Editing the Test Sequence
The generator has a default sequence, which you can edit in VGM. One sequence can be stored in the
generator at the same time.
To modify the test sequence:
1.
2.
3.
4.
5.
6.
7.
8.
To run the test sequence, see page 13.
1.800.561.8187

Modifying Test Sequence

Connect the generator with VGM, and then double-click the generator name.
In the generator window, click the Sequence List icon
Right-click the sequence name, and then select Edit to open the Sequence Editor.
Select the 700A generator from the Generator list. Do not select the virtual generator.
Modify the test sequence.
VGM help describes the basic operation of the Sequence editor. Specify only a format and image
for each step. Do not use the No Change value. The 700A-Series generators do not support the
output gating and sync options, and the No Change value.
Select Edit > Edit Sequence Name to save the sequence as a new sequence file.
Select File > Save to save the sequence on your PC, and then close the Sequence Editor.
In the top half of the main VGM window, select the sequence, then click the Send Data icon
store the sequence on the generator.
www.
to display the sequence name.
