- Page 1 CR400 MID TOWER PC CASE...
- Page 2 3.0 ports and headphone and microphone jacks. Strategically placed routing holes keep cables neat and tidy. Note: This manual is a guide for the CR400 MID TOWER case. For instructions on installing the motherboard and other components, please refer to their documentation.
-
Page 3: Table Of Contents
- Water Cooling Installation - 120.0 mm or 240.0 mm options - Air Cooling Installation - GPU Installation Top / Front Panel Assembly - General Maintenance - Important Safety Information - Limited product warranty ("Limited Warranty") - Troubleshooting your new CR400 - Recommended parts... -
Page 4: Before You Begin
Before You Begin www.riotoro.com/cases... -
Page 5: Exploded View
CR400 MID TOWER CASE Exploded view 1. Front panel 2. Side panel 3. Structure 4. I/O panel 5. 120.0 mm Red LED fan 6. Dust Filter 7. 120.0 Fan 8. Side panel with window Before You Begin... -
Page 6: What Is In The Box
CR400 MID TOWER CASE WHAT’S IN THE BOX ITEM IMAGE DESCRIPTION CR400 Build your gaming Mid Tower Case machine Nylon ties Cable management Water cooling Long screws installation Fan screws Fan installation Thumb screws GPU installation Motherboard Phillip screws installation... -
Page 7: Precautions
CR400 MID TOWER CASE PRECAUTIONS Please take the following precautions: - Handle all PC components and cards with care. - Hold cards and processors by their edges to avoid damaging components. - To avoid damaging components by electrostatic discharge, periodically ground yourself by touching an unpainted metal surface or by using a wrist grounding strap. -
Page 8: Requirements
2. A magnetic Phillips screw driver This means you need to have the Phillips screw driver available in order to complete this assembly. Note: Handle all components with care, should you need any assistance go to www.riotoro.com/support Before You Begin... -
Page 9: Ready, Setup, Go
Ready, Setup, Go www.riotoro.com/cases Chapter 1 Before You Begin... -
Page 10: Specifications
CR400 MID TOWER CASE SPECIFICATIONS - Type: Mid Tower - Color: Black - Case Material: Steel, ABS Plastic - With Power Supply: - Motherboard Compatibility: ATX, microATX, Mini-ITX - Side Panel Window: - External 5.25" Drive Bays: - External 3.5" Drive Bays: - Internal 3.5"... -
Page 11: Remove The Side Panels
CR400 MID TOWER CASE REMOVE THE SIDE PANELS Put the case upright on a stable, flat surface with rear facing you. Remove the thumbscrews from both side Remove each panel by sliding the panel panels and store them in a safe place. -
Page 12: Install The Motherboard
CR400 MID TOWER CASE INSTALL THE MOTHERBOARD CR400 comes with enough mounting standoffs for a full ATX or smaller form factor. From inside, snap the I/O shield into the Align the motherboards screw holes with the cutout in the rear of the case. -
Page 13: Connect The Front Panel Switches And Leds
CR400 MID TOWER CASE CONNECT THE FRONT PANEL SWITCHES AND LEDS The front panel switches, LEDs, and USB ports have wire leads that need to be attached to header pins the motherboard. Use your motherboard manual to locate the proper header pins and attach the right connectors. -
Page 14: Power Supply Installation
CR400 MID TOWER CASE POWER SUPPLY INSTALLATION CR400 is designed for quick PSU installation, simply put in place and tighten screws to the back panel. Slide the PSU into position Tighten screws Note: To avoid issues follow the instructions provided by the PSU manufacturer. -
Page 15: Ssd / Hdd Installation
CR400 MID TOWER CASE SSD / HDD INSTALLATION CR400 is designed with tool-less 3.5” (convertible to 2.5”) and 2.5” drive bays. Remove the tool-less bracket, attach Place the bracket with the drive in its the HDD into it original position. -
Page 16: Fan Installation - Front, Top, Bottom
