6pmm series socket 370 processor motherboard

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-6LMM
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC
LU
Eric Lu
Signature:
Date:
Feb. 20, 2001
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device ,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
harmful
interference
This
equipment
and
can
radiate
in
radio

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA-6PMM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Gigabyte GA-6PMM

  • Page 1 DECLARATION OF CONFORMITY Per FCC Part 2 Section 2. 1077(a) Responsible Party Name: G.B.T. INC. Address: 18305 Valley Blvd., Suite#A LA Puent, CA 91744 Phone/Fax No: (818) 854-9338/ (818) 854-9339 hereby declares that the product Product Name: Mother Board Model Number: GA-6LMM Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),...
  • Page 2: Declaration Of Conformity

    Safety of household and similar electrical appliances (Stamp) Declaration of Conformity We, Manufacturer/Importer (full address) G.B.T. Technology Träding GMbH declare that the product Mother Board GA-6PMM is in conformity with EN 61000-3-2* EN60555-2 EN61000-3-3* EN60555-3 EN 50081-1 EN 50082-1 EN 55081-2...
  • Page 3 6PMM Series Socket 370 Processor Motherboard USER'S MANUAL Socket 370 Processor Motherboard REV. 3.2 Third Edition R-32-03-010622 12ME-6PMM-3203...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History 2) Item Checklist 3) Features 4) Installation Guide 5) Performance & Block Diagram 6) Suspend to RAM 7) BIOS Setup 8) Technical Support /RMA Sheet 9) Appendix Manual revision information Product item list...
  • Page 7: Table Of Contents

    Revision History Item Checklist Summary of Features 6PMM Series Motherboard Layout Installation Guide Page Index for Connectors / Panel and Jumper Definition Performance List Block Diagram Suspend to RAM Installation @BIOS Introduction Easy Tune III Introduction Page Index for BIOS Setup Technical Support /RMA Sheet Appendix Table Of Content...
  • Page 8: Revision History

    6PMM Series Motherboard Revision History Revision Revision Note Initial release of the 6PMM Series motherboard user’s manual. Initial release of the 6PMM Series motherboard user’s manual. Second release of the 6PMM Series motherboard user’s manual. Third release of the 6PMM Series motherboard user’s manual.
  • Page 9: Item Checklist

    Item Checklist Item Checklist The 6PMM Series motherboard Cable for IDE / floppy device Diskettes or CD (TUCD) for motherboard driver & utility 6PMM Series user’s manual...
  • Page 10 6PMM Series Motherboard Features Summary Form Factor Motherboard Chipset Clock Generator Memory I/O Control Slots On-Board IDE On-Board Peripherals Hardware Monitor PS/2 Connector BIOS 24.3 cm x 23.4 cm Micro ATX size form factor, 4 layers PCB. 6PMM Series includes 6PMM, 6PMM-L Socket 370 processor Intel Pentium !!! 100/133MHz FSB, FC-PGA Intel CeleronTM 66MHz FSB, FC-PGA...
  • Page 11 On-Board LAN On-Board Sound On-Board VGA Additional Features Build in RTL8139C (Optional) AC’97 CODEC Line In/Line Out/Mic In/CD In/TEL/Game Port Build S3 Savage4 (86C370) in VT8605 Support shared memory architecture` Includes 3 fan power connectors. Poly fuse for keyboard over-current protection Support STR (Suspend-To-RAM) function Support Wake-On LAN (WOL) Support internal / external Modem wake up.
  • Page 12 6PMM Series Motherboard 6PMM Motherboard Layout PS/2 JP20 RTL8139C AGP 1 JP21 AC97 PCI1 PCI2 PCI3 JP16 PGA 370 VT8605 6PMM VT82C 686B COMB JP18 JP17 JP10 JP11 LED1 BAT1 USB2 BIOS...
  • Page 13: Installation Guide

    Installation Guide Getting Started WARNING! Computer motherboards and expansion cards contain very delicate Integrated Circuit (IC) chips. To protect them against damage from static electricity, you should follow some precautions whenever you work on your computer. Unplug your computer when working on the inside.
  • Page 14 6PMM Series Motherboard To set up your computer, you must complete the following steps: Step 1 - Set system jumpers Step 2- Install the Central Processing Unit (CPU) Step 3-Install memory modules Step 4-Install expansion cards Step 5-Connect ribbon cables, cabinet wires, and power supply Step 6-Set up BIOS software Step 7-Install supporting software tools Step 2...
  • Page 15: Cpu Installation

