SY-MUHD-44 & SY-MUHD-88
IP Set-Up Commands
Set the Host IP address of the matrix switcher
(Default: 192.168.001.239)
Set the subnet mask
(Default: 255.255.255.000)
Set the Router IP address
(Default: 192.168.001.001)
Set the TCP/IP port number
(Default: 23)
Set DHCP on
Set DHCP off
Get Status Information
Output a report giving the current status of the matrix switcher
Read the input connection status
Read the output connection status
Read input HDCP status
Read output HDCP status
Read output channel settings
Read output On/Off states
Read External (de-embedded) audio status
Read input EDID setting
Read all network settings
Read cascade mode status

Other Commands

Power off the matrix switcher (enter standby mode)
Power off the matrix switcher (exit standby mode)
Help, list all available commands
Reset to factory defaults
Notes:
(1) This command generate a large report giving detailed information about the current status of
the matrix switcher.
(2) This command lists all the commands that the matrix switcher supports.
(3) These EDID commands output an ASCII data block that lists the values of the requested EDID
data values in hexadecimal notation.
(4) These commands respond with a short message, usually one line, giving the requested
information.
(5) The IP status command will respond with all the current IP settings: Host IP address, Subnet
mask, Router IP address, TCP/IP port number and the DHCP setting.
www.sy.co.uk
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(4)
(5)
(4)
(2)
>@WIPH xxx.xxx.xxx.xxx�
>@WIPN xxx.xxx.xxx.xxx�
>@WIPR xxx.xxx.xxx.xxx�
>@WIPH zzzzz�
>@WIPDP ON�
>@WIPDP OFF�
(2)
>@RSTA�
>@R8001�
>@R8002�
>@R8003�
>@R8004�
>@R8006�
>@R8007�
>@R8008�
>@R8009�
>@R8012�
>@R8017�
>@WSPF�
>@WSPN�
>@RH�
>@WSDF�
