- Page 1 CR101BE MID TOWER PC CASE...
- Page 2 Two 3.5” drive bays and two SSD mounts provide plenty of storage, the front-mounted I/O and ODD bays provides easy access to external devices and audio ports. Note: This manual is a guide for the CR101BE convertible case. For instructions on installing the motherboard and other components, please refer to their documentation.
-
Page 3: Table Of Contents
- Water Cooling Installation - 240.0 mm options - Air Cooling Installation - GPU Installation Top / Front Panel Assembly - General Maintenance - Important Safety Information - Limited product warranty ("Limited Warranty") - Troubleshooting your new CR101BE - Recommended parts... -
Page 4: Before You Begin
Before You Begin www.riotoro.com/cases... -
Page 5: Exploded View
CR101BE MID TOWER CASE Exploded view 1. Side panel 2. Front panel 3. I/O 4. ODD cover 5. Body 6. Fan bracket 7. Side panel Before You Begin... -
Page 6: What Is In The Box
CR101BE MID TOWER CASE WHAT’S IN THE BOX ITEM IMAGE DESCRIPTION CR101BE Build your gaming MID TOWER Case machine Radiator brackets 240.0 mm radiator installation 120.00 mm fan Ventiallation HDD screws HDD installation PSU screws PSU installation Motherboard Standoffs installation... -
Page 7: Precautions
CR101BE MID TOWER CASE PRECAUTIONS Please take the following precautions: - Handle all PC components and cards with care. - Hold cards and processors by their edges to avoid damaging components. - To avoid damaging components by electrostatic discharge, periodically ground yourself by touching an unpainted metal surface or by using a wrist grounding strap. -
Page 8: Requirements
2. A magnetic Phillips screw driver This means you need to have the Phillips screw driver available in order to complete this assembly. Note: Handle all components with care, should you need any assistance go to www.riotoro.com/support Before You Begin... -
Page 9: Ready, Setup, Go
Ready, Setup, Go www.riotoro.com/cases... -
Page 10: Specifications
CR101BE MID TOWER CASE SPECIFICATIONS - Type: MID TOWER - Color: Black - Case Material: Steel, ABS Plastic - Metal Thickness: 0.4 mm - With Power Supply: - Motherboard Compatibility: ATX, Micro ATX, Mini-ITX - Side Panel Window: - External 5.25" Drive Bays: - External 3.5"... -
Page 11: Remove The Side Panels
CR101BE MID TOWER CASE REMOVE THE SIDE PANELS Put the case upright on a stable, flat surface with the rear facing you. Remove the thumbscrews from both side Remove the side panel by sliding it towards the panels and store them in a safe place. -
Page 12: Install The Motherboard
CR101BE MID TOWER CASE INSTALL THE MOTHERBOARD CR101BE comes with enough mounting standoffs for a full ATX or smaller form factor. Align the motherboards screw holes with the From inside, snap the I/O shield into the case standoff, attach the motherboard using cutout which is located in the rear of the case. -
Page 13: Connect The Front Panel Switches And Leds
CR101BE MID TOWER CASE CONNECT THE FRONT PANEL SWITCHES AND LEDS The front panel switches, LEDs, and USB ports have wire leads that need to be attached to the motherboard header pins. Use the motherboard manual to locate the proper header pins and attach the right connectors. -
Page 14: Power Supply Installation
CR101BE MID TOWER CASE POWER SUPPLY INSTALLATION CR101BE is designed for a quick PSU installation, simply put in place and tighten screws to the back panel. Slide the PSU into position Tighten screws Chapter 2... - Page 15 CR101BE MID TOWER CASE REMOVE FRONT PANEL In order to install all fans, you need to remove the front panel. Remove the security screws from the panel. Remove the front panel. Note: place the two screws on a safe place as they need to be reinstalled when you put the front panel back.