CR400 MID TOWER CASE FAN INSTALLATION – FRONT, TOP, REAR CR400 is designed to provide superb cooling with the two included 120.0 mm fans. Optionally, two 140.0 mm fans can be installed instead. Remove the front panel and magnetic filter Attach the 120.0 mm or 140.0 mm fan on the... -
Page 17: Attaching The Case Fan Cables
The fans included are NON-RGB fans, DO NOT connect to the RGB header. To avoid issues follow the instructions provided by the fan, controller and motherboard manufacturer. Connecting a NON-RGB RIOTORO FAN will potentially set the RGB lightning out of sync, connect any non RGB fan or third party fan to the motherboard fan headers if needed. -
Page 18: Water Cooling Installation - 120.0 Mm Or 240.0 Mm Options
MID TOWER CASE WATER COOLING INSTALLATION - 120.0 MM OR 240.0 MM OPTIONS CR400 is designed to provide superb fan cooling with two options, use a 120.0 mm on the front, top or rear. Alternatively, a 240.0 mm radiator in the front or top. -
Page 19: Air Cooling Installation
CR400 MID TOWER CASE AIR COOLING INSTALLATION CR400 is designed to provide superb cooling with the installation of air cooling solutions up to 180.0 mm in height. Attach the brackets and air cooler to the Make sure all screws are tighten and fans... -
Page 20: Gpu Installation
CR400 MID TOWER CASE GPU INSTALLATION The CR400 allows for the installation of up to thee (3) GPUs. Remove the thumb screws for the PCIe Attach each GPU to the motherboard, place expansion covers. and tighten the thumbs screws and PCIe cover. - Page 21 Everything Else...
-
Page 22: General Maintenance
CR400 MID TOWER CASE GENERAL MAINTENANCE If you need to clean your gaming computer by doing more than wiping it down with a clean cloth, follow these instructions: - Complete power down of your machine, display and peripherals. - Disconnect all the power cables from the electrical outlet power strip. -
Page 23: Important Safety Information
- Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the RIOTORO hotline or go to www.riotoro.com for support. Do not attempt to service or fix the device yourself at any time. -
Page 24: Limited Product Warranty ("Limited Warranty")
MID TOWER CASE LIMITED PRODUCT WARRANTY ("Limited Warranty") Limited Warranty. RIOTORO warrants the Product to be free from defects in materials and workmanship when used normally in accordance with the official documentation for the applicable Warranty Period from the date of retail purchase. -
Page 25: Troubleshooting Your New Cr400
(refer to your MB manual to identify the right pin headers.) - How to clean the Dust filters. The CR400 comes with dust filters, and are meant to help keep the computer components clean, blocking the dust from the outside, they are located across several points that could potentially be used as intake areas. -
Page 26: Recommended Parts
CR400 MID TOWER CASE RECOMMENDED PARTS P O W E R S U P P L Y U N I T BUILDER EDITION 500W & 600W: The Builder Edition combines 80 PLUS White certified energy efficiency with flat cables for reduced energy consumption, quiet operation, and easy installation. - Page 27 CR400 MID TOWER CASE RECOMMENDED PARTS W A T E R C O O L I N G R G B F A N BIFROST 120ti & 240: is a new generation water cooling solution for both AMD and Intel platforms.
- Page 28 CR400 MID TOWER CASE RECOMMENDED PARTS G A M I N G M I C E G A M I N G K E Y B O A R D AUROX: the Aurox Prism RGB gaming mouse combines an ergonomic exterior with an ultra-precise 10000 DPI optical sensor, 8 programmable buttons, aluminum scroll wheel, and customizable RGB lighting.
- Page 29 © 2019 RIOTORO Inc. All rights reserved. RIOTORO, the RIOTORO logo, and CR400 are trademarks of RIOTORO Inc., Registered in the U.S. and other countries. All other trademarks are the property of their respectiveowners. Product may vary slightly from those pictured.
- Page 30 www.riotoro.com...
