CHALLENGER 9000M SERIES
Residential Vehicular Garage Door Operator
MODEL NUMBERS 9300M, 9500M, and J9500M
I N S T A L L A T I O N A N D O W N E R ' S M A N U A L
INSTALLER: Place this manual in the plastic envelope provided and
110060
R E A D T H I S M A N U A L C A R E F U L L Y B E F O R E I N S T A L L A T I O N O R U S E

TABLE OF CONTENTS

Product Features ......................................................2
Tools Required..........................................................2
Component Identification ........................................3
Assembly Instructions ....................................3
Identify Your Door Type ...........................................4
C: Installing the Operator ........................................6
Mounting the Front Bracket...............................6
Mounting the Power Head .................................7
Door Bracket Installation ...................................7
Door Arm Installation.........................................8
Connecting Electrical Power .............................9
The Convenience Lamp .....................................9
D: Control & Auxiliary Equipment..........................10
Standard Wall Button Installation ...................10
Programming the Radio Receiver ...................13
READ THESE STATEMENTS CAREFULLY AND FOLLOW THE INSTRUCTIONS CLOSELY
The Warning and Caution boxes throughout this manual are there to protect you and your equipment.
WARNING
Indicates a
MECHANICAL
hazard of INJURY
OR DEATH. Gives
instructions to avoid
the hazard.
BY
permanently attach to the wall near the pushbutton.
SA VE T HES E I NST R U C T I ONS
Pay close attention to these boxes as you follow the manual.
CAUTION
Indicates a MECHANICAL
hazard of DAMAGE to the
door, door operator, or
equipment. Gives
instructions to avoid the
hazard.
As of date of
manufacture, meets all
ANSI/UL 325 Safety
Requirements for
Vehicular Garage
Door Operators
Section E: Operation & Adjustments.....................15
Important Safety Instructions .........................15
Turning on the Power ......................................15
Basic Operating Parameters ...........................15
Manual Door Operation..................................... 9
Adjustments .....................................................16
Opening Travel Adjustments...........................16
Setting The Close Limit ...................................16
Obstruction Sensing Adjustment....................16
Testing The Obstruction Sensing ...................17
Positive Mechanical Lock Adjust ....................18
Photoelectric Obstruction Test .......................18
Wiring Diagram .......................................................19
Troubleshooting Guide ..........................................19
Warranty Information .............................................20
WARNING
Indicates an
ELECTRICAL hazard
of INJURY OR
DEATH. Gives
instructions to avoid
the hazard.
CAUTION
Indicates an ELECTRICAL
hazard of DAMAGE to the
door, door operator, or
equipment. Gives
instructions to avoid the
hazard.
