HD Turret and Bullet
Camera
User Manual
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I Camera
Type II Camera
Type III Camera
Type IV Camera
Type V Camera
Type VI Camera
This manual may contain several technical incorrect
places or printing errors, and the content is subject to
change without notice. The updates will be added to
the new version of this manual. We will readily improve
or update the products or procedures described in the
manual.
Model
HWT-T120-P/HWT-T120
HWT-T140-P/HWT-T140
HWT-T220-P
HWT-T240-P
HWT-T120-M
HWT-T140-M
HWT-T220-M
HWT-T240-M
HWT-B220-M/HWT-B220
HWT-B240-M/HWT-B240
HWT-B120-P/HWT-B120-M
HWT-B140-P/HWT-B140-M
0100001080706
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HIKVISION HWT-T120-P
Summary of Contents for HIKVISION HWT-T120-P
- Page 1 Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model HWT-T120-P/HWT-T120 Type I Camera HWT-T140-P/HWT-T140 HWT-T220-P Type II Camera HWT-T240-P HWT-T120-M...
-
Page 2: Regulatory Information
Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
-
Page 4: Product Features
To avoid heat accumulation, good ventilation is required for the operating environment. Keep the camera away from liquid while in use for non-water-proof device. While in delivery, the camera shall be packed in its original packing, or packing of the same texture. Mark Description Table 0-1 Mark Description Mark... - Page 5 Note: Press and hold the switch button for 5 seconds to switch the video output. Four kinds of video outputs are available: TVI, AHD, CVI, and CVBS. 1.2.3 Overview of Type III Camera Clip Plate Mounting Base Trim Ring Enclosure Main Body Switch Button Power Cord...
-
Page 6: Installation
1.2.6 Overview of Type VI Camera Switch Button Mounting Base Power Cord DC12V 12 VDC Video Cable Main Body Lens Figure 1-6 Overview of Type VI Camera Note: Press and hold the switch button for 5 seconds to switch the video output. Four kinds of video outputs are available: TVI, AHD, CVI, and CVBS. - Page 7 4. Drill the screw holes, and the cable hole (optional) on the ceiling according to the drill template. Cable Screw Hole Hole Side Opening Figure 2-2 Drill Template Note: Drill the cable hole, when adopting the ceiling outlet to route the cable 5.
- Page 8 Pan Position [0° to 360°] Rotation Position Tilt Position [0°to 360°] [0°to 75°] Figure 2-5 3-axis Adjustment 1). Hold the camera body and rotate the enclosure to adjust the pan position [0° to 360°]. 2). Move the camera body up and down to adjust the tilt position [0°...
- Page 9 Figure 2-8 Attach the Mounting Base to the Ceiling Note: The supplied screw package contains self-tapping screws, and expansion bolts. For cement ceiling, expansion bolts are required to fix the camera. For wooden ceiling, self-tapping screws are required. 5.
- Page 10 Before you start: Both wall mounting and ceiling mounting are suitable for the camera. We take ceiling mounting as an example in this section. You can take the steps of ceiling mounting as a reference, when adopting wall mounting. Steps: 1.
- Page 11 Figure 2-14 Put the Trim Ring Back and Tighten It 6. Connect the corresponding cables, such as power cord, and video cable. 7. Power on the camera to check whether the image on the monitor is gotten from the optimum angle. If not, adjust the camera according to the figure below to get an optimum angle.
-
Page 12: Menu Description
Note: Drill the cable hole, when adopting the ceiling outlet to route the cable. 3. Attach the bracket to the ceiling and secure the camera with supplied screws. Figure 2-17 Fix the Camera to the Ceiling Note: The supplied screw package contains ... - Page 13 Figure 3-1 Connection 2. Power on the analog camera, TVI DVR, and the monitor to view the image on the monitor. 3. Click PTZ Control to enter the PTZ Control interface. 4. Call the camera menu by clicking button, or click Iris+.
- Page 14 3.2 EXPOSURE Exposure describes the brightness-related parameters, which you can set the EXPOSURE MODE as GLOBAL, BLC, or DWDR. GLOBAL GLOBAL refers to the normal exposure mode which performs exposure according to the whole image brightness. BLC (Backlight Compensation) ...
-
Page 15: Video Settings
Figure 3-4 AUTO IR LIGHT You can turn on/off the IR LIGHT to meet the requirements of different circumstances. SMART IR The SMART IR function is used to adjust the light to its most suitable intensity, and prevent the image from over exposure. -
Page 16: Factory Default
SHARPNESS Sharpness determines the amount of detail an imaging system can reproduce. You can set the SHARPNESS value from 1 to 9. SATURATION Adjust this feature to change the saturation of the color. The value ranges from 1 to 9. DNR (Digital Noise Reduction) The DNR function can decrease the noise effect, especially when capturing moving images in poor light...
