Summary of Contents for Inter-m RM-911W
- Page 1 Operation Manual RM-911D/W Remote Microphone...
- Page 2 W a r n i n g CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING To prevent fire or shock hazard, do not expose the unit to rain or moisture.
-
Page 3: Table Of Contents
C o n t e n t s Welcome ..............2 Unpacking ..............2 Short Form Instructions ..........3 Installation Environment............4 Important Safety Instructions .......4 Features ..............6 Front Panel.............7 Rear Panel .............9 Operation Method..........14 Connection ............16 Block Diagram ............17 Specifications ............19 Dimension ............20 Service Procedures............21 Schematic ............21... -
Page 4: Welcome
W e l c o m e A personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products. -
Page 5: Short Form Instructions
S h o r t F o r m I n s t r u c t i o n s 1. Connect the CAT-5E cable to the ARM-911. Be sure that the CAT-5E cable length must not longer than the maximum operable length. 2. -
Page 6: Installation
I n s t a l l a t i o n Environment Never place this product in an environment which could alter its performance or reduce its service life. Such environments usually include high levels of heat, dust, moisture, and vibration. Important Safety Instructions 1. - Page 7 - DO NOT OPEN THE CASE OR ATTEMPT REPAIRS OR MODIFICATIONS YOURSELF This product contains no user-serviceable parts. Refer all maintenance to qualified Inter-M service personnel. Opening the case and/or tampering with internal circuitry voids the warranty. - ALWAYS POWER OFF BEFORE MAKING CONNECTIONS Always turn the AC mains OFF before connecting or disconnecting cables.
-
Page 8: Features
F e a t u r e s ■ ■ DIRECT bROADCASTING Of EMERGENCy MESSAGE By pressing one of 10 instant play buttons, message file can be directly played. ■ ■ REMOTE CONTROl Of ARM-911 Using RM-911D/W, emergency message of ARM- 911 can be controlled at remote place. -
Page 9: Front Panel
If password is set in the GUI, first press the password, and then press the TALK button (RM- 911D) or press the PTT switch (RM-911W) to use the Mic. If password is not correct or not inputted, then the Mic can not be used. - Page 10 OUTpUT lEvEl lED Displays the output audio level. IN-USE INDICATING lED Indicates the RM-911D/W which is now broad- casting using MIC. pOWER lED Indicates the power on state. INSTANT plAy bUTTON Pressing the one of 10 buttons can play the emergency message which is stored in the SD card of ARM-911.
-
Page 11: Rear Panel
R e a rP a n e l RM-911D ExTERNAl ADApTOR (OpTION) INpUT Connect the external adaptor (OPTION) when it is needed. The power is supplied by the ARM-911 if the adaptor is not used. If the external adaptor is used, then the maximum operable distance can be extended and the power consumption of ARM-911 is decreased. - Page 12 AUDIO OUTpUT vOlUME The audio output volume is increased by turning the volume clockwise. The audio output volume is decreased by turning the volume counter-clockwise. MONITOR OUTpUT vOlUME The monitor output volume is increased by turning the volume clockwise. The monitor output volume is decreased by turning the volume counter-clockwise.
- Page 13 RM-911W AC INpUT Of ADApTOR (OpTION) Install the external adaptor (OPTION) after open the left top cover, when it is needed. The power is supplied by the ARM-911 if the adaptor is not used. If the external adaptor is used, then the maximum operable distance can be extended and the power consumption of ARM-911 is decreased.
- Page 14 Remove the metal plate. Open the left top cover. Screw off the bracket to fix adaptor. Install the adaptor inside the unit. DC 24V Connect the DC 24V Jack. Input Jack Fix the adaptor with the bracket. ↓ RM-911D/W(REMOTE MICROPHONE)
- Page 15 CONNECTING TERMINAl Of ARM-911 Connect to the ARM-911 using CAT5E cable. The CAT5E pin description is as below. Pin 1 : RS-422 RX+ (Refer to RM-911W) Pin 2 : RS-422 RX- (Refer to RM-911W) Pin 3 : RS-422 TX+ (Refer to RM-911W)
-
Page 16: Operation Method
O p e r a t i o nM e t h o d ■ ■ SETTING pASSWORD Connect to the ARM-911 network using the IP address of the ARM-911. Move to the RM password menu among the Administrator Menu. Input the password for the RM1, RM2, RM3, and RM4 respectively. - Page 17 (RM-911D/W), then the broadcasting is stopped and the LED of the button is off. If the password is inputted not correctly, then wait until the LED is off and input the password correctly. ■ ■ MODE SETTING SWITCh (RM-911D only) ←...
-
Page 18: Connection
C o n n e c t i o n s RM-911D/W(REMOTE MICROPHONE) -
Page 19: Block Diagram
B l o c kD i a g r a m RM-911D RM-911D/W(REMOTE MICROPHONE) - Page 20 RM-911W RM-911D/W(REMOTE MICROPHONE)
-
Page 21: Specifications
S p e c i f i c a t i o n s RM-911D RM-911W MIC INPUT (1kHz) Balanced Unbalanced Input Sensitivity -50dBu ±3dB Signal to Noise Ratio NOR: 65dB NOR: 63dB (S/N, 20kHz LPF, A-WTD) LIM: 60dB LIM: 58dB Total Harmonic Distortion NOR: 0.3%, LIM: 0.7%... -
Page 22: Dimension
Dimension RM-911D RM-911W RM-911D/W(REMOTE MICROPHONE) -
Page 23: Service
To obtain specific warranty information and available service locations contact Inter-M directly(in Korea or the USA) or the authorized Inter-M Distributor for your specific country or region. RM-911D/W(REMOTE MICROPHONE) - Page 24 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
