- Page 1 Quick Installation Guide Applicable Models AS6508T / AS6510T Ver.2.3.0903 (2015-3-2) Ver.3.4.0606(2019-6-6)
-
Page 2: Table Of Contents
Table of Contents Notices ............................ 3 Safety Precautions ........................4 1. Package Contents ......................5 2. Optional Accessories ......................7 3. Hardware Installation Guide ....................8 Tools Needed for Hard Disk Installation ................8 Hard Disk Installation ......................8 Connecting and Powering on the NAS ................10 Upgrading System Memory .................... -
Page 3: Notices
Notices Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. -
Page 4: Safety Precautions
Safety Precautions The following safety precautions will increase the life of the NAS. Follow all precautions and instructions. Electrical Safety Unplug this product from the power source before cleaning. Use only the bundled power adapter. Using other power adapters may damage your device. Ensure that you plug the power adapter to the correct power input rating. -
Page 5: Package Contents
1. Package Contents Applicable Models: AS6508T, AS6510T Model Name AS6508T AS6510T Power Cord RJ45 Network Cable 10 Gigabit Network Cable M.2 thumbscrews Screws for use with 3.5” HDD... - Page 6 Screws for use with 2.5” HDD Quick Installation Guide...
-
Page 7: Optional Accessories
2. Optional Accessories The items below may be purchased from the ASUSTOR Accessories Store http://shop.asustor.com. -
Page 8: Hardware Installation Guide
At least one 2.5 or 3.5 inch SATA hard disk. (For a list of compatible hard disks, please see http://www.asustor.com/service/hd?id=hd) Hard Disk Installation 1. Press the button on the lower portion of the hard disk tray to release the latch. - Page 9 3.5-inch hard disks: Place the hard disk into the disk tray, making sure that the mounting holes on the sides of the hard disk and disk tray are lined up. Secure the drive with four screws. 2.5-inch hard disks and SSD hard disks: Place the hard disk into the area of the disk tray outlined in red (see picture below).
-
Page 10: Connecting And Powering On The Nas
5. Once the latch is secure, you can lock it in place using the disk tray lock. Using a flathead screwdriver, turn the lock counterclockwise to lock the latch mechanism. Turning the lock clockwise will unlock it. Connecting and Powering on the NAS Connect the NAS to its power supply. -
Page 11: Upgrading System Memory
Your NAS and memory modules use high precision components and electronic connector technology. To avoid invalidation of the warranty during your product warranty period, we recommend that: Memory for AS65 series devices may be purchased from local dealers or the online ASUSTOR Accessories Store (http://shop.asustor.com). - Page 12 Removing the Cover 1. Shutdown the NAS by selecting [Shut down] from the ADM User Menu. 2. Disconnect all cables and devices connected to the NAS including the power cord. 3. Use a screwdriver to loosen the three screws found on the rear of the NAS as shown in the illustration. 4.
- Page 13 Installing Memory 1. Upon opening the NAS, RAM slots can be found on the motherboard on the left hand side of the NAS. Insert a DIMM into an empty slot at a 45° angle and align the notches of the RAM and the slot. 2.
-
Page 14: Installing M.2 Ssd
Note: Upon installation of new RAM, your ASUSTOR NAS will perform a memory check on startup. This process occurs only once and may take up to 10 minutes to complete. This is normal. Replacing the Cover 1. Replace the cover and tighten the three screws that were removed previously. - Page 15 Disconnect all cables and devices connected to the NAS including the power cord. Use a screwdriver to loosen the three screws found on the rear of the NAS as shown in the illustration. Grip the cover from both sides with two hands and then gently push it back to remove it from the chassis.
- Page 16 M.2 SSDs. 2. If installing two drives, ASUSTOR recommends that they be the same model for optimum performance. 3. Do not mix PCIe NVMe and SATA AHCI SSDs in the M.2 slots as your NAS will not boot with both types of drives installed.
- Page 17 2. Adjust the standoff so that it matches the length of your SSD. Gently push the drive down as indicated by the arrow so that it is flush with the location of the standoff. Secure drive with included thumbscrew. Repeat process for second drive.
