- Page 1 Installation Guide SY-MSUHD-88 8x8 HDMI 2.0 4K60 Matrix (18 Gbps) SY Electronics Ltd., 7 Worrall Street, Manchester, M5 4TH, United Kingdom Tel: +44 (0)161 868 3450 – Web: sy.uk...
-
Page 2: Connectors And Controls
The MSUHD-88 is an 8x8 true 4K60 HDMI matrix switcher that is capable is switching HDMI signals up to 18Gbps. HDMI2.0, HDCP2.2 and video resolutions up to 4K are all fully supported. It allows any source (BluRay player, HD DVD player, satellite receiver, game station, etc.) to be shown on the any of the displays simultaneously, no matter whether the source is HDCP compliant or not. -
Page 3: Installation
Power on the input sources you want to show Connect the power supply into the SY-MSUHD-88 and turn on the displays you want to view Use the remote control or the front panel push buttons to make input to output source... -
Page 4: Mode Button
Mode Button The mode button provides three additional selectable options: Scaler Mode (first press of MODE) EDID Management (second press of MODE) Display IP Settings (third press of MODE) Scaler Mode Pressing the MODE button once will make all the output buttons light up, pressing any of the output buttons will display the current scaler setting for that output on the LCD. - Page 5 20：1080P 3D 8CH HDR 21：4K30Hz 3D 2CH (PCM) HDR 22：4K30Hz 3D 6CH HDR 23：4K30Hz 3D 8CH HDR 24：4K60Hz (Y420) 3D 2CH (PCM) HDR 25：4K60Hz (Y420) 3D 6CH HDR 26：4K60Hz (Y420) 3D 8CH HDR 27：4K60Hz 3D 2CH (PCM) HDR 28：4K60Hz 3D 6CH HDR 29：4K60Hz 3D 8CH HDR 30：USER EDID 1 31：USER EDID 2...
- Page 6 The left arrow button selects the next lowest numbered input port, and the right arrow selects the next highest numbered input port. The IR remote control for the SY-MSUHD-88 allows the user to increase or decrease all eight of the inputs source selections simultaneously with a single button press.
-
Page 7: System Information
RS232 Commands The SY-MSUHD-88 switcher can also be controlled using RS232 commands. The following tables lists all the available commands that can be used to control or configure the SY-MSUHD-88 switcher. The baud rate settings are: 57600,n,8,1 (57.6K, no parity, 8 bits, 1 stop) with no handshaking (Tx, Rx only). -
Page 8: Video Settings
Video Settings The following table gives the commands for video selection and various other video options: Command Description Set output x to input y SET OUTx VS INy Set the HDCP status for output x, where y is: SET OUTx HDCPy 0 = AUTO 1 = BYPASS 2 = Disable... -
Page 9: Edid Settings
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 67 Ideally, the above example would be placed into a text file and then sent to the SY-MSUHD-88 switcher using a serial emulation program. The data given above is only an example and may not be compatible with the display devices connected to the SY-MSUHD-88 switcher. -
Page 10: Network Settings
The IP settings can be used to either gain access to the built-in web interface or as a control input for sending the same commands as given for the RS232 port through an IP v4 connection. Please note that the carriage-return character is still required for every command sent over IP to the SY-MSUHD-88. sy.uk V2.4... -
Page 11: Specifications
Specifications General Parameter HDMI Inputs HDMI Outputs Analogue audio outputs (Stereo) S/PDIF coax digital audio outputs Supports all HDMI resolutions up to 4K60 4:4:4, as Video Format Supported (in & out) well as all PC resolutions HDCP compliance HDCP 2.2 and 1.4 (see Video Settings) Audio Formats Supported L-PCM, DTS-HD, Dolby TrueHD Maximum Transmission Distance... -
Page 12: Safety Instructions
Damage to the product due to incorrect usage or storage Damage caused by unauthorised repairs Damage caused by mistreatment of the product 5. Please direct any questions or problems you may have to your local dealer before contacting SY Electronics. sy.uk V2.4...
