CLUB TOASTER
MODEL CTX-200L
A.J. Antunes & Co.
UTX-200 & CTX-200
Scan with mobile device or enter URL
for product and service information.
http://tiny.cc/ajaUTX-CTX

TABLE OF CONTENTS

Adjusting Toasting Quality .........................................7
Toasting Clubs ...........................................................7
Viewing the Program Mode Settings .........................8
CT Unit Status Mode .................................................8
Purging Products from the Toaster ............................9
Shutting down the CTX-200L ....................................9
Reset to Factory Defaults ..........................................9
Changing the Display Language ...............................9
Maintenance ..............................................................10
Daily Cleaning .........................................................10
Replacing Belt Wraps ..............................................12
Troubleshooting .......................................................14
Replacement Parts ...................................................16
Wiring Diagram .........................................................19
LIMITED WARRANTY
• Improper or unauthorized repairs.
• Scheduled Maintenance procedures as outlined in your MRC Card.
• This Warranty does not cover Consumable items. NOTE: The Conveyor Belt
wraps are consumable items that can be easily adjusted or replaced accord-
ing to the Maintenance Section of this product's Owner's Manual.
• Water pressure problems or contamination problems such as foreign material
in water lines or inside solenoid valves due to an incoming water source.
• Freight, foreign, excise, municipal or other sales or use taxes.
• Consequential damages such as loss of profit, loss of time, the cost of repair-
ing or replacing other property which is damaged, or any other incidental
damage of any kind.
© McDonald's Corporation All Rights Reserved
1
CLUB TOASTER CTX-200L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9210825 and is the answer not in the manual?

Questions and answers

Summary of Contents for A.J.Antunes 9210825

  • Page 1: Table Of Contents

    CLUB TOASTER MODEL CTX-200L CLUB TOASTER CTX-200L Manufacturing Numbers 9210825 & 9210826 Place this manual in the Toaster section A.J. Antunes & Co. of your Equipment Manual. Manufactured exclusively for McDONALD’S ® A.J. ANTUNES & CO. 180 KEHOE BLVD. CAROL STREAM, ILLINOIS 60188, U.S.A.
  • Page 2: Owner Information

    CLUB TOASTER CTX-200L OWNER INFORMATION General Service/Technical Assistance This manual is produced for the Club Toaster. If you experience any problems with the installation or operation of your unit, contact your Authorized Service The Club Toaster is designed to toast the club portion Agency.
  • Page 3: Specifications

    Max Amps/ Plug Description and Phase Power Freq. Mfg. No Voltage Line Configuration 208 V 3.3 kW CTX-200L 9210825 240 V 4.3 kW Pin & Sleeve 1 Phase 208 V 3.3 kW CTX-200L 9210826 240 V 4.3 kW NEMA L6-30P Dimensions 29”...
  • Page 4: Important Safety Information

    CLUB TOASTER CTX-200L IMPORTANT SAFETY INFORMATION Throughout this manual, you will find the following safety words and symbols that signify important safety issues with regards to operating or maintaining the equipment. WARNING WARNING GENERAL WARNING. Indicates information ELECTRICAL WARNING. Indicates information important to the proper operation of the equip- relating to possible shock hazard.
  • Page 5: Installation

    CLUB TOASTER CTX-200L INSTALLATION Unpacking Feeder 1. Remove the CTX-200L (Figure 1) and all packing materials from the shipping carton. Then open the accessories box and remove all its contents. It should contain the following: • 1 Bun Feeder (Figures 1 and 2) •...
  • Page 6: Assembling The Unit

    CLUB TOASTER CTX-200L INSTALLATION (continued) Assembling the Unit Assemble the unit as shown in Figures 1 and 2. Universal Toaster Bun Feeder (Can be installed to the right or the left side of the toaster depending on Bun Compression placement of both the UT Knob and CT toasters) Club Toaster...
  • Page 7: Operation

    CLUB TOASTER CTX-200L OPERATION Toasting Clubs Operating Instructions Follow these steps to start the Club Toaster: Follow these steps to toast clubs with the Club Toaster: 1. Make sure the unit is turned on and that the 1. Turn on the Power Switch located at the back of Ready display reads the unit.
  • Page 8: Viewing The Program Mode Settings

