Summary of Contents for Riotoro CR1288
- Page 1 CR1288 FULL TOWER PC CASE...
- Page 2 GPU, CPU, and storage. Additional mount points allow users to add more fans or radiators. Note: This manual is a guide for the CR1288 Full Tower case. For instructions on installing the motherboard and other components, please refer to their documentation.
-
Page 3: Table Of Contents
- Water Cooling Installation - 120.0 mm or 240.0 mm options - GPU Installation Top / Front Panel Assembly - General Maintenance - Important Safety Information - Limited product warranty ("Limited Warranty") - Troubleshooting your new CR1288 - Recommended parts... -
Page 4: Before You Begin
Before You Begin www.riotoro.com/cases... -
Page 5: Exploded View
CR1288 FULL TOWER CASE Exploded view 1. I/O panel 2. Front panel 3. Side panel 4. SSD caddy 5. Fan hub 6. HDD caddy 7. Top filter 8. Bottom filter 9. Body 10. 140.0 mm fans 11. 120.0 mm fan 12. -
Page 6: What Is In The Box
CR1288 FULL TOWER CASE WHAT’S IN THE BOX ITEM IMAGE DESCRIPTION CR1288 Build your gaming Full Tower Case machine Nylon ties Cable management Water cooling Long screws installation Fan screws Fan installation Thumb screws GPU installation Motherboard Phillip screws installation... -
Page 7: Precautions
CR1288 FULL TOWER CASE PRECAUTIONS Please take the following precautions: - Handle all PC components and cards with care. - Hold cards and processors by their edges to avoid damaging components. - To avoid damaging components by electrostatic discharge, periodically ground yourself by touching an unpainted metal surface or by using a wrist grounding strap. -
Page 8: Requirements
Start by taking the entire content out of the box, sort them out by section, take out the quick start mouse mat and use it as general guide and building surface. Note: Handle all components with care, should you need any assistance go to www.riotoro.com/support Before You Begin... -
Page 9: Ready, Setup, Go
Ready, Setup, Go www.riotoro.com/cases Chapter 1 Before You Begin... -
Page 10: Specifications
CR1288 FULL TOWER CASE SPECIFICATIONS - Type: Full Tower - Color: Black - Case Material: Steel, ABS Plastic - With Power Supply: - Motherboard Compatibility: E-ATX, ATX, Micro ATX, Mini-ITX - Side Panel Window: Tempered Glass - External 5.25" Drive Bays: - External 3.5"... -
Page 11: Remove The Side Panels
CR1288 FULL TOWER CASE REMOVE THE SIDE PANELS Put the case upright on a stable, flat surface with rear facing you. Remove the thumbscrews from both side Remove each panel by sliding the panel panels and store them in a safe place. -
Page 12: Install The Motherboard
CR1288 FULL TOWER CASE INSTALL THE MOTHERBOARD CR1288 comes with enough mounting standoffs for a full ATX or smaller form factor. From inside, snap the I/O shield into the Align the motherboards screw holes with the cutout in the rear of the case. -
Page 13: Connect The Front Panel Switches And Leds
CR1288 FULL TOWER CASE CONNECT THE FRONT PANEL SWITCHES AND LEDS The front panel switches, LEDs, and USB ports have wire leads that need to be attached to header pins the motherboard. Use your motherboard manual to locate the proper header pins and attach the right connectors. -
Page 14: Power Supply Installation
CR1288 FULL TOWER CASE POWER SUPPLY INSTALLATION CR1288 is designed for quick PSU installation, simply put in place and tighten screws to the back panel. Slide the PSU into position Tighten screws Chapter 2... -
Page 15: Fan Installation - Front, Top, Bottom, Back
FULL TOWER CASE FAN INSTALLATION – FRONT, TOP, BOTTOM, BACK CR1288 is designed to provide superb cooling with the two included 120.0 mm fans. Optionally, two 140.0 mm fans can be installed instead. Remove the front panel and magnetic filter Attach the 120.0 mm or 140.0 mm fan on the... -
Page 16: Attaching The Case Fan Cables
The fans included are NON-RGB fans, DO NOT connect to the RGB header. To avoid issues follow the instructions provided by the fan, controller and motherboard manufacturer. Connecting a NON-RGB RIOTORO FAN will potentially set the RGB lightning out of sync, connect any non RGB fan or third party fan to the motherboard fan headers if needed. -
