Specifications - Quantum Data 701A Quick Start Manual

Video Formats
Storage:
Press Signal Type button to view signal types.
Edit method:
Test Images (Patterns)
Press Image button to list images.
Horizontal Timing
Frequency:
Total pixels:
Active range:
Vertical Timing
Frequency:
Active lines:
Scan types:
Sync Types
Separate digital horizontal and vertical
Digital and analog composite
Bipolar HDTV
Video Outputs
Timing accuracy: 2%
Connectors:
SDI / HD-SDI (701A only)
Connector:
Links:
Bit stream:
Encoding:
Bits/component: 10-bits/component
Sampling mode: YCbCr
Signal swing:
Standards:
DVI
Connector:
Links:
Encoding:
TMDS differential swing:
1.800.561.8187

Specifications

132 total
Windows-based VGM software
1 KHz to 250 KHz
144 to 4096
16 to 4096 pixels
1 Hz to 650 Hz
1 to 4096
Progressive, 2:1 Interlace
See diagram on page 3.
BN DI - SMPTE 292M-C
Single
1.485 Gb/s and 1.485/1.001 Gb/s
4:2:2
800mV
SDI - SMPTE 259M;
HD-SDI - SMPTE 292M-C
DVI-1 dual link
Single link 25MHz-85MHz
RGB (4:4:4 with 8-bits/component)
150–1560 mVp-p (programmable)
www.
Digital Video
Pixel rate: Single link 75 MHz
Audio Outputs
Connecter: 3.5 mm stereo phone jack
Signals: Left: 1 KHz tone
Right: 2 KHz tone
User Interface
Display: 4 x 20 character backlit LCD
Buttons: 9 function buttons, 8 menu buttons, 2
paging buttons
Computer Interface
Type: RS-232, 9 pin D-sub
Protocol: 9600 baud, 8-N-1, Xon/Xoff
VESA EDID/DDC Support
Reads a monitor's EDID data through DVI
connector, and shows list of supported
standard formats. DDC test mode for cycling
through supported standard formats.
Battery Power Operation
Type: Six AA 1500 mA-H rated recharge-
able NiMH batteries (included)
Use time: 8 hours with fully charged NiMH
batteries. Less when using backlight,
DVI, NTSC, or RF features.
AC Power Operation
Type: External charger/power supply sup-
plied with unit
Input: 100-240 VAC @ 47-63 Hz
Output: 12V
Size and Weight
Size: H 5.5 x W 8.25 x D 2 inches
H 140 x W 210 x D 51 mm
Ship weight: 4 lbs, including batteries
.com
25
