Game /MIDI Ports
Joystick/ MIDI (15 pin Female)
Audio Connectors
MIC In
Line Out
Line In
USB Connector
USB 0
USB 1
This connector supports joystick, MIDI keyboard and other
relate audio devices.
After install onboard audio driver, you may connect
speaker to Line Out jack, micro phone to MIC In jack.
Device like CD-ROM , walkman etc can be connected
to Line-In jack.
Before you connect your device(s) into USB connector(s),
please make sure your device(s) such as USB keyboard,
mouse, scanner, zip,speaker..etc. Have a standard USB
interface. Also make sure your OS (Win 95 with USB
supplement, Win98, Windows 2000, Windows ME, Win
NT with SP 6) supports USB controller. If your OS does not
support USB controller, please contact OS vendor for pos-
sible patch or driver upgrade. For more information please
contact your OS or device(s) vendors.
1 7
Hardware Installation Process
