GLM.SE DSP System SE7261A Subwoofer and 8130A Digital Input Monitor
Drivers
Bass
Treble
All drivers are magnetically shielded
Free field frequency response of system
Maximum peak SPL output per pair
on top of console @ 1 m with music material
Maximum short term sine wave SPL output @ 1 m
on axis in half space, averaged as specified
Crossover frequency
Self generated noise level in free
field @ 1 m on axis (A-weighted)
Harmonic distortion at 85 dB SPL @ 1 m on axis
Freq: 50...100 Hz
> 100 Hz
Harmonic distortion at given dB SPL @ 1 m in
half space
2nd
3rd
Input signal
Analog
AES/EBU (single wire)
Output / Thru signal
AES/EBU (single wire)
Digital audio
Word length
Sample rate
Control network
Type
Connection
GLM TM software frequency response adjustment *
Notch filters
System calibration *
Bass amplifier output power
Treble amplifier output power
(Long term output power is limited by driver
protection circuitry)
Power consumption
Idle
Full output
Dimensions
Height
Width
Depth
Height with Iso-Pod™
Weight
8130A SE7261A
130 mm (5") 254 mm (10")
19 mm (3/4") metal dome n/a
58 Hz - 20 kHz (± 2 dB) 19 Hz - 100 Hz (± 3 dB)
≥ 108 dB SPL n/a
(from 100 Hz to 3 kHz) (from 30 Hz to 85 Hz)
≥ 100 dB SPL ≥ 108 dB SPL
3 kHz n/a
≤ 10 dB ≤ 15 dB
< 2 %
n/a
< 0.5 %
n/a
@ 90 dB SPL
from 30 to 85 Hz
n/a ≤ 3 %
n/a ≤ 3 %
n/a
1 XLR female
1 XLR female 4 XLR female
Single dual acting
connector
1 XLR male 4 XLR male
16 - 24 bits 16 - 24 bits
32 - 192 kHz 32 - 192 kHz
n/a proprietary GLM TM
network
2 RJ45, CAT5 cables
2 (at the high pass filters of 4 LF
the SE7261A)
AutoCal , GLM.SE AutoCal , GLM.SE
TM TM TM TM
manual, DIP switches manual, Stand-alone
40 W 120 W
40 W n/a
15 VA 15 VA
80 VA 150 VA
285 mm (11 / ") 527 mm (20 / ")
1 3
4 4
462 mm (18 3 / ")
189 mm (7 / ")
7
16
16
363 mm (14 / ")
5
178 mm ( 7 1 / ")
16
16 n/a
299 mm (11 13 / ")
16
5.6 kg (12.3 lb) 27 kg (59 lb)
(GLM.SE™) Small Environment DSP
System Software
• GLM.SE™ provides connectivity for one SE7261A DSP
subwoofer combined with up to eight 8130A digital input
loudspeakers
• Enables multiple custom User Setups with all settings
and functions able to be stored in GLM.SE™ setup or
directly to the SE7261A subwoofer
• Step-by-step Wizard guides user through complete
cabling connections and loudspeaker labeling
• Rapid Cabling setups for most common system
configurations
• Manual Cabling setups for customized system
configurations
• Groups for both Channels and Loudspeakers may be
customized by User
• Solo/Mute function for all Loudspeakers and Groups
• Volume controlled via computer, 3rd party USB device
or customer console
• Video Display Compensation for inherent video delays
in digital video devices
• GLM.SE supports Windows XP and Mac OS X
TM
operating systems
• GLM.SE™ provides interface to AutoCal™ automated
acoustic self-calibration algorithm
Major components included:
• GLM TM interface device
• 8200A Calibration microphone and holder
• USB cable
• Measurement signal cable
• Software CD
• System Operating Manual