Page 17: Rgb Hub Details
CR1288 FULL TOWER CASE RGB HUB DETAILS The RGB controller is able to power and provide lighting control to your RGB components SATA cable to PSU I/O Cable 12 Volt Fan 1 Power Fan 2 Power LED Strip Fan 3... -
Page 18: Lighting Control With Rgb Motherboards
CR1288 FULL TOWER CASE LIGHTING CONTROL WITH RGB MOTHERBOARDS Motherboards with RGB lighting features allow you to control the case lighting from its software, just make sure it has RGB 4-pin connectors with the pinout 12V-G-R-B. Detach the case’s RGB cable (12 volt RGB cable) -
Page 19: Customizing Rgb Lighting
CR1288 FULL TOWER CASE CUSTOMIZING RGB LIGHTING You can easily customize the case lighting by pressing the color, brightness or mode button, the setting will be saved even when the system is powered off. 1. Changing the Lighting Mode To step through the lighting modes, press the RGB button. -
Page 20: Ssd / Hdd Installation
CR1288 FULL TOWER CASE SSD / HDD INSTALLATION CR1288 is designed with tool-less 3.5” (convertible to 2.5”) and 2.5” drive bays. Remove the tool-less bracket, attach Place the bracket with the drive in its the HDD or SSD into it original position. -
Page 21: Water Cooling Installation - 120.0 Mm Or 240.0 Mm Options
FULL TOWER CASE WATER COOLING INSTALLATION - 120.0 MM OR 240.0 MM OPTIONS CR1288 is designed to provide superb fan cooling with two options, use a 120.0 mm or a 240.0 mm radiator in the front or top. Remove the front panel, attach the 120.0 mm Remove the front panel, attach the 240.0 mm... -
Page 22: Gpu Installation
CR1288 FULL TOWER CASE GPU INSTALLATION The CR1288 allows for the installation of up to thee (3) GPUs. Remove the thumb screws for the PCIe Attach each GPU to the motherboard, place expansion covers. and tighten the thumbs screws and PCIe cover. - Page 23 Everything Else...
-
Page 24: General Maintenance
CR1288 FULL TOWER CASE GENERAL MAINTENANCE If you need to clean your gaming computer by doing more than wiping it down with a clean cloth, follow these instructions: - Complete power down of your machine, display and peripherals. - Disconnect all the power cables from the electrical outlet power strip. -
Page 25: Important Safety Information
- Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the RIOTORO hot-line or go to www.riotoro.com for support. Do not attempt to service or fix the device yourself at any time. -
Page 26: Limited Product Warranty ("Limited Warranty")
FULL TOWER CASE LIMITED PRODUCT WARRANTY ("Limited Warranty") Limited Warranty. RIOTORO warrants the Product to be free from defects in materials and workmanship when used normally in accordance with the official documentation for the applicable Warranty Period from the date of retail purchase. -
Page 27: Troubleshooting Your New Cr1288
(refer to your MB manual to identify the right pin headers.) How to clean the Dust filters. The CR1288 comes with dust filters, and are meant to help keep the computer components clean, blocking the dust from the outside, they are located across several points that could potentially be used as intake areas. -
Page 28: Recommended Parts
CR1288 FULL TOWER CASE RECOMMENDED PARTS P O W E R S U P P L Y U N I T BUILDER EDITION 500W & 600W: The Builder Edition combines 80 PLUS White certified energy efficiency with flat cables for reduced energy consumption, quiet operation, and easy installation. - Page 29 CR1288 FULL TOWER CASE RECOMMENDED PARTS W A T E R C O O L I N G R G B F A N BIFROST 120ti & 240: is a new generation water cooling solution for both AMD and Intel platforms.
- Page 30 CR1288 FULL TOWER CASE RECOMMENDED PARTS G A M I N G M I C E G A M I N G K E Y B O A R D AUROX: the Aurox Prism RGB gaming mouse combines an ergonomic exterior with an ultra-precise 10000 DPI optical sensor, 8 programmable buttons, aluminum scroll wheel, and customizable RGB lighting.
- Page 31 © 2019 RIOTORO Inc. All rights reserved. RIOTORO, the RIOTORO logo, and CR1288 are trademarks of RIOTORO Inc., Registered in the U.S. and other countries. All other trademarks are the property of their respective owners. Product may vary slightly from those pictured.
- Page 32 www.riotoro.com...
