Table of Contents
Precautions .......................................................................................... 2
Product Features .................................................................................. 3
Package Overview ............................................................................... 4
Product Overview ................................................................................. 5
Connecting the Projector to Desktop Computer ................................... 8
Connecting the Projector to Portable Computer ................................... 9
Connecting the Projector to Other Video Sources ............................... 10
Powering On/Off the Projection Display ............................................... 12
Adjusting the Projected image .............................................................. 14
On-Screen Display Menus ................................................................... 18
Troubleshooting .................................................................................... 22
Changing the Lamp ............................................................................... 25
Specifications ....................................................................................... 26
Compatibility Modes ............................................................................. 27
1
English
Advertisement
Table of Contents
Related Manuals for Optoma Optoma EP705H
Summary of Contents for Optoma Optoma EP705H
-
Page 1: Table Of Contents
Installation Connecting the Projector to Desktop Computer ... 8 Connecting the Projector to Portable Computer ... 9 Connecting the Projector to Other Video Sources ... 10 Powering On/Off the Projection Display ... 12 Adjusting the Projected image ... 14 User Controls Panel Control &... -
Page 2: Usage Notice
English Usage Notice Do not look into the lens. The bright light may hurt your eyes. Warning- To reduce the risk of fire or electric shock, do not expose this Warning- product to rain or moisture. Please do not open or disassemble the product as this may cause Warning- electric shock. -
Page 3: Introduction
Introduction Product Features This product, is an SVGA single chip 0.7”DLPä Projector. The outstanding features of it are listed as follows: True SVGA, 800 x 600 addressable pixels 5 lbs (2.3 kgs) lightweight compact design ä Single chip DLP technology... -
Page 4: Package Overview
English Package Overview This projection display comes with all the items shown below. Check to make sure your unit is complete. Contact your dealer immediately if anything is missing. Projection Display Power Cord VGA Cable S-Video Cable Audio-In Cable for Computer Composite Video Cable Audio Cable User’s Manual... -
Page 5: Product Overview
Product Overview Main Unit Focus Ring Focus Ring Lens Firmware Upgrade Port Carrying Handle Connection Ports Power Connector Power Switch v v v v v Notice : Firmware Upgrade is for after service purpose only. Panel Control Security Lock Slot English Remote Control Receiver... -
Page 6: Connection Ports
English Connection Ports Composite Video Connector S-video Connector Power Connector Panel Control Four Directional Select Keys Menu Reset Source COMPUTER IN S-VIDEO VIDEO AUDIO Computer Input Connector Audio Iuput Connector Audio Output Connector Power Switch Power / Standby Temperature Lamp Enter... -
Page 7: Remote Control
Remote Control Source Reset Freeze/CLR Menu Keystone Correction Four Directional Select Keys Enter English Power / Standby Resync Mute Picture in Picture Volume ( + / - ) Zoom In / Zoom Out... -
Page 8: Installation
2. Connect one end of the projector signal cable to the projector; connect the other end to the VGA connector on the computer and tighten the screws. 3. Connect one end of the power cord into the back of projector; connect the other end to an electrical outlet. -
Page 9: Connecting The Projector To Portable Computer
2. Connect one end of the projector signal cable to the projector; connect the other end to the VGA connector on the notebook and tighten the screws. 3. Connect one end of the power cord into the back of projector; connect the other end to an electrical outlet. -
Page 10: Connecting The Projector To Other Video Sources
“Audio in” port on the speaker; plug the other end into the “Audio out” port on the projector. 4. Connect one end of the power cord into the back of projector; connect the other end to an electrical outlet. - Page 11 “Audio in” port on the speaker; plug the other end into the “Audio out” port on your projector. 4. Connect one end of the power cord into the back of projector; connect the other end to an electrical outlet.
-
Page 12: Powering On/Off The Projection Display
1. Remove the lens cap.Œ 2. Ensure that the power cord and signal cable are securely connected. 3. Turn on the main power switch on the back of the projector and allow the projector to warm up for 1-2 minutes.... - Page 13 *If you want to turn on the main power switch immediately, you must allow about 10 minutes for thermal dissipation. 4. Disconnect the power cord from the electrical outlet and the projector. * When the “LAMP” indicator lights solid amber; please change the lamp module immediately.
