GA-8ITX3 Motherboard
F) J18 (AUX Power)
6
1
A) J16 (AUX +12V Power Connector)
+12V
GND
D) LED2 (RIMM LED)
+5VDC
+3.3VDC
+3.3VDC
GND
GND
GND
3
4
+12V
GND
1
2
The 6-pin Aux. Power connector provides
additional current to meet the board's
+3.3VDC and +5VDC requirments.
Please refer to the detail on P.24
This connector (ATX +12V) is used only
for CPU Core Voltage.
Do not remove memory modules while
RIMM LED is on. It might cause short or
other unexpected damages due to the
2.5V stand by voltage. Remove memory
modules only when STR function is
disabled by jumper and AC Power cord is
disconnected.
2 0
