SNOWJOE SUNJOE SPX6000C-CT Operator's Manual page 8

Fig. 3
Trigger
gun holder
4. Align the water inlet on the base unit with the outlet on
the bottom of the bucket, and seat the bucket on the
base unit. Check alignment to ensure a proper seal and
connection (Fig. 4).
Fig. 4
Water inlet
Bucket outlet
5. Flip up the buckles on the base unit and latch to bucket.
Press down on the buckle ends to lock the bucket to the
base unit (Fig. 5).
Fig. 5
m
WARNING!
unit, do not lift the pressure washer by the handle. Instead, use
the tow handle to pull the pressure washer unit along on its
wheels (Fig. 6).
Fig. 6
Bucket
6. Take the spray wand and align the two tabs with your
trigger gun. Once aligned, push the spray wand firmly into
the trigger gun, twist counter-clockwise to lock into place
Base unit
(Fig. 7).
Fig. 7
Trigger gun
8
1. Flip up
Bucket buckle
2. Press the end
When the water bucket is fixed on the base
Spray wand
