- Page 1 4BIG QUADRA USB 3.0 USER MANUAL CLICK HERE TO ACCESS UP-TO-DATE ONLINE VERSION of this document for the most recent content as well as for features such as expandable illustrations, easier navigation, and search capability. 4big Quadra USB 3.0 User Manual...
-
Page 2: Box Content
INTRODUCTION Welcome to the User Manual for the LaCie 4big Quadra USB 3.0. These pages will guide you through the process of connecting your LaCie product and will explain its features. If this manual doesn't answer your questions or if you are... -
Page 3: Minimum System Requirements
MINIMUM SYSTEM REQUIREMENTS Your system must meet certain requirements in order for your LaCie product to function properly. For a list of these requirements, please refer to the product packaging or consult the product support web page at www.lacie.com/support/. Note: USB 3.0 Connection: For optimal performance through the USB connection, the drive must be connected to a USB 3.0 host port. -
Page 4: Front View
VIEWS OF THE PRODUCT FRONT VIEW Activity LED and shortcut button. See LaCie Desktop Manager for details. 4big Quadra USB 3.0 User Manual... -
Page 5: Rear View
REAR VIEW Drive status LEDs Swappable disks Drive locks USB 3.0 port Chain lock port On/off FireWire 800 ports Power RAID selection/confirmation buttons. See Manage RAID for details. Cable management connectors RAID mode indicator LEDs 4big Quadra USB 3.0 User Manual... -
Page 6: Cables And Connectors
Your LaCie drive is shipped with a SuperSpeed USB 3.0 cable to ensure maximum data transfer performance when connected to a compatible USB 3.0 port. The cable will also work when connected to a USB 2.0 or 1.1 port, but drive performance will be limited to their respective transfer rates. - Page 7 Note: FireWire 800 is backwards compatible with FireWire 400, which means that if you have an adapter cable, you can connect your LaCie FireWire 800 product to a FireWire 400 port on your computer. In this case, file transfers will be limited to FireWire 400 speeds. If your product does not include an adapter cable in the package, you can purchase one from www.lacie.com/accessories/.
-
Page 8: Getting Connected
GETTING CONNECTED Please follow the setup steps in the order they are given to ensure that your LaCie product's volume(s) mount(s) correctly on your computer. STEP 1 - CONNECT THE POWER CABLE Connect the power supply to a wall outlet and to the drive. -
Page 9: Step 3 - Turn On The Drive
STEP 4 - INSTALL SOFTWARE You can now choose to install and run the included LaCie software utilities. Software are located on the CD that came in the product box. If you wish to set email alerts or modify front LED behavior, install LaCie Desktop Manager. - Page 10 4big Quadra USB 3.0 User Manual...
- Page 11 LACIE DESKTOP MANAGER LaCie Desktop Manager unlocks the full potential of your LaCie product. It will allow you to check the status of your device, set up email alerts, create an action when you click the front blue button (shortcut button), and configure power-saving.
- Page 12 INFO TAB On this page you will see advanced information on your drive, such as device name, the internal hard disk serial number (not the LaCie product serial number), available capacity, connection type, etc. Reformat From the Info tab, you can reformat the disks.
- Page 13 Using LaCie Desktop Manager, you can configure a short click to trigger a task (when the product is not in Eco mode). Instantly back up your work, open a family budget spreadsheet, or launch your most commonly used applications.
- Page 14 Energy Management – Mac Users Based upon your LaCie product, Eco Mode may be managed by Mac OS X. If prompted, please click on Energy Saver Settings to enter the System Preferences. Select “Put the hard disk(s) to sleep when possible” to conserve energy.
- Page 15 Energy Management – Windows Users By default, your drive will enter Eco Mode after 5 minutes of inactivity in order to conserve energy. To exit Eco Mode, simply access data and the disks will automatically restart, or click the product's front button. Unclick the Automatic Eco Mode due to Inactivity box to turn off Eco Mode, or select a period of inactivity after which the disks will enter Eco Mode.
-
Page 16: Alerts Tab
ALERTS TAB Enable alerts to receive a message via the LaCie Desktop Manager about changes to the status of your LaCie device. Important info: Activating alerts may affect the transfer rates of your device. For optimal transfer rates, disable alerts. - Page 17 EMAILS TAB If you wish to be warned by email of any change in the status of your LaCie device, enter email addresses here (up to five). You can also enter an email subject line. Next, select the type of event for which you would like to receive emails.
-
Page 18: Led Information
LED INFORMATION Your LaCie product features a multi-functional LED on the front of the drive, as well as four status LEDs on the rear. See Views of the Product for LED locations. LED STATES Blinking blue If the Blinking blue/red... -
Page 19: Manage Raid
MANAGE RAID MODIFY RAID MODE Important info: Changing the RAID mode destroys data stored on the 4big. If you have saved data on the drives, back up data before following these steps. Make sure that the 4big is turned off but that its power supply is connected and that it's connected to a computer via an interface cable. -
Page 20: About Raid Modes
ABOUT RAID MODES Refer to the table below for an overview of the different RAID modes, and see the descriptions for details. RAID Mode Capacity Protection Speed Factory Default RAID 0 100% None Excellent Yes RAID 5 Good Good – RAID 5+spare 50% Excellent Good... - Page 21 RAID 5: In RAID 5, data is striped across all disks (minimum of three) and a parity block for each data block (P in the illustration below) is written on the same stripe. If one physical disk fails, the data from the failed disk can be rebuilt onto a replacement disk.
