Riotoro MORPHEUS Manual

Convertible pc case mid tower configuration
Hide thumbs
Table of Contents

Advertisement

Quick Links

MORPHEUS
CONVERTIBLE PC CASE
MID TOWER CONFIGURATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MORPHEUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Riotoro MORPHEUS

Summary of Contents for Riotoro MORPHEUS

  • Page 1 MORPHEUS CONVERTIBLE PC CASE MID TOWER CONFIGURATION...
  • Page 2 The perforated mesh exterior and keeps the PC cool, and USB Type-C provides state-of-the-art connectivity. Note: This manual is a guide for the Morpheus convertible case. For instructions on installing the motherboard and other components, please refer to their documentation.

  • Page 3: Table Of Contents

    MORPHEUS CONVERTIBLE PC CASE CONTENTS Before You Begin Trim / Side Panel Assembly - Exploded view - Components required to build this section - What is in the box - Secure the trim to the structure - Requirements - Install cooling bracket and filter...

  • Page 4: Before You Begin

    Before You Begin www.riotoro.com/Morpheus...

  • Page 5: Exploded View

    MORPHEUS CONVERTIBLE PC CASE Exploded view 1. I/O panel 2. Dust filter 3. Top panel structure 4. Extension bracket 5. SSD cage 6. HDD cage 7. Middle panel 8. Cable management channels 9. Cooling bracket 10. Base plate structure 11. Bottom panel 12.

  • Page 6: What Is In The Box

    OVERVIEW RIOTORO Morpheus, the world's first convertible PC case, allows you to resize your PC as your needs evolve. Morpheus can easily shape-shift to and from a short or tall ATX mid-tower. The entire exterior is perforated mesh, which combined with the stock dual 140.0 mm fans, keeps your PC’s components running cool and...
  • Page 7 MORPHEUS CONVERTIBLE PC CASE WHAT’S IN THE BOX ITEM IMAGE DESCRIPTION 120.0 mm Front, Top, or Red LED Fan Bottom 80.0 mm Back Exhaust Fan Screw M3 x 5mm Trim installation Screw M3 x 5mm Structure installation Screw 5 x 10KT...

  • Page 8: Requirements

    Start by taking the entire content out of the box, sort them out by section, take out the quick start mouse mat and use it as general guide and building surface. Note: Handle all components with care, should you need any assistance go to www.riotoro.com/support Before You Begin...

  • Page 9: Back / Bottom Panel Assembly

    Back / Bottom Panel Assembly www.riotoro.com/Morpheus...

  • Page 10: Components Required To Build This Section

    MORPHEUS BACK / BOTTOM PANEL ASSEMBLY Components required to build this section: IMAGE DESCRIPTION Top & bottom trim Back panel PCIe bracket Back panel Mini Adjustable top Back panel structure & body Bottom structure Bottom panel and feet Dust filter Bottom panel 80.0 mm...

  • Page 11: Unpack Components

    MORPHEUS BACK / BOTTOM PANEL ASSEMBLY Unpack components To start the assembly, you need to: - Take out the preassembled bottom and back panel out of the bag. - Remove the top back trim and set it aside for later use, additionally...

  • Page 12: Create An L-Shape Structure

    MORPHEUS BACK / BOTTOM PANEL ASSEMBLY Create an L-Shape structure - Lift the back panel to an upright position, in order to make an L-Shaped structure, , tke out the shipping foam, mini tower expansion bracket and 80.0 mm fan and set them aside for later use.

  • Page 13: Secure The Structure

    MORPHEUS BACK / BOTTOM PANEL ASSEMBLY Secure the structure - Locate the two screw holes at the bottom of the structure, place and tighten two structure screws. screw them from the outside in Chapter 1...
  • Page 14 MORPHEUS BACK / BOTTOM PANEL ASSEMBLY Secure the structure Once you have secured the two sides, you should have an L-shaped section ready for configuration. - Adjust the height of the adjustable top in order align the structure screw holes of the adjustable top and the back panel body.

