Calibrating Generator - Quantum Data 701A Quick Start Manual

Model 700A and 701A generators use programmable hardware to set the amplitude calibration factors
for analog video outputs. These calibration factors are stored in Flash EPROM, and are not lost if the
batteries are run down or removed.
Quantum Data calibrates the analog video and sync output amplitudes in new generators to published
specifications. You can recalibrate these amplitudes over a nominal range to meet your specific testing
conditions.
Equipment Needed for Calibration
•
•
•
•
•
•
1.800.561.8187
Calibrating
WARNING: Recalling the original factory calibration settings is not possible after saving
your own settings.
DC voltmeter capable of measuring from 0 to 1 volt with a minimum resolution of 2 millivolts
Precision 75 ohm (+/- 1%) input terminator for the voltmeter
Test cable to connect the voltmeter to the R, G, B and ground pins on the VGA connector
Oscilloscope with a precision 75 ohm (+/- 1%) input impedance and suitable gain and bandwidth to
display a 1.00 Volt pk-pk signal with 3.579 MHz color carrier
75 ohm coaxial cable to connect the oscilloscope to the BNC TV output
Vector scope