-
Page 18: Software Installation Guide
The installation wizard will install ASUSTOR Control Center onto your computer. After ASUSTOR Control Center has been installed, it will automatically begin to scan your network for ASUSTOR NAS devices. Select your NAS from the list and follow the installation wizard’s instructions to complete the configuration... - Page 19 Mac Users After ASUSTOR Control Center has been installed, it will automatically begin to scan your network for ASUSTOR NAS devices. Select your NAS from the list and follow the installation wizard’s instructions to complete the configuration process.
-
Page 20: Web Installation
Web Installation If you already know your NAS’s current IP address, you can open up a web browser and enter in your NAS’s IP address (for example: http://192.168.1.168:8000) to begin initialization. Please follow the instructions from the installation wizard to complete the configuration process. -
Page 21: Installation Using A Mobile Device
Installation Using a Mobile Device Search for “AiMaster” in Google Play or the Apple App Store. You can also scan the QR codes provided below. Download and install the AiMaster mobile app to your mobile device. AiMaster for Android AiMaster for iOS Make sure that your mobile device is connected to the same local network that your NAS is connected to. - Page 22 Select your NAS from the list that appears. Select [Start Initialization] to begin installation. Follow the prompts and instructions to complete the configuration process.
-
Page 23: Installation Using The Lcd Display
Installation Using the LCD Display The LCD display will ask you whether or not you want initialize the NAS once it has detected that the NAS has not yet started to initialize. Please use the "↵” button found on the right side of the LCD display to confirm that you want to initialize the NAS. -
Page 24: Installation Using A Direct Connection
Installation Using a Direct Connection Troubleshooting Please see section for installation instructions. Shutting Down Your NAS 1. Confirm the function settings for the power button as shown in the graphic below. When the power button is held down for 1.5 seconds you can decide whether to shut down the NAS or have it enter into sleep mode. This setting may be access from within ADM by selecting: [Settings][Hardware] ... -
Page 25: Appendix
4. Network LED Indicator * 5. USB LED Indicator * Additional notes: The AS6508T and AS6510T NAS devices have two LEDs indicating network connection on the front of the NAS. LAN LED 1 indicates that a 2.5-Gigabit LAN connection has been established, while LAN LED 2 is for 10-Gigabit connections. -
Page 26: Rear Panel
Rear Panel 1. Power Supply Unit 2. USB 3.2 Gen 1 Port 3. 10G RJ45 Port 4. 2.5G RJ45 Port 5. Reset Button 6. K-lock 7. System Fan Operating the LCD Panel You can use the LCD panel to configure system settings and check system information. The buttons located on the right side of the LCD panel can be used to navigate through its menus. - Page 27 2. Network 3. Storage 4. Temperature 5. Operation 6. Configuration Press the [Up] or [Down] buttons to navigate through the menu items. Press the [Confirm] button to enter into any submenu. Press the [Back] button to return to the previous level. 1.
- Page 28 In the Temperature submenu you can use the [Up], [Down] and [Confirm] buttons to view the temperature for the items listed below. 4.1. CPU: The temperature of the CPU. 4.2. System: The temperature of the NAS system. 4.3. HDD: The temperature of the hard disks. 5.
-
Page 29: Troubleshooting
“No”. Troubleshooting Q: Why can’t I detect my ASUSTOR NAS using ASUSTOR Control Center? A: If you are having trouble detecting your NAS using ASUSTOR Control Center, please do the following: 1. Please check your network connection: Make sure that your computer and your NAS are part of the same local area network. - Page 30 Right-click on [Local Area Connection] and select [Properties]. Under the [Networking] tab select [Internet Protocol Version 4 (TCP/IPv4)] and click on [Properties].
- Page 31 Under the [General] tab select the [Use the following IP address] radio button. Set the [IP address] to 169.254.1.10 and the [Subnet mask] to 255.255.0.0 and then click on [OK].
- Page 32 Open up ASUSTOR Control Center to scan for your NAS.
- Page 33 4. If the above mentioned procedures have not managed to solve your problem, please contact your local ASUSTOR dealer or ASUSTOR Customer Service http://support.asustor.com.You are also encouraged ASUSTOR Knowledgebase. to browse through the...