    CLUB TOASTER CTX-200L OPERATION (continued) Club Toaster Settings The following table describes the recommended Club PLTN Toaster operating settings. Light Buns Dark PLTN Setting Value MOTOR Bottom Temp. (Lower 570°F (299°C) Platen) Top Temp (Upper Platen) 570°F (299°C) ADJUST PRGM PREV NEXT SELECT...
  • Page 9: Purging Products From The Toaster

    CLUB TOASTER CTX-200L OPERATION (continued) Reset to Factory Defaults Purging Products from the Toaster Inadvertent changes to the settings of the CTX-200L During normal operation, if it ever becomes necessary could affect how the unit operates. If a fault message to purge a product from the toaster, follow these steps: appears, it is recommended that you first attempt to 1.
  • Page 10: Maintenance

    CLUB TOASTER CTX-200L MAINTENANCE WARNING The unit will remain hot to the touch while it is PLTN cooling down. Personal injury and burns may Ready result from touching the unit before it is finished PLTN cooling down. MOTOR NOTE: If at any time the unit displays an error message or if it fails to operate properly, contact ADJUST PRGM...
  • Page 11 CLUB TOASTER CTX-200L MAINTENANCE (continued) Cleaning and Sanitizing the Belt Wraps NOTE: Do NOT clean the Belt Wraps while 1. Open the Front Cover and Top Cover (Figure 8). they are turning. Press (Figure 7) to temporarily stop the Belt Wraps from turning.
  • Page 12: Replacing Belt Wraps

    CLUB TOASTER CTX-200L MAINTENANCE (continued) Replacing Belt Wraps Push both Bottom Rollers up and down to lock into place. Over time, the Belt Wraps will begin to show signs of This loosens Belt Wraps. wear. This wear appears in the form of tears or discol- oration of the belt.
  • Page 13 CLUB TOASTER CTX-200L MAINTENANCE (continued) INSTALLING BELT WRAPS NOTE: Refer to Figure 13 for the proper connection point locations when installing Belt Wraps. Follow this procedure to install new Belt Wraps. NOTE: The bottom Belt Wrap should be installed NOTE: Install Belt Wraps with the studs facing the by threading the Belt Wrap around the bottom rear INSIDE of the unit.
  • Page 14: Troubleshooting

    CLUB TOASTER CTX-200L TROUBLESHOOTING CAUTION To avoid possible personal injury and/or damage to the unit, all inspections, tests, and repair of electrical equipment should be performed by QUALIFIED SERVICE PERSONNEL. The unit MUST be completely shut down and unplugged before servicing, except when electrical tests are required. Use extreme care during electrical circuit tests.
  • Page 15 CLUB TOASTER CTX-200L TROUBLESHOOTING (continued) Problem Possible Cause Corrective Action The unit displays the following mes- The Thermocouple in the Platen The toaster cannot be operated sage: circuit has failed. with this type of failure. Contact your Authorized Service Agency for Upper Sensor Fail service.
  • Page 16: Replacement Parts

    CLUB TOASTER CTX-200L REPLACEMENT PARTS CAUTION To avoid possible personal injury and/or damage to the unit, all inspections, tests, and repair of electrical equipment should be performed by QUALIFIED SERVICE PERSONNEL. The unit should be completely shut down and unplugged before servicing, except when electrical tests are required. Use extreme care during electrical circuit tests.
  • Page 17 CLUB TOASTER CTX-200L REPLACEMENT PARTS (continued) P/N 1010993 Rev. H 03/15 McDonald’s...
  • Page 18 92 0400347 Strain Relief 1/2” Npt 3030135 Pin, Tensioner 42 0011969 Idler Sprocket Assembly 93 0700482 Power Cord Assembly (Mfg. No. 9210825) 43 0021384 Idler & Brg Retainer Weldment 0700577 Power Cord Assembly 0504491 Retainer, Idler & Brg (Mfg. No. 9210826)
  • Page 19: Wiring Diagram

    CLUB TOASTER CTX-200L WIRING DIAGRAM P/N 1010993 Rev. H 03/15 McDonald’s...
