EP750/755
Preface
This manual is prepared for the maintenance service for EP750/755
Micro-portable SVGA/XGA DLP Projector. Maintenance procedures
described in this manual are intended to isolate faulty parts and replace
them in the field. It also aims to serve as a guide in procuring
replacement parts for this product.
This manual is copyrighted and all rights are reserved. This product
may not, in whole or in part, be copied, photocopied, translated or
reduced to any electronic or machine readable form without prior
written consent except for copies retained by the purchaser for backup
purpose.
This manual includes system overview, major system assembly,
components’ description, and the “Troubleshooting” making
explanations on how to detect errors. It also includes a flow chart for
checking or correcting faults.
No warranty or representation, either expressed or implied, is made
with respect to this documentation, its quality, performance,
merchantability or fitness for particular purpose.
No event that the vendor will be liable for direct, indirect, special,
incidental or consequential damages arising out of the user or inability
to use this product or documentation.
NOTICE :
The information found in this manual is subject to change
without prior notice. Any subsequent changes made to the
data herein will be incorporated in further edition.
Copyright 2001, December
All Rights Reserved
Manual Version 1.0
Document # 836-G04-01A
P/ N : 36. 83603. 001
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
0-1
