Page 1: Table Of Contents
2022/07/07 14:23 manual_egk-lw20w00 Table of Contents EGK-LW20W00 Operating Manual ....................1. Description ..........................2. Overview ............................ 2.1 Technical data ......................... 2.2 Installation ..........................2.3 Power ON/OFF ......................... 2.4 System leds ........................... 2.5 Battery ..........................2.6 Firmware update ........................3. Measures .......................... - Page 2 Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 https://www.enginko.com/support/ Printed on 2022/07/07 14:23...
-
Page 3: Egk-Lw20W00 Operating Manual
2022/07/07 14:23 1/31 manual_egk-lw20w00 EGK-LW20W00 Operating Manual Important safety information Read this manual before attempting to install the device! Failure to observe recommendations included in this manual may be dangerous or cause a violation of the law. The manufacturer will not be held responsible for any loss or damage resulting from not following the instructions of this operating manual. -
Page 4: Technical Data
Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 2.1 Technical data CPU ARM Cortex M4 Class A LoRaWAN® 1.0.2 , EU868 OTAA/ABP activation Level range 140 ÷ 1500mm, resolution 1mm, accuracy TBD Field of View: ±15° Non contact level detection up to 1.5mt Internal temperature measurement (+/- 1°C typ, +/- 2°C max). - Page 5 2022/07/07 14:23 3/31 manual_egk-lw20w00 Alternatively, the sensor can be mounted to overfill detection on the side of the lid: In this case, level parameters need to be modified. Custom brackets available on request. 2.2.1 Bin lid or side mount For mounting onto the lid or side of the bin, use the provided screws and spacers: e n g i n k o .
- Page 6 Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 2.2.1.1 Lid mount examples https://www.enginko.com/support/ Printed on 2022/07/07 14:23...
- Page 7 2022/07/07 14:23 5/31 manual_egk-lw20w00 2.2.2 Wall mount For mounting onto wall, use the optional wall mount bracket EGK-RAWALL: e n g i n k o . s u p p o r t . c e n t e r - https://www.enginko.com/support/...
- Page 8 Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 https://www.enginko.com/support/ Printed on 2022/07/07 14:23...
- Page 9 2022/07/07 14:23 7/31 manual_egk-lw20w00 2.2.3 Pole mount For installation on poles, pillars or posts use the included bracket and fasteners: 2.2.4 LoRa Tool To deploy the sensor, download the latest LoRa Tool Android App to setup LoRaWAN® credentials and other preferences :...
- Page 10 Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 2.2.5 Connection Enable the Bluetooth on the smartphobne and open the App: once the sensors list appears (as BLE MAC address), select the sensor you need to configure: and read it: https://www.enginko.com/support/ Printed on 2022/07/07 14:23...
-
Page 11: Power On/Off
2022/07/07 14:23 9/31 manual_egk-lw20w00 2.3 Power ON/OFF The sensor is shipped completely off to prevent battery consumption during storage. It is therefore necessary to carry out a first power-on prior to commissioning. To power on the sensor: lay the magnet at the bottom of the provided tool into the area shown in the figure:... - Page 12 Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 Successful power on is signaled by the flashing of the 3 LEDs. In case of long period of inactivity, if necessary, is possible to shut-off again the sensor to prevent battery consumption, via downlink or with LoRa Tool App: https://www.enginko.com/support/...
-
Page 13: System Leds
2022/07/07 14:23 11/31 manual_egk-lw20w00 2.4 System leds LoRaWAN® not configured Slow flashing Joining Quick flashing Sending Quick flashing 2.5 Battery This sensor contains lithium battery, which must be disposed of separately. EGK-LW20W00 is provided with a battery pack: Code... - Page 14 Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 remve the PCB batteries pack from the main board (PCB board is secured with two small screws): https://www.enginko.com/support/ Printed on 2022/07/07 14:23...
- Page 15 2022/07/07 14:23 13/31 manual_egk-lw20w00 Place the new PCB batteries pack and put them in place with the screws: e n g i n k o . s u p p o r t . c e n t e r - https://www.enginko.com/support/...
- Page 16 Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 Place the front panel and fix it with the 4 screws. After the batteries replacement, internal counters need to be resetted. To perform the operation, you need a unique reset code that must be requested to enginko (please provide the DevEUI of the sensor when you ask for that code): https://www.enginko.com/support/...
