Select a suitable mounting location and verify there is sufficient cable to reach the mid-
dle of the Wall Mount.
1. Mark and drill mounting holes in the surface using the Wall Mount Flange.
2. Pull out cables required to connect to the dome camera from the wall.
3. Set and fix wall mount bracket using plastic anchors and M8x35 screws.
4. Open the access plate and pull out cables through rectangular access hole of the
wall mount bracket.
5. Attach the 1.5 inch adapter to wall mount bracket and fix it using set screw.
6. Attach the camera's safety wire to the wall mount bracket and organize cables.
7. Close the access plate of the wall mount bracket
8. Push in and turn clockwise the camera into the adapter, and fix it using set screw
of the adapter.

Installation - Ceiling Mount

The ceiling mounting plate must be attached to a structural object such as concrete that
will support the weight of the mount and Dome Camera.
Plastic Anchor (4x)
Tapping Screw 8x35 (4x)
Mounting Bracket (1x)
Set Screw (1x)
Adapter
Set Screw (1x)
Safety Wire
Access Plate
Srew Machine 3x5 (2x)