    CPU Installation Please make sure the CPU type and speed is supported by your motherboard. CPU Top View Socket Actuation Lever 1.Pull the lever out and lift it up. Installation Guide CPU Bottom View 2.The notched corner should point toward the end of the lever.
  • Page 16 6PMM Series Motherboard CPU Heat Sink Installation: Beware: Please check that the heat sink is in good contact with the CPU before you turn on your system. Poor contact will cause over heat with might cause damage to your processor! 3.Align CPU and insert it (Please refer to your heatsink installation manual for application of thermal grease to...
  • Page 17 CPU Speed Setup The system bus speed is selectable at 66,100,133MHz and Auto. The user can select the system bus speed (SW1) and change the DIP switch (SW2) selection to set up the CPU speed for 500 – 1G Hz processor. Set System Bus Speed CPU (MHz) PCI(MHz)
  • Page 18 6PMM Series Motherboard Intel Processor all have locked Frequency Multiple, so you can not change the CPU Frequency Multiple. For Auto Jumper Setting: Note: 1. If you use 66/100/133 MHz CPU, We recommend you to setup your system speed to “Auto”...
  • Page 19 Celeron 566/ 66 MHz FSB 1 2 3 4 Celeron 600/ 66 MHz FSB 1 2 3 4 Celeron 633/ 66 MHz FSB 1 2 3 4 Celeron 667/ 66 MHz FSB 1 2 3 4 Installation Guide...
  • Page 20 6PMM Series Motherboard 6. Celeron 700/ 66 MHz FSB 1 2 3 4 7. Cyrix III 550/ 100MHz FSB (Optional) 1 2 3 4 8. Cyrix III 600 / 100 MHz FSB (Optional) 1 2 3 4 Pentium !!! 500/100MHz FSB 1 2 3 4...
  • Page 21 10. Pentium !!! 550/100MHz FSB 1 2 3 4 11. Pentium !!! 600/100MHz FSB 1 2 3 4 12. Pentium !!! 650/100MHz FSB 1 2 3 4 13. Pentium !!! 700/100MHz FSB 1 2 3 4 Installation Guide...
  • Page 22 6PMM Series Motherboard 14. Pentium !!! 750/100MHz FSB 1 2 3 4 15. Pentium !!! 800/100MHz FSB 1 2 3 4 16. Pentium !!! 850/100MHz FSB 1 2 3 4 17. Pentium !!! 533/133MHz FSB 1 2 3 4...
  • Page 23 18. Pentium !!! 600/133 MHz FSB 1 2 3 4 19. Pentium !!! 667/133MHz FSB 1 2 3 4 20. Pentium !!! 733/133MHz FSB 1 2 3 4 21. Pentium !!! 800/133MHz FSB 1 2 3 4 Installation Guide...
  • Page 24 6PMM Series Motherboard 22. Pentium !!! 866/133MHz FSB 1 2 3 4 23. Pentium !!! 933/133MHz FSB 1 2 3 4 24. Pentium !!! 1G Hz /133MHz FSB 1 2 3 4...
  • Page 25: Memory Installation

    Memory Installation The motherboard has 2 dual inline memory module (DIMM) sockets support 4 banks. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 26 6PMM Series Motherboard Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition CPU Speed Setup Connectors Game & Audio Port COM A / COMB / VGA / LPT Port USB 1 & LAN Connector PS/2 Keyboard & PS/2 Mouse Connector USB 2 Front USB Connector JP1 (CPU Fan Connector) JP3 (Power Fan Connector)
  • Page 27: Connectors

    Connectors Game & Audio Port Please note: This motherboard supports standard audio port and game port. After install onboard audio driver. you may connector speaker to line out jack, micro phone to MIC in jack Device like CD-ROM , walkman etc can be connected to line-in jack COM A / COM B / VGA / LPT Port Please note: This mainboard supports 1 standard COM port, 1 VGA port and 1 LPT port.
  • Page 28: Ps/2 Keyboard & Ps/2 Mouse Connector

