) Copyright © 2011 CyberPower Systems, Inc.

  • Page 4: Hardware Installation

    Step 5: Place the internal battery trays back into the Battery module (See page 17) Once completed, perform the same steps for the Power module. CAUTION! The Battery module must be installed below the Power module. Copyright © 2011 CyberPower Systems, Inc.

  • Page 5: Vertical/Tower Installation

    CAUTION! Do not work alone under hazardous conditions. CAUTION! In case of the risk of electric shock, do not remove the top cover. CAUTION! The battery can energize hazardous live parts inside even when the AC input power is disconnected. Copyright © 2011 CyberPower Systems, Inc.

  • Page 6: Installing Your Ups System

    UPS will continuously emit two beeps per second. For resetting the unit, unplug some equipment from the outlets. Make sure your equipment carries a load current within the unit’s safe range, (refer to the technical specifications). Copyright © 2011 CyberPower Systems, Inc.

  • Page 7: Hardwiring The Input/ Output Terminals

    Step 2: Fix the bottom cover on the terminal block Loosen the four screws to separate the top and bottom covers. Tighten the two screws to fix the bottom cover on the terminal block. Copyright © 2011 CyberPower Systems, Inc.
  • Page 8 Connect the three wires to the output terminal block. Connect the three wires to the input terminal block. Step 5: Fix the top cover on the bottom cover Tighten the six screws to fix the top cover on the bottom cover. Copyright © 2011 CyberPower Systems, Inc.

  • Page 9: Backfeed Protection

    3. Hardwire the input terminals and “Backfeed Protection Connector” as shown in the following diagram. 4. The external isolation device must be installed in the Mains path. Mains L1 L2 PE IP-L1 IP-L2 PSDR 2A Fuse Backfeed (Slow Blow) AC-L1 AC-L2 Copyright © 2011 CyberPower Systems, Inc.

  • Page 10: Basic Operation

    It is recommended to install the PowerPanel® Business 15. Extended Runtime Battery Module Connector Edition Agent software on the PC/Server connected with Connection for additional CyberPower XL Battery modules. the USB cord. 16. EPO (Emergency Power Off) Connector 11. Remote Control Port Enables an emergency UPS Power-Off from a remote location.
  • Page 11 Step 5: Use a power cord to plug AC input inlet of the battery module into a wall receptacle. Step 6: Turn on the DC breaker of the Battery module. Copyright © 2011 CyberPower Systems, Inc.
  • Page 12 Step 6: Use a power cord to plug AC input inlet of the 2 battery module into AC output outlet of the 1 Battery module. Step 7: Turn on the DC breaker of the 2 Battery module. Copyright © 2011 CyberPower Systems, Inc.

  • Page 13: Led Indicators - Ups Status

    Press this button to scroll up in the LCD menu. ▼ Press this button to scroll down in the LCD menu. ENTER Press this button to select an option. Press this button to cancel or return to previous LCD menu. Copyright © 2011 CyberPower Systems, Inc.

  • Page 14: Lcd Setup Functions

    Date & Time Displays the present Date & Time - - - - / - - / - - - -:- - Next BAT Change Displays the next Battery Change Date & Time XXX / XXXX Copyright © 2011 CyberPower Systems, Inc.

  • Page 15: Lcd Event Log

    You may be prompted to save the selection, if so press the “ENTER” button to save the setting. Some options are saved and started automatically. (See the following table for additional details.) Press the “ESC” button to cancel or return to the previous LCD menu. Copyright © 2011 CyberPower Systems, Inc.
  • Page 16 Configure “Audible Alarms” as “Disable” on the LCD module and it will stop warning of any malfunction audibly. MANUAL BATTERY TEST Configure “Battery Test” as “Active” on the LCD module; and it will perform the “Manual Battery Test” Copyright © 2011 CyberPower Systems, Inc.

  • Page 17: Lcd Module Remote Control And Wall-Mounting Instructions

    Step 4: Mount LCD Module on the Wall SAFETY PRECAUTIONS CAUTION! It must be done by qualified personnel. CAUTION! To avoid electric shock, turn off and unplug the unit before installing REMOTE CONTROL or WALL-MOUNTING INSTRUCTIONS. Copyright © 2011 CyberPower Systems, Inc.

  • Page 18: Maintenance

    Only use replacement batteries which are certified by Batteries are considered hazardous waste and must be disposed of CyberPower Systems. Use of incorrect battery type is an electrical properly. Contact your local government for more information about hazard that could lead to explosion, fire, electric shock, or short circuit.