-
Page 16: Fan Installation - Front, Back, Side
CR101BE MID TOWER CASE FAN INSTALLATION – FRONT, BACK, SIDE CR101BE is designed to provide superb cooling; with fan mounts on the front, back and side. Attach the 120.0 mm fan on the front and Attach up to two 120.0 mm fans on the side an 80.0 mm exhaust on the back. -
Page 17: Ssd / Hdd / Odd Installation
CR101BE MID TOWER CASE SSD / HDD / ODD INSTALLATION CR101BE is designed with easy installation 3.5” and 2.5” drive bays and ODDs. (optional) Attach the HDD or SSD to the respective Attach the ODD to the respective location, location. -
Page 18: Water Cooling Installation - 120.0 Mm Options
CR101BE MID TOWER CASE WATER COOLING INSTALLATION - 120.0 MM OPTIONS CR101BE is designed to provide superb water cooling, you can easily install a 120.0 mm radiator in the front. Attach the water block to the motherboard. Attach the fan and radiator to the fan bracket. -
Page 19: Air Cooling Installation
CR101BE MID TOWER CASE AIR COOLING INSTALLATION CR101BE is designed to provide superb cooling with the installation of air cooling solutions up to 140.0 mm in height. Attach the brackets and air cooler to the Make sure all screws are tighten and fans... -
Page 20: Gpu Installation
CR101BE MID TOWER CASE GPU INSTALLATION The CR101BE allows for the installation of up to thee (3) GPUs. Remove the thumb screws for the PCIe Attach each GPU to the motherboard, place expansion covers. and tighten the thumbs screws. Note: the total amount of GPUs depends on the motherboard you choose. - Page 21 Everything Else...
-
Page 22: General Maintenance
CR101BE MID TOWER CASE GENERAL MAINTENANCE If you need to clean your gaming computer by doing more than wiping it down with a clean cloth, follow these instructions: - Complete power down of your machine, display and peripherals. - Disconnect all the power cables from the electrical outlet power strip. -
Page 23: Important Safety Information
- Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the RIOTORO hot-line or go to www.riotoro.com for support. Do not attempt to service or fix the device yourself at any time. -
Page 24: Limited Product Warranty ("Limited Warranty")
MID TOWER CASE LIMITED PRODUCT WARRANTY ("Limited Warranty") Limited Warranty. RIOTORO warrants the Product to be free from defects in materials and workmanship when used normally in accordance with the official documentation for the applicable Warranty Period from the date of retail purchase. -
Page 25: Troubleshooting Your New Cr101Be
(refer to your MB manual to identify the right pin headers.) How to clean the Dust filters. The CR101BE comes with dust filters, and are meant to help keep the computer components clean, blocking the dust from the outside, they are located across several points that could potentially be used as intake areas. -
Page 26: Recommended Parts
CR101BE MID TOWER CASE RECOMMENDED PARTS P O W E R S U P P L Y U N I T BUILDER EDITION 500W & 600W: The Builder Edition combines 80 PLUS White certified energy efficiency with flat cables for reduced energy consumption, quiet operation, and easy installation. - Page 27 CR101BE MID TOWER CASE RECOMMENDED PARTS W A T E R C O O L I N G R G B F A N BIFROST 240: is a new generation water cooling solution for both AAMD and Intel proces- sors uses a 240.0 mm radiator with dual 120.0 mm static pressure 120.0 mm fans for extreme cooling that fits nearly any PC case.
- Page 28 CR101BE MID TOWER CASE RECOMMENDED PARTS G A M I N G M I C E G A M I N G K E Y B O A R D AUROX: the Aurox Prism RGB gaming mouse combines an ergonomic exterior with an ultra-precise 10000 DPI optical sensor, 8 programmable buttons, aluminum scroll wheel, and customizable RGB lighting.
- Page 29 © 2020 RIOTORO Inc. All rights reserved. RIOTORO, the RIOTORO logo, and CR101BE are trademarks of RIOTORO Inc., Registered in the U.S. and other countries. All other trademarks are the property of their respective owners. Product may vary slightly from those pictured.
- Page 30 www.riotoro.com...