-
Page 14: Adjusting The Projected Image
To lower the projector: 1. Press and hold the elevator button. 2. Lower down the projector, then release the button to lock the elevator foot into position. * When you adjust the projector height; please place the projector on a flat surface and avoid falling down of the projector. -
Page 15: Adjusting The Projector Focus
Adjusting the Projector Focus To focus the image, rotate the focus ring until the image is clear. The projector will focus at distances from 3.3 feet to 32.8 feet (1m to 10m). Zoom Ring Focus Ring... -
Page 16: User Controls
Press “Menu” to open the on-screen display (OSD) menus and to switch among different menus. To exit OSD, press the “Freeze/CLR” button or select the “ Exit Menu” icon and press “Enter” button. The projector saves any changes you made automatically. Source Press “Source”... - Page 17 When the “Zoom” icon is displayed, you can use the four directional select keys to change the vertical or horizontal positioning of the image. Keystone Adjusts image distortion caused by tilting the projector. to make adjustments for your selection. English...
-
Page 18: On-Screen Display Menus
OSD will be the “Computer OSD”. In video source, the OSD will be the “ Video OSD”. The projector will detect the source automatically. To open the OSD menu, press the “menu” button on the Remote Control or Panel Control. -
Page 19: Horizontal Position
Press the right button to move the image down. Auto-Image The projector automatically adjusts tracking, frequency and vertical and horizontal position for most computers. * The image options are available only for computer sources. The projector sets these options automatically for video sources. Audio Volume Press the left button to decrease the volume. - Page 20 When you select this function, the projector turns the image upside down for ceiling-mounted projection. Rear-Ceiling When you select this function, the projector reverses and turns the image upside down at same time. You can project from behind a translucent screen with ceiling mounted projection. 16:9 (Video mode only) You can select this function to fit your DVD aspect ratio type.
-
Page 21: Lamp Warning
Lamp Lamp Warning Choose this function to show or hide the warning message when the lamp changing warning message is displayed. Lamp Reset Reset the lamp setting only when the lamp changing is done. Exit Menu Exit Menu When you want to close the OSD menu, choose this item and select “ Yes” to exit menu. Reset All Choose “... -
Page 22: Appendices Troubleshooting
Ensure all the cables and power connections are correctly and securely connected as described in the “Installation” section. If the projector is plugged into a power strip, make sure the power strip is turned on. Ensure the pins of connectors are not crooked or broken. - Page 23 Check and reconfigure the display mode of your graphic card to make it compatible with the product. Problem: Image is out of focus Adjust the Focus Ring on the projector lens. Make sure the projection screen is between the required distance 3.3ft.(1m)~ 32.8ft. (10m) from the projector.
- Page 24 English Problem: The screen is outstretched when displaying 16:9 DVD The projector itself will automatically detect 16:9 DVD and adjust the aspect ratio by digitiza- tion to full screen with 4:3 default setting. If the projection display is still outstretched, you will also need to adjust the aspect ratio by referring to the following: Please select 4:3 aspect ratio type on your DVD player if you are playing a 16:9 DVD.
-
Page 25: Changing The Lamp
Warning: Lamp compartment is hot! Allow it to cool before changing lamps! Lamp Changing Procedure: 1. Turn off the power to the projector by pressing the Power/Standby button. 2. Allow the projector to cool down at least 30 minutes. 3. Turn off the main power switch. -
Page 26: Specifications
English Specifications Light Valve Contrast Ratio Lamp Number of Pixels Displayable Color Projection Lens Projection Screen Size Projection Distance Computer Compatibility Video Compatibility H. Frequency V. Frequency Multimedia Audio Power Supply Power Consumption I/O Connectors Weight Dimensions (W x H x D) Environmental Safety Regulation - Single Chip DLP... -
Page 27: Compatibility Modes
English Compatibility Modes V.Frequency H.Frequency Mode Resolution (Hz) (kHz) * Compressed...
