Use the supplied surface-mount bracket on walls or ceilings, or mount on a standard microphone stand.
Use a maximum of two in-line antenna amplifiers for extremely long cable runs or for two runs of lighter-grade cable,
Cable Maintenance
To maintain top performance for antenna cables:
•
Avoid sharp bends or kinks in the cables.
•
Do not deform cables with makeshift clamps, such as bending a nail over the cable.
•
Do not use in permanent outdoor installations.
•
Do not expose to extreme moisture.
Selecting Antenna Cables
Use 50 ohm low-loss coaxial cable, such as RG-8U. Shure offers pre-terminated antenna cables ranging from 6 to 100 feet.
NOTE: When ordering cables from Shure, select the low-loss "Z" models (available for longer cables) when using frequency bands above 1000 MHz.
as shown
Shure Incorporated
5/8