  • Page 15: Install The Exhaust Fan

    MORPHEUS BACK / BOTTOM PANEL ASSEMBLY Install the exhaust fan - Align the fan to the back panel body, place and tighten the fan screws (provided in box PL01-1). screw them from the outside in Chapter 1...
  • Page 16 Middle Panel Assembly www.riotoro.com/Morpheus...

  • Page 17: Middle Panel Assembly - Components Required To Build This Section

    MORPHEUS MIDDLE PANEL ASSEMBLY Components required to build this section: IMAGE DESCRIPTION panel with 6x Cable Middle panel Management Routing Channels Base plate Middle panel HDD bracket for Middle panel two drives SSD bracket for Middle panel two drives Extension plate...

  • Page 18: Unpack Components

    MORPHEUS MIDDLE PANEL ASSEMBLY Unpack components Provided a successful SECTION 1 assembly, now the next step is to install the middle panel and its components. To start the assembly, you need to: - Take out the preassembled middle panel and base plate out of the bags.

  • Page 19: Seure The Structure

    MORPHEUS MIDDLE PANEL ASSEMBLY Secure the structure - Align the holes for the preassembled middle panel and base plate, join both parts by placing and tightening two (1 & 2) structure screws. screw them from the outside in Chapter 2...
  • Page 20 MORPHEUS MIDDLE PANEL ASSEMBLY Secure the structure - Get the HDD stabilizer, align the screw holes, place and tighten two structure screws in order to secure it into place. Note: you need to have the Phillips screw driver available in order to complete this assembly.
  • Page 21 MORPHEUS MIDDLE PANEL ASSEMBLY Secure the structure Once the middle section is fully assembled, place it inside the SECTION 1 build. Make sure to align the screw holes to facilitate assembly. - Place the middle panel on top of the bottom panel and secure it into position using five structure screws;...
  • Page 22 MORPHEUS MIDDLE PANEL ASSEMBLY Secure the structure Once the middle section is fully assembled, place it inside the SECTION 1 build. Make sure to align the screw holes to facilitate assembly. - Take out the extension plate out of the bag, align it to the middle panel secure it into place with three structure screws.
  • Page 23 MORPHEUS MIDDLE PANEL ASSEMBLY Secure the structure - Turn over the build, place and tighten a screw located in the bottom panel. screw them from the outside in Chapter 2...

  • Page 24: Secure The Drive Caddies

    MORPHEUS MIDDLE PANEL ASSEMBLY Secure the drive caddies - Turn over the build to its upright position. Take out the additional SSD bracket out of the bag, slide it into position and use the thumb screw secure it into place.

  • Page 25: Top / Front Panel Assembly

    Top / Front Panel Assembly Trim / Side Panel Assembly www.riotoro.com/Morpheus www.riotoro.com/Morpheus...

  • Page 26: Components Required To Build This Section

    MORPHEUS TOP / FRONT PANEL ASSEMBLY Components required to build this section: IMAGE DESCRIPTION Middle structure and Front panel dust filter Adjustable to and Front panel bottom structure Top and bottom Front panel trim 120.0 mm Front panel Exhaust Fan...

  • Page 27: Unpack Components

    MORPHEUS TOP / FRONT PANEL ASSEMBLY Unpack components Provided a successful SECTION 2 assembly, now the next step is to install the top and front panels and their components. To start the assembly, you need to: - Take out the preassembled top and front panel out of the bag.

  • Page 28: Create An L-Shape Structure

    MORPHEUS TOP / FRONT PANEL ASSEMBLY Create an L-Shape structure - Lift the front panel to an upright position, in order to make an L-Shaped structure, take out the cooling bracket and the two 120.0 mm red LED fans and set them aside for later use.

