LM5161PWPBKEVM Buck Evaluation Module
User's Guide
Literature Number: SNVU504A
August 2016 – Revised August 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LM5161PWPBKEVM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Texas Instruments LM5161PWPBKEVM

  • Page 1 LM5161PWPBKEVM Buck Evaluation Module User's Guide Literature Number: SNVU504A August 2016 – Revised August 2016...
  • Page 2: Table Of Contents

    LM5161 Buck EVM Schematic ..................LM5161 Buck EVM Bill of Materials .................... LM5161 Buck EVM PCB Layout .......................... Revision History Table of Contents SNVU504A – August 2016 – Revised August 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
  • Page 3 EVM Top Copper View with LM5161 ................EVM Bottom Copper View with LM5161 ..................EVM Top Solder Mask with LM5161 SNVU504A – August 2016 – Revised August 2016 List of Figures Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
  • Page 4 ..................LM5161 Buck EVM Specifications ......................FPWM Pin Mode ............LM5161 Buck EVM Bill of Materials for 300 kHz Configuration List of Tables SNVU504A – August 2016 – Revised August 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
  • Page 5: Introduction

    JP1 – MODE pin allows the user to select between forced CCM (FPWM = 1) and DCM (FPWM = 0) operation. See Section 3.2 Table 2 for more details. SNVU504A – August 2016 – Revised August 2016 LM5161 Buck EVM User’s Guide Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
  • Page 6: Operation

    Figure 1. Buck EVM Setup Operation In order to maintain proper operation of the LM5161PWPBKEVM, the input voltage applied across J1 should be gradually increased. The load at the output (J2) should not exceed 1 A. The inductor L2 used in this board is optimized for small solution size.
  • Page 7: Typical Performance Curves

    = 300kHz diode FPWM = 1 = 300kHz connected connected Figure 2. Load Regulation Figure 3. Line Regulation SNVU504A – August 2016 – Revised August 2016 LM5161 Buck EVM User’s Guide Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
  • Page 8: Efficiency Vs. I Out

    Figure 8. Steady State at V = 48 V and FPWM = 1 (no load) Figure 9. EN/UVLO Startup/Shutdown at Full Load LM5161 Buck EVM User’s Guide SNVU504A – August 2016 – Revised August 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
  • Page 9: Pre-Bias Startup At No Load

    Figure 15. Load Transient (I = No Load to Full Load) in Load Load No Load) in CCM SNVU504A – August 2016 – Revised August 2016 LM5161 Buck EVM User’s Guide Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
  • Page 10: Load

    Figure 18. Short Circuit (I = Full Load to Short) Figure 19. Line Transient (36V -100V -72V Load LM5161 Buck EVM User’s Guide SNVU504A – August 2016 – Revised August 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
  • Page 11: Lm5161 Synchronous Buck Evm Schematic

    PGND 1µF LM5161PWP 2.00k 6.81k Copyright © 2016, Texas Instruments Incorporated Figure 20. LM5161 Synchronous Buck EVM Schematic SNVU504A – August 2016 – Revised August 2016 LM5161 Buck EVM User’s Guide Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
  • Page 12 BST capacitor (see Figure 21), in order to protect the internal VCC-BST bootstrap diode during a full load transient. LM5161 Buck EVM User’s Guide SNVU504A – August 2016 – Revised August 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
  • Page 13: Evm Component View With Lm5161

    Figure 22. EVM Top Copper View with LM5161 Figure 23. EVM Bottom Copper View with LM5161 Figure 24. EVM Top Solder Mask with LM5161 SNVU504A – August 2016 – Revised August 2016 LM5161 Buck EVM User’s Guide Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
  • Page 14 Changes from Original (August 2016) to A Revision ..................... Page ..................• Changed datasheet crossreference to LM5161..................• Changed Orderable name to LM5161PWPR Revision History SNVU504A – August 2016 – Revised August 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