-
Page 17: Firmware Update
2022/07/07 14:23 15/31 manual_egk-lw20w00 At the end of the procedure the battery level displays 100%. 2.6 Firmware update Download the latest firmwares available on the smartphone: e n g i n k o . s u p p o r t . c e n t e r - https://www.enginko.com/support/... -
Page 18: Measures
Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 Upload it with LoraTool App: 3. Measures On each reading of the sensor by LoraTool, the measured distance is shown on the main page: https://www.enginko.com/support/ Printed on 2022/07/07 14:23... -
Page 19: Level Settings
2022/07/07 14:23 17/31 manual_egk-lw20w00 The temperature value is measured inside the sensor. Once provisioned on a LoRaWAN® network, the device sends the distance, temperature, filling level & timestamp to the server via uplink. 3.1 Level settings Level measurements are carried out according to few parameter settings. A target over the defined range cannot be detected. - Page 20 Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 3.1.1 Start [mm] Starting point of the measurement (in mm from “REFERENCE” point). Values can be set from 140 to 1360: https://www.enginko.com/support/ Printed on 2022/07/07 14:23...
- Page 21 2022/07/07 14:23 19/31 manual_egk-lw20w00 Default: 140 A target within the “Start [mm]” distance will result at a “Start” distance. The “Start [mm]” value is also related to other level parameters. Contact enginko in case of assistance. 3.1.2 Lenght [mm] Range of measure (in mm, from “Start”...
- Page 22 Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 Default: 1360 3.1.3 Signal threshold Minimum target detection threshold. Values can be set from 1 to 20000: https://www.enginko.com/support/ Printed on 2022/07/07 14:23...
- Page 23 2022/07/07 14:23 21/31 manual_egk-lw20w00 Default: 200 3.1.4 Power Power setting for target detection. Values can be set from 1 to 5: e n g i n k o . s u p p o r t . c e n t e r - https://www.enginko.com/support/...
-
Page 24: Lorawan Network
Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 Default: 3 4 LoRaWAN network The sensor is compliant with LoRaWAN® specification 1.0.2. https://www.enginko.com/support/ Printed on 2022/07/07 14:23... -
Page 25: Activation
2022/07/07 14:23 23/31 manual_egk-lw20w00 4.1 Activation The device supports the following activations on a LoRaWAN® network: NONE: sensor not activated OTAA: the JoinEUI and the AppKey not setted, must be written to the device; OTAA MCF88: Over the air activation, fixed keys: JoinEUI = 904e915000000001, AppKey on request;... -
Page 26: Other Settings
Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 The device exits factory activated with NONE mode. On request devices can be shipped aleady activated. Note: in OTAA AppKey is write only, in reading the field will always be empty, even if set. - Page 27 2022/07/07 14:23 25/31 manual_egk-lw20w00 DST: set to change DST (default: none). No time sync: set to disable time synchronization request (default: enabled). UnConfirmed: set for unconfirmed uplinks (default: confirmed uplink). Led OFF: set to disable the led. Single join/day: set for to allow only one join per day (default: multiple join allowed).
-
Page 28: Passwords
Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 5 Passwords The device can be protected by passwords, to avoid unauthorized persons to read data or modify parameters. As default passwords are equal to 0. Allowed values range from 0 to 999999999 (only numbers). - Page 29 2022/07/07 14:23 27/31 manual_egk-lw20w00 Once the passwords are setted, to gain access from LoRa Tool to the sensor, open the App: and set the right values before reading from the device: e n g i n k o . s u p p o r t . c e n t e r - https://www.enginko.com/support/...
-
Page 30: Configuration File
Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 To bring back the sensor to factory default and reset the passwords, a reset code must be requested to enginko (please provide the DevEUI of the sensor when you ask for that code). -
Page 31: Multi Devices Configuration
2022/07/07 14:23 29/31 manual_egk-lw20w00 6.1 Multi devices configuration WIth LoRa Tool App is possible to configure many devices in an easy way. For multi-configuration is needed at least one XML file with the parameters to set. Settings on this file will be applied to all the sensors. -
Page 32: Loraweb Tool
Last update: 2022/05/17 15:44 manual_egk-lw20w00 https://www.enginko.com/support/doku.php?id=manual_egk-lw20w00 For details on files format please ask to enginko. 7 LoRaWEB Tool enginko provides, upon free registration, LoRaWEB online tool, where for each sensor it is possible to find documentation, javascript examples for parsing, downlink generator and uplink decoder: LoRaWEB Tool (iot.mcf88.cloud/LoRaWeb) -
Page 33: Payload
2022/07/07 14:23 31/31 manual_egk-lw20w00 8 Payload For payload descriptions, uplinks and downlinks format and available commands please refer to this document: DATA FRAME FORMAT 9 Ordering code Ordering Code Description EGK-LW20W00 LoRaWAN® waste level sensor EGK-RAWALL Wall mount bracket...