    6PMM Series Motherboard USB1 & LAN : USB1 Connector & LAN Connector (LAN Connector is Optional) Please note: Before you connect your device(s) into USB connector(s), please make sure your device(s) such as USB keyboard, mouse, scanner, zip, speaker..etc. have a standard USB interface. Also make sure your OS (Win 95 w/ USB supperment, Win98, Windows 2000, Windows ME, Win NT w/ SP 6) supports USB controller.
  • Page 29: Usb 2 Front Usb Connector

    USB 2 Front USB Connector Please note: Be careful with the polarity of the front panel USB connector. Check the pin assignment while you connect the front panel USB cable. Please contact your nearest dealer for optional front panel USB cable. JP1: CPU Fan Please note , a proper installation of the CPU cooler is essential to prevent the CPU from running under abnormal condition or damaged by...
  • Page 30 6PMM Series Motherboard JP3: Power Fan JP4: Sysem Fan Pin No. Definition Control +12V Pin No. Definition Control +12V SENSE...
  • Page 31: Atx Power

    ATX Power Please note: AC power cord should only be connected to your power supply unit after ATX power cable and other related devices are firmly connected to the mainboard. Floppy Port Pin No. 3,5,7,13,15-17 1,2,11 4,6,19,20 5V SB (Stand by+5V) PS-ON (Soft On/Off) Red Line Connectors...
  • Page 32: Ide1(Primary), Ide2(Secondary) Port

    6PMM Series Motherboard IDE1(Primary), IDE2(Secondary) Port J7 : TEL: The connector is for Modem with internal voice connector IDE 1 IDE 2 Red Line Pin No. Definition Signal-In Signal-Out...
  • Page 33: J8:Cd Audio Line In

    J8:CD Audio Line In J2:IR Please note: Be careful with the polarity of the IR connector while you connect the IR. Please contact you nearest dealer for optional IR device Pin No. Definition CD-L CD-R Pin No. Definition VCC (+5V) IR Data Input IR Data Output Connectors...
  • Page 34: J4 (Modem Ring On)

    6PMM Series Motherboard J4: Internal Modem Card Wake Up J5: Wake On LAN Pin No. Definition Signal Pin No. Definition +5V SB Signal...
  • Page 35: Jp20: Front Audio

    JP12 : STR LED Connector & DIMM LED Please note: Do not remove memory modules while DIMM LED is on. It might cause short or other unexpected damages due to the 3.3V stand by voltage. Remove memory modules only when STR function is disabled by jumper and AC Power cord is disconnected.
  • Page 36: Page Index For Connectors / Panel And Jumper Definition

    6PMM Series Motherboard Panel and Jumper Definition J3 : 2x11 Pins Jumper GN (Green Switch) GD (Green LED) HD (IDE Hard Disk Active LED) SPK (Speaker Connector) RE (Reset Switch) P+P P (Power LED) PW (Soft Power Connector) S P K P P P+ Open: Normal Operation Close: Entering Green Mode...
  • Page 37: Jp5 (Clear Cmos Function)

    JP5 : Clear CMOS Function Please note , You may clear the CMOS data to its default values by this jumper JP6 : Case Open Panel and Jumper Definition Clear CMOS Normal (Default) Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default) Pin No.
  • Page 38: Jp7 :Usb Device Wake Up Selection

    6PMM Series Motherboard JP7 :USB Device Wake up Selection Please note , To use “USB Device Wakeup” function, set BIOS setting “USB Dev Wake up from S3” to ENABLED and enable jumpers JP7&JP11. To prevent user confusion. *(Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup.
  • Page 39: Jp11: Str Function Selection

    JP11: STR Function Selection JP10 : Over Voltage CPU Speed Up (Magic Booster) (When JP10 set “Pin1-2” close , CPU Voltage is rising 10%) Panel and Jumper Definition Disabled Enabled (Default) Pin No. Definition 1-2 close STR Enabled 2-3 close STR Disabled (Default) Over CPU Normal Voltage...
  • Page 40: Jp9 (Onboard Lan Function)

    6PMM Series Motherboard JP9: Onboard LAN Function (Optional) Please note, This MB supports optional LAN chip. If the MB has optional LAN chip the user can enable the LAN function by setting the JP9 to 1-2, user can disable the optional LAN function by setting the JP9 to 2-3.
  • Page 41: Bat1(Battery)

    JP16/JP17/JP18 : Onboard AC97& AMR (Primary or Secondary ) Select (Optional) (AMR Please note, This MB supports AMR slot, you can look up the table above to choose the appropriate AMR card for your board. BAT1 : Battery Panel and Jumper Definition Audio Modem Riser) JP16 Jumper...
  • Page 42: Performance List

