Appendices
Remark :
1.> " "compressed
*
computer image.
2.> The column of Digi-
tal is support DVI-D
connector.
English 36

Compatibility Modes

Mode Resolution
VESA VGA 640 x 350
VESA VGA 640 x 350
VESA VGA 640 x 400
VESA VGA 640 x 480
VESA VGA 640 x 480
VESA VGA 640 x 480
VESA VGA 640 x 480
VESA VGA 720 x 400
VESA VGA 720 x 400
VESA SVGA 800 x 600
VESA SVGA 800 x 600
VESA SVGA 800 x 600
VESA SVGA 800 x 600
VESA SVGA 800 x 600
VESA XGA 1024 x 768
VESA XGA 1024 x 768
VESA XGA 1024 x 768
VESA XGA 1024 x 768
* VESA SXGA 1152 x 864
* VESA SXGA 1152 x 864
* VESA SXGA 1152 x 864
* VESA SXGA 1280 x 1024
MAC LC 13" 640 x 480
MAC II 13" 640 x 480
MAC 16" 832 x 624
MAC 19" 1024 x 768
* MAC 1152 x 870
MAC G4 640 x 480
i MAC DV 1024 x 768
* i MAC DV 1152 x 870
* i MAC DV 1280 x 960
(ANALOG)
V.Frequency H.Frequency
(Hz) (kHz)
70 31.5
85 37.9
85 37.9
60 31.5
72 37.9
75 37.5
85 43.3
70 31.5
85 37.9
56 35.2
60 37.9
72 48.1
75 46.9
85 53.7
60 48.4
70 56.5
75 60.0
85 68.7
70 63.8
75 67.5
85 77.1
60 63.98
66.66 34.98
66.68 35
74.55 49.725
75 60.24
75.06 68.68
60 31.35
75 60
75 68.49
60 60.0
(Digital)
V.Frequency H.Frequency
(Hz) (kHz)
70 31.5
85 37.9
85 37.9
60 31.5
72 37.9
75 37.5
85 43.3
70 31.5
85 37.9
56 35.2
60 37.9
72 48.1
75 46.9
85 53.7
60 48.4
70 56.5
75 60.0
85 68.7
70 63.8
75 67.5
85 77.1
60 63.98
*** ***
*** ***
*** ***
*** ***
*** ***
*** ***
*** ***
*** ***
*** ***