- Page 22 RAID10: RAID 10 (also called RAID 1+0) is another RAID level that combines the attributes of other levels, specifically RAID 1 and RAID 0. It is a “stripe of mirrored sets”, meaning that data is striped across two mirrored arrays. The striping occurs between arrays and the mirroring occurs within the same array, which makes the rebuilding very fast.
-
Page 23: Replace Drive
Grasp the drive tray handle and carefully extract the drive. Replace Drive Important info: If a hard drive that you have purchased from LaCie fails, please contact your LaCie reseller or LaCie Customer Support. Note that for optimum storage use, the new drive should have equal or greater capacity than the drive it is replacing. -
Page 24: Windows Xp Users
USB, FireWire, Thunderbolt, and eSATA external devices feature “plug & play” connectivity, which means that your LaCie storage can be connected and disconnected while the computer is running. To prevent failures, however, it is important to follow these steps when disconnecting your device. -
Page 25: Mac Users
MAC USERS Drag the storage device icon to the Trash. (The icon pictured below is a generic USB device icon. Your LaCie storage may be represented by an icon that looks like the device itself.) When the icon disappears from the desktop, the storage device can be disconnected. -
Page 26: Formatting And Partitioning
FORMATTING AND PARTITIONING Standard LaCie storage devices will prompt you to run LaCie Setup Assistant when they are first connected to a computer (Windows or Mac). LaCie Setup Assistant helps you to quickly format the storage device according to your needs. - Page 27 MS-DOS File System (FAT 32): This is the Microsoft file system, more typically known as FAT 32. Use FAT 32 if you are going to be sharing your LaCie storage device between Mac and Window computers. See the table below for a comparison between HFS+ and FAT 32 (MS-DOS).
-
Page 28: Formatting Instructions
Right-click on Computer and choose Manage. From the Manage window select Disk Management. From the list of storage devices in the middle of the Disk Management window, locate your LaCie device. By default, a partition is already created on the device with LaCie software utilities. Follow your operating system instructions to reset the existing partition. - Page 29 Mac Users Make sure the storage device is connected to and mounted on the computer. Select Utilities from the Go menu in the Finder menu bar. In the Utilities folder, double-click Disk Utility. Disk Utility will display the message Select a disk, volume, or image. All connected storage devices, partitions, or disk images will be displayed in this column.
-
Page 30: Getting Help
GETTING HELP If you are having problems with your LaCie product, consult the table below for a list of available resources. Order Source Description Location Concise steps to Quick follow for getting your Either a printed leaflet or accessory box and included in the... -
Page 31: Troubleshooting Topics
A: When you turn on the product, the fan will spin at top speed for four seconds. You should be able to hear it by putting your ear near the heat exhaust ports on the rear of the product. If you hear nothing, contact LaCie technical support. - Page 32 Q: Is your computer's internal hard drive limiting transfer speeds? A: If your computer has a low-performance internal hard drive (typically a notebook or netbook computer), it will limit the transfer speed since the internal drive's transfer speed will be significantly less than that of the LaCie hard drive.
- Page 33 A: Disk space will not be reclaimed until the file is completely erased. To remove the files forever, empty your trash/recycle bin. Q: Why is the volume capacity less than advertised on my storage? A: After formatting, the available capacity of a drive will show less than advertised on the box. The difference is based upon how capacity is viewed by the operating system.
- Page 34 X. Right-click this icon, then choose Properties. The General tab will show why the device is not working. Still not working? There may be a hardware defect or other problem. Time to contact www.lacie.com/support/. 4big Quadra USB 3.0 User Manual...
-
Page 35: Health And Safety Precautions
LaCie be held liable for the recovery or restoration of this data. To help prevent the loss of your data, LaCie highly recommends that you keep TWO copies of your data; one copy on your external hard disk, for instance, and a second copy either on your internal hard disk, another external hard disk or some other form of removable storage media. -
Page 36: General Use Precautions
II). Do not expose the LaCie device to temperatures outside the range of 5º C to 35º C (41º F to 95º F); or to operational humidity beyond 10-80%, non-condensing, or non-operating humidity beyond 10-90%, non-condensing. -
Page 37: Warranty Information
LaCie (“LaCie”) warrants, to the original purchaser, that this equipment shall be free of defects in materials and workmanship for a period of one (1), two (2), three (3), or five (5) years, depending on the model, from LaCie's date of original shipment when the equipment is used normally and is properly serviced when needed. If you discover a defect covered by the warranty set forth above, your sole and exclusive remedy will be for LaCie, in its sole discretion to (i) repair or replace the product at no charge to you;... - Page 38 Any loss, corruption or destruction of data while using a LaCie drive is the sole responsibility of the user, and under no circumstances will LaCie be held liable for the recovery or restoration of this data. To help prevent the loss of your data, LaCie highly recommends that you keep TWO copies of your data;...
-
Page 39: Note To Australian Customers
Within the 15 calendar days of purchase, should you experience an issue with your new LaCie product, we ask you to return the product to the place where it was originally bought. You will be required to give a proof of purchase. -
Page 40: Legal Information
LEGAL INFORMATION COPYRIGHTS Copyright © 2014 LaCie. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written consent of LaCie. -
Page 41: Canada Compliance Statement
This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI). If this is used near a radio/TV receiver, it may cause radio interference. Install the equipment according to the manual. This statement does not apply to the LaCie CloudBox.