  • Page 19: Technical Specifications

    L x W x H = 26 x 17 x 5.2in. (66 x 43.3 x 13.2cm) Net Weight--Power Module 53lbs(24Kg) Net Weight--Battery Module 167.2lbs(76Kg) 171.6lbs(78Kg) Safety Conformance Approvals CE, UL *)200V are derated by 20%, 208 V are derated by 10% for OL6000RT3U Copyright © 2011 CyberPower Systems, Inc.

  • Page 20: Troubleshooting

    Internal DC bus voltage is too high or too low. CyberPower Systems Inc. www.cpsww.com © Entire contents copyright 2011 CyberPower Systems Inc., All rights reserved. Reproduction in whole or in part ® ® without permission is prohibited. PowerPanel Business Edition and PowerPanel Personal Edition are trademarks of CyberPower Systems Inc.

  • Page 21: Product Registration

    If the Product is defective in material or workmanship, CyberPower will repair or replace it at CyberPower's expense, or, if CyberPower is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required).
  • Page 22 (collectively, "High Risk Activities"). CyberPower expressly disclaims any express or implied warranty of fitness for High Risk Activities or with aquariums. CyberPower does not authorize use of any Product in any High Risk Activities or with Aquariums.

  • Page 23: Conformance Approvals

    Cet appareil numerique de la class A respecte toutes les exigencies du Reglement sur le materiel brouilleur du Canada. This document is believed to be accurate, but CyberPower reserves the right to change or correct the contents and does not assume any responsibility for omissions or errors.
  • Page 24 User’s Manual Step-Down Transformer OL8K10KRT3UTF CyberPower Systems (USA), Inc. 4241 12th Avenue East Suite 400 Shakopee, MN 55379 Phone: 877-297-6937 Fax: 952-403-0009 www.CPSww.com K01-0000212-01...
  • Page 25 The CyberPower Step-Down Transformers support installation with power cord L6-30P (OL6KRT2UTF / OL8K10KRT3UTF) or hardwire (OL6KRT2UTFHW / OL8K10KRT3UTFHW), and are designed for a variety of CyberPower UPS systems. When combined with the UPS, the Step-Down Transformer converts voltage from 200-240V down to 100-120V.

  • Page 26: Hardware Installation

    M5X12L screws at the front of the rack. The 2U Step-Down Transformer takes up position 2 through position 5. The 3U Step-Down Transformer takes up position 2 through position 8. CAUTION! The Step-Down Transformer must be installed above the power module. Copyright © 2011 CyberPower Systems, Inc.
  • Page 27 CAUTION! Do not work alone under hazardous conditions. CAUTION! In case of the risk of electric shock, do not remove the top cover. CAUTION! The battery can energize hazardous live parts inside even when the AC input power is disconnected. Copyright © 2011 CyberPower Systems, Inc.
  • Page 28 Loosen the four screws to separate the top and bottom covers. Step 2: Fix the bottom cover on the terminal block Tighten the two screws to fix the bottom cover on the terminal block. Copyright © 2011 CyberPower Systems, Inc.

  • Page 29: Hardwiring The Input/ Output Terminals

    HARDWIRING THE INPUT/ OUTPUT TERMINALS Step 3: Input configuration Insert the input cable through the appropriate cable gland (not included). Connect the three wires to the input terminal block. Copyright © 2011 CyberPower Systems, Inc.
  • Page 30 Step 4: Fix the top cover on the bottom cover Tighten the five screws to fix the top cover on the bottom cover. Step 5: Connect the other side of the input cable to UPS output terminal block. Copyright © 2011 CyberPower Systems, Inc.
  • Page 31 Provides battery backup and surge protection. They ensure power is OL6KRT2UTF provided to connected equipment over a period of time during a power failure. 6. Output Circuit Breaker (208Vac) Provides output overload and fault protection. OL6KRT2UTFHW OL8K10KRT3UTF OL8K10KRT3UTFHW Copyright © 2011 CyberPower Systems, Inc.
  • Page 32 CAUTION! Before connecting to the UPS, check that the input voltage into the UPS is within specifications. CyberPower Systems Inc. www.cpsww.com © Entire contents copyright 2011 CyberPower Systems Inc., All rights reserved. Reproduction in whole or in part ® ® without permission is prohibited. PowerPanel Business Edition and PowerPanel...
  • Page 33 If the Product is defective in material or workmanship, CyberPower will repair or replace it at CyberPower's expense, or, if CyberPower is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required).
  • Page 34 (collectively, "High Risk Activities"). CyberPower expressly disclaims any express or implied warranty of fitness for High Risk Activities or with aquariums. CyberPower does not authorize use of any Product in any High Risk Activities or with Aquariums.
  • Page 35 Cet appareil numerique de la class A respecte toutes les exigencies du Reglement sur le materiel brouilleur du Canada. This document is believed to be accurate, but CyberPower reserves the right to change or correct the contents and does not assume any responsibility for omissions or errors.
