Know Your Cordless Pressure Washer
Read the owner's manual and safety instructions carefully before operating the cordless pressure washer. Compare the
illustration below to the cordless pressure washer in order to familiarize yourself with the location of the various controls and
adjustments. Save this manual for future reference.
1
1
2 3
4
5
6
7
31
32
33
34
1. Trigger gun
2. Safety lock
3. Trigger
4. High-pressure hose
5. Trigger gun holder
6. Spray wand
7. Base unit
8. Quick-connect collar
9. Fixed wheel (2)
10. Battery compartment cover
11. On/Off switch
12. Control panel
13. Pressure select buttons (2)
14. Bucket handle
Technical Data
Battery Voltage*
Motor
Max. Water Inlet Temperature
Bucket Capacity
Max. Water Inlet Pressure
Max. Rated Flow
For battery options and specifications, see Optional Accessories for details.
*Initial no-load voltage, when fully charged, peaks at 40 volts; nominal voltage under typical load is 36 volts.
FRONT
16
15
14
13
8
12
9
10
11
30
29
15. Tow handle
16. Bucket lid
17. High-pressure hose connection
18. Water bucket
19. All-direction wheel (2)
20. Bucket buckle (2)
21. Water outlet
22. Water outlet connection
23. Garden hose adapter
24. Needle clean-out tool
25. 40º Quick-Connect nozzle (gray)
26. 25º Quick-Connect nozzle (green)
27. 15º Quick-Connect nozzle (yellow)
28. 0º Quick-Connect nozzle (orange)
40 V D.C.
Brushless
104ºF/40ºC
5.3 gal (20 l)
0.7 MPa
0.79 GPM
6
BACK
20
21
22
23
24
28 27 26 25
29. Soap dispenser attachment
30. Push lock button
31. Battery indicator
32. Push button for battery indicator
33. 40 V 4.0 Ah EcoSharp
iBAT40), 40 V 5.0 Ah EcoSharp
PRO (model iBAT40XR) or 40 V
6.0 Ah EcoSharp
iBAT40XRP) lithium-ion battery –
Sold separately
34. 40 V EcoSharp
(model iCHRG40) or 40 V EcoSharp
dual-port battery charger (model
iCHRG40-DPC) – Sold separately
Max. Flow
Max. Rated Pressure
Max. Pressure
High Pressure Hose Length
Weight (unit alone)
Weight (unit + battery)
17
18
19
(model
®
®
PRO (model
®
battery charger
®
®
1 GPM
800 PSI
1160 PSI
20.3 ft (6.2 m)
17 lbs (7.7 kg)
19.1 lbs (8.7 kg)
