Setting up the TV
Image shown may differ from your TV.
Attaching the stand
UB80**, UB82**, UF695*-ZB
1
B Stand Base
1
2
1 Attach the stand to the TV using the upper
mounting hole on the back of the TV.
2 Attach the stand to the TV using the lower
connection on the back of the TV.
2
UB83**-ZG, UF695*-ZA
1
A Stand Base
1 Attach the stand to the TV using the upper
mounting hole on the back of the TV.
2 Attach the stand to the TV using the lower
connection on the back of the TV.
2
M4 x L20
4 EA
ASSEMBLING AND PREPARING
A stand base
B stand base
1
2
M4 x L21
19
4 EA