    6PMM Series Motherboard Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Intel Coppermine 1G Hz , Intel Coppermine 850MHz Intel Celeron 700MHz , VIA Cyrix III 600MHz...
  • Page 43: Block Diagram

    Block Diagram AGP 4X On Chip PCI Bus 33MHz AC-Link AC97 CODEC 3 PCI PCI (33MHz) PCI (33MHz) 48MHz 14.318MHz 33MHz CPUCLK (66/100/133MHz) Socket 370 System Bus 66/100/133MHz 66/100/133MHz VT8605 33MHz 14.318MHz 48MHz VT82C686B Ports Floppy PS/2 LPT Port 9248-39 Block Diagram 3.3V SDRAM DIMM HCLK (66/100/133MHz)
  • Page 44: Suspend To Ram Installation

    6PMM Series Motherboard Suspend To RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 45 Step 2: (If you want to use STR Function, please set jumper JP11 Pin 1-2 Closed.) Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup. Select the item “POWER MANAGEMENT SETUP”, then select “ Type : S3 / STR”...
  • Page 46 6PMM Series Motherboard A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” Choose the “Stand by”...
  • Page 47 Suspend To RAM Installation Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 48 6PMM Series Motherboard C. Select the “Advanced” tab and “Standby” mode in Power Buttons. D. Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button. A.4 How to recover from the STR sleep mode? There are five ways to “wake up”...
  • Page 49 A.5 Notices : In order for STR to function properly, several hardware and software requirements must be satisfied: Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). Your SDRAM must be PC-100 compliant. Jumper JP12 is provided to connect to the STR LED in your system chassis.
  • Page 50: Bios Introduction

    BIOS, just choose “Save Current BIOS” to save it first. You make a wise choice to use Gigabyte, and @BIOS update your BIOS smartly. You are now worry free from updating wrong BIOS, and capable to maintain and manage your BIOS easily.
  • Page 51: Easy Tune Iii Introduction

    “Advanced Mode” to enjoy “sport drive” class overclocking. In “Advanced Mode”, one can change the system bus speed in small increments to get ultimate system performance. And no matter which mainboard is used, if it’s a Gigabyte’s product*, EasyTuneIII helps to perform the best of system.
  • Page 52 6PMM Series Motherboard This wonderful software is now free bundled in Gigabyte motherboard attached driver CD. Users may make a test drive of “EasyTuneIII” to find out more amazing features by themselves. For further technical information, please link to: Note: If your TUCD version is 1.6 or below, please visit our website and download the latest EasyTune III TM version.
  • Page 53: Page Index For Bios Setup

    Page Index for BIOS Setup The Main Menu Standard CMOS Setup BIOS Features Setup Chipset Features Setup Power Management Setup PNP/ PCI Configuration Load BIOS Defaults Load Setup Defaults Integrated Peripherals Hardware Monitor Setup Supervisor Password / User Password IDE HDD Auto Detection Save &...
  • Page 54: Entering Setup

    6PMM Series Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Interface. The interface allows users to modify the basic system configuration, which is stored in battery-backed CMOS RAM so that it retains the Setup information can be retained when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 55: Getting Help

    GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 56 6PMM Series Motherboard Power Management Setup This setup page includes all the adjustable items of Green function features. PnP/PCI Configurations This setup page includes all the adjustable configurations of PCI & PnP ISA resources. Load BIOS Defaults Load BIOS Defaults option loads preset system parameter values to set the system in its most stable configurations.
  • Page 57: Standard Cmos Setup

    Standard CMOS Setup The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes none, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value in each item. AMIBIOS SETUP –...
  • Page 58 6PMM Series Motherboard IDE Primary Master / Slave , Secondary Master / Slave The category identifies the type of hard disk from drive C to F that has been installed in the computer. There are two settings: Auto, and Manual. Manual: HDD type is user-definable; Auto will automatically detect HDD type.
  • Page 59: Extended Memory

    Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
  • Page 60: Bios Features Setup

    6PMM Series Motherboard BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Processor Serial Number First Boot Device Second Boot Device Third Boot Device Floppy Drive Seek Boot Up Num-Lock Password Check HDD S.M.A.R.T Capability Processor Serial Number...
  • Page 61: Password Check