  • Page 29: Secure The Structure

    MORPHEUS TOP / FRONT PANEL ASSEMBLY Secure the structure Secure the structure - Locate the two screw holes at the bottom of the L-Structure, place and tighten two (1 and 2) structure screws. screw them from the outside in Chapter 3...
  • Page 30 MORPHEUS TOP / FRONT PANEL ASSEMBLY Secure the structure Once you have secured the two sides, you should have an L-shaped section ready for configuration. - Remove the structure screws, adjust the height of the top structure screw them from the outside in...
  • Page 31 MORPHEUS TOP / FRONT PANEL ASSEMBLY Secure the structure - Align the middle structure to the top and bottom structure, place and tighten four (1, 2, 3, 4, 5, 6, 7 and 8) structure screws Chapter 3...
  • Page 32 MORPHEUS TOP / FRONT PANEL ASSEMBLY Secure the structure - Turn the L-Shape to an upright position and place it on top of section two build and remove filter Chapter 3...
  • Page 33 MORPHEUS TOP / FRONT PANEL ASSEMBLY Secure the structure - Place and tighten four (1, 2, 3 and 4) structure screws to join all sections screw them from the outside in Chapter 3...
  • Page 34 MORPHEUS TOP / FRONT PANEL ASSEMBLY Secure the structure - Place and tighten two (1 and 2) structure screws to join the front and bottom panels, four (3, 4, 5 and 6) to join the middle and front panels and two (7 and 8) to join the middle and back panels...
  • Page 35 MORPHEUS TOP / FRONT PANEL ASSEMBLY Secure the structure - Place and tighten two (1 and 2) structure screws to join the back and top panels and tighten two (3 and 4) structure screws to join the middle and top panels...

  • Page 36: Trim / Side Panel Assembly

    Trim / Side Panel Assembly www.riotoro.com/Morpheus...

  • Page 37: Components Required To Build This Section

    MORPHEUS TOP / FRONT PANEL ASSEMBLY Components required to build this section: IMAGE DESCRIPTION Top and bottom Front panel trim Adjustable side Side panel panel Magnetic filter Sidepanel Mid tower configuration Side panel magnetic filter Mini tower configuration Side panel...

  • Page 38: Secure The Trim To The Structure

    MORPHEUS TRIM / SIDE PANEL ASSEMBLY Secure the trim to the structure - Start by positioning the bottom trim, place and tighten two (1 and 2) trim screws, place the top trim, place and tighten three (3, 4 and 5) trim screws and finally place and tighten four (6, 7, 8 and 9) structure screws.
  • Page 39 MORPHEUS TRIM / SIDE PANEL ASSEMBLY Secure the trim to the structure - Slide the top and bottom trim into position, place and tighten eight (1, 2, 3, 4, 5, 6, 7 and 8) trim screws tighten structure screws from the inside...

  • Page 40: Install Cooling Bracket And Filter

    Install cooling bracket and filter - Position and snap on the cooling bracket on the front panel, from the inside of Morpheus and secure it into position with one structure screw and put the dust filter back on screw it from the outside in...

  • Page 41: Adjust The Side Panels

    MORPHEUS TRIM / SIDE PANEL ASSEMBLY Adjust the side panels Now you are ready to finalize the assembly, should you want to install your components, this would be the right time to start. If you want to finalize the assembly you need to:...
  • Page 42 MORPHEUS TOP / FRONT PANEL ASSEMBLY Adjust the side panels - Unscrew the structure screws, reposition the side panel parts to fit the mid tower configuration Chapter 4...
  • Page 43 MORPHEUS TRIM / SIDE PANEL ASSEMBLY Adjust the side panels - Place and tighten the structure screws to secure the pieces in position and place the dust filters Chapter 4...

  • Page 44: Install Side Panels

    MORPHEUS TRIM / SIDE PANEL ASSEMBLY Install side panels - Choose which color of side panel screws you want to us, place the side panel into position, place and tighten the side panel screws Note: Save the unused dust filter extension for a future use...
  • Page 45 Ready, setup, go www.riotoro.com/Morpheus...

