INSTALLATION
8. Fix the lower hinge to the opposite side
securely. Fix the hinge deep into the bottom.
Then fix the removed foot and screw to the
opposite side.
GB
9. Return the unit to the standing position.
10. Remove the pin from the upper hinge. Turn
the hinge over then re-insert the pin.
11. Remove screw hole caps, then insert them to
the opposite side.
12. Put the door on the lower hinge.
13. Holding the door against the unit, insert the
pin of the upper hinge into the hole in the
upper corner of the door.
14. Make sure the door is properly aligned then
securely fix the upper hinge with the screws.
15. Check and make sure there is no gap
between the door gasket and cabinet. If gap
is found, remove the door and re-adjust the
depth of the lower hinge.
16. Replace the top cover on studs and fix the
screws.
18