    Floppy Drive Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360 type is 40 tracks while 720 , 1.2 and 1.44 are all 80 tracks. Enabled BIOS searches for floppy disk drive to determine if it is 40 or 80 tracks. Note that BIOS can’t differentiate between 720, 1.2 or 1.44 drive type as they are all 80 tracks.
  • Page 62: Chipset Features Setup

    6PMM Series Motherboard Chipset Features Setup We would not suggest you change the chipset default setting unless you really need it. AMIBIOS SETUP –CHIPSET FEATURE SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved *** DRAM Timing *** DRAM Frequency SDRAM CAS# Latency AGP Mode...
  • Page 63 AGP Fast Write Disable AGP Fast Write (Default Value) Disabled Enabled Enable AGP Fast Write AGP Comp. Driving Detect AGP Comp. Driving automatically. (Default Value) Auto Manual Set AGP Comp. Driving is Manual. If AGP Comp. Driving is Manual. Manual AGP Comp. Driving : AGP Aperture Size Set AGP Aperture Size to 4MB.
  • Page 64 6PMM Series Motherboard Delay DRAM Read Latch 1.0ns Set DRAM Read Latch Delay to 1.0ns. 1.5ns Set DRAM Read Latch Delay to 1.5ns. 0.5ns Set DRAM Read Latch Delay to 0.5ns. Set DRAM Read Latch to No delay. (Default Value) No delay Memory Data Drive Set Memory Data Drive to 6 mA.
  • Page 65 Power Management Setup AMIBIOS SETUP –POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Sleep Type USB Dev Wakeup From S3-S5 Suspend Time Out(Minute) Soft-off by Power Button System after AC Back Modem Use IRQ ModemRingOn/WakeOnLan PME Event Wake up Resume by RTC Alarm...
  • Page 66 6PMM Series Motherboard Suspend Time Out (Minute.) Disable Suspend Time Out Function. (Default Value) Disabled Set Suspend Time Out after 1min. Set Suspend Time Out after 2min. Set Suspend Time Out after 4min. Set Suspend Time Out after 8min. Set Suspend Time Out after 10min. Set Suspend Time Out after 20min.
  • Page 67 PME Event Wake up Disabled Disable PME event wake up function. Enable PME event wake up function. (Default Value) Enabled Resume by RTC Alarm You can set “Resume by RTC Alarm ” item to enabled and key in Data/time to power on system.
  • Page 68: Reset Configuration Data

    6PMM Series Motherboard PnP/PCI Configurations AMIBIOS SETUP –PNP/PCI CONFIGURATION SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Reset Configuration Data VGA Boot From AGP Frame Buffer Size IRQ3 IRQ4 IRQ5 IRQ7 IRQ9 IRQ10 IRQ11 IRQ14 IRQ15 Reset Configuration Data To advise BIOS clear PnP configuration data for usable value.
  • Page 69: Power Management Setup

    Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item F6 : Load BIOS Defaults Load BIOS Default except Standard CMOS Setup...
  • Page 70: Load Setup Defaults

    6PMM Series Motherboard Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP Load SETUP Defaults (Y/N)? N PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit...
  • Page 71: Integrated Peripherals

    Integrated Peripherals AMIBIOS SETUP –INTEGRATED PERIPHERAL ( C ) 1999 American Megatrends, Inc. All Rights Reserved OnBoard IDE OnBoard FDC OnBoard Serial Port 1 OnBoard Serial Port 2 Serial Port 2 Mode Duplex Mode OnBoard Parallel Port Parallel Port Mode Parallel Port DMA Parallel Port IRQ USB Controller...
  • Page 72 6PMM Series Motherboard OnBoard Serial Port 2 BIOS will automatically setup the port 2 address. (Default Value) . Auto 3F8/COM1 Enable onboard Serial port 2 and address is 3F8. 2F8/COM2 Enable onboard Serial port 2 and address is 2F8. 3E8/COM3 Enable onboard Serial port 2 and address is 3E8.
  • Page 73 USB Controller USB Port 0&1 USB Controller for USB Port 0&1. USB Port 2&3 USB Controller for USB Port 2&3. USB Controller for All USB Port. (Default Value) All USB Port Disabled USB Controller Function Disabled. USB Legacy Support Keyboard/FDD Set USB Legacy Support Keyboard and Floppy Disk.
  • Page 74 6PMM Series Motherboard SB IRQ Select IRQ 5 / 7 / 9 / 10. (Default Value: 5 ) SB DMA Select DMA 0 / 1 / 2/ 3. (Default Value: 1 ) MPU-401 Enabled Enabled MPU-401. Disabled MPU-401. (Default Value) Disabled MUP-401 I/O Address Set MUP-401 I/O Address to 330h-333h.
  • Page 75 Hardware Monitor AMIBIOS SETUP –HARDWARE MONITOR SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved - = Hardware Monitor =- Case Status Current CPU Temp. Current System Temp. Current CPU Fan Speed Current System Fan Speed Vcore +3.300V +5.000V +12.000V Case Status...
  • Page 76: Hardware Monitor Setup