  • Page 46: Specifications

    MORPHEUS READY, SETUP, GO Specifications - Type: Convertible Tower - Color: Black - Case Material: Steel, ABS Plastic - With Power Supply: - Motherboard Compatibility: ATX, microATX, Mini-ITX - Side Panel Window: - External 5.25" Drive Bays: - External 3.5" Drive Bays: - Internal 3.5"...

  • Page 47: Motherboard Installation

    MORPHEUS READY, SETUP, GO Motherboard Installation Morpheus comes with enough mounting standoffs for a full ATX or smaller form factor. Remove the thumb screws, side panel and Align the motherboards screw holes with the install the I/O shield case standoff, attach the motherboard using the provided screws.

  • Page 48: Connect The Front Panel

    READY, SETUP, GO Connect the Front Panel Switches and LEDs Morpheus’ front panel switches, LEDs, and USB ports have wire leads that need to be attached to header pins the motherboard. Use your motherboard manual to locate the proper header pins and attach the right connectors.

  • Page 49: Power Supply Installation

    MORPHEUS READY, SETUP, GO Power Supply Installation Morpheus is designed for quick PSU installation, simply put in place and tighten screws to the back panel. Slide the PSU into position Tighten screws Chapter 5...

  • Page 50: Ssd / Hdd Installation

    MORPHEUS READY, SETUP, GO SSD / HDD Installation Morpheus is designed with tool-less 3.5” (convertible to 2.5”) and 2.5” drive bays. Remove the tool-less bracket, attach Place the bracket with the drive in its the HDD into it original position.

  • Page 51: Fan Installation: Front, Top, Bottom

    READY, SETUP, GO Fan Installation - Front, top, bottom Morpheus is designed to provide superb cooling with the two included 120.0 mm fans. Optionally, two 140.0 mm fans or a single 200.0 mm fan can be installed instead (not included).

  • Page 52: Attaching The Case Fan Cables

    RGB controller. Note: connecting a NON-RGB RIOTORO FAN will potentially set the RGB lightning out of sync, connect any non RGB fan or third party fan to the motherboard fan headers if needed. Chapter 5...

  • Page 53: Water Cooling Installation - 120.0 Mm

    READY, SETUP, GO Water Cooling Installation - 120.0 mm or 140.0 mm options Morpheus is designed to provide superb fan cooling with two options, use a 120.0 mm or a 240.0 mm radiator in the front, top or bottom. Remove the dust filters, attach the 120.0 mm Remove the dust filters, attach the 140.0 mm...

  • Page 54: Gpu Installation

    MORPHEUS READY, SETUP, GO GPU Installation In the mid tower configuration Morpheus allows for the installation of up to four (4) GPUs. Remove the thumb screws and PCIe Attach each GPU to the motherboard, place expansion covers/ and tighten the thumbs screws.

  • Page 55: Everything Else

    Everything else www.riotoro.com/Morpheus...

  • Page 56: General Maintenace

    MORPHEUS EVERYTHING ELSE General Maintenace If you need to clean your gaming computer by doing more than wiping it down with a clean cloth, follow these instructions: - Complete power down of your machine, display and peripherals. - Disconnect all the power cables from the electrical outlet power strip.

  • Page 57: Important Safety Information

    - Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the RIOTORO hotline or go to www.riotoro.com for support. Do not attempt to service or fix the device yourself at any time.

  • Page 58: Limited Product Warranty

    EVERYTHING ELSE LIMITED PRODUCT WARRANTY ("Limited Warranty") Limited Warranty. RIOTORO warrants the Product to be free from defects in materials and workmanship when used normally in accordance with the official documentation for the applicable Warranty Period from the date of retail purchase.
  • Page 59 © 2019 RIOTORO Inc. All rights reserved. RIOTORO, the RIOTORO logo, Morpheus logo and GPX100 are trademarks of RIOTORO Inc., Registered in the U.S. and other countries. All other trademarks are the property of their respectiveowners. Product may vary slightly from those pictured.
  • Page 60 www.riotoro.com/Morpheus...