    6PMM Series Motherboard Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP...
  • Page 77: Ide Hdd Auto Detection

    IDE HDD AUTO Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Tue Jan 25, 2000 Time (hh/mm/ss) : 10:36:24 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Pri Master : Not Installed Pri Slave : Not Installed Sec Master : Not Installed...
  • Page 78: Save & Exit Setup

    6PMM Series Motherboard Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION SAVE to CMOS and EXIT(Y/N)? Y LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit...
  • Page 79: Exit Without Saving

    Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.23 ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item F6 : Load BIOS Defaults Type "Y"...
  • Page 80: Technical Support /Rma Sheet

    6PMM Series Motherboard Technical Support /RMA Sheet Customer/Country: Company: Contact Person: Model name/Lot Number: BIOS version: Hardware Mfs. Model name Size: Configuration Memory Brand Video Card Audio Card CD-ROM / DVD-ROM Modem Network AMR / CNR Keyboard Mouse Power supply Other Device Problem Description: Phone No.:...
  • Page 81: Appendix

    Appendix Appendix A : VIA Chipsets Driver Installation A.VIA 4 in 1 Service Pack Utility: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “VIA 4in 1 Service Pack Utility”...
  • Page 82 6PMM Series Motherboard 6.Click “Next”. 8.Click “Next”. 9.Click “Finish” to restart computer. 7.Click “Next”. (10)
  • Page 83 B.AC’97 Audio Driver: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Press “Audio” icon. 1.Click “VIA AC’97 Audio Driver” item. 3.Click “Next”.
  • Page 84 6PMM Series Motherboard C. LAN Driver: (Optional) Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “Next” item. 3.You can select “Specify a location: D:\Network\Rtl8139c\Win98 then Click “Next”...
  • Page 85 D. VGA Driver: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “Advanced” item. 3.Click “Next” 5.You can select “Specify a location: D:\Chipset\Via\Vt8605\Win9x then Click “Next”...
  • Page 86 6PMM Series Motherboard 7.Click “Finish” to restart computer.
  • Page 87 Appendix B: BIOS Flash Procedure BIOS update procedure: If your OS is Win9X, we recommend that you used Gigabyte @BIOS Program to flash BIOS. Click “Tool” . Click “ ” . Methods and steps : I. Update BIOS through Internet a.
  • Page 88 In method I, if the BIOS file you need cannot be found in @BIOS server, please go onto Gigabyte's web site for downloading and updating it according to method II. d. Please note that any intercorruption during updating will cause system unbooted...
  • Page 89 Format a bootable system floppy diskette by the command “ format a:/s ” in command mode. Visit the Gigabyte website at http:// need and download it to your bootable floppy diskette. Insert the bootable diskette containing the BIOS file into the floppy diskette driver.
  • Page 90 6PMM Series Motherboard Appendix C: Issues To Beware Of When Installing AMR Please use inverse AMR card like the one in order to avoid mechanical problem. (See Figure A) PCI Slot Figure A: Inverse AMR Card (Default) PCI Slot Figure B: Non inverse AMR Card...
  • Page 91 Appendix D: Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface Advanced Power Management Accelerated Graphics Port Audio Modem Riser Advanced Communication Riser BIOS Basic Input / Output System Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser Direct Memory Access Desktop Management Interface...
  • Page 92 6PMM Series Motherboard Acronyms Meaning Original Equipment Manufacturer PCI A.G.P. Controller POST Power-On Self Test Peripheral Component Interconnect RIMM Rambus in-line Memory Module Special Circumstance Instructions SECC Single Edge Contact Cartridge SRAM Static Random Access Memory Symmetric Multi-Processing System Management Interrupt Universal Serial Bus Voltage ID...

This manual is also suitable for:
