- Page 1 Quick Installation Guide TI-F11SFP...
- Page 2 1. Before You Start Package Contents ŸTI-F11SFP ŸQuick Installation Guide ŸRemovable terminal block ŸDIN-rail mount ŸWall mount plates Minimum Requirements ŸExisting network ŸPower supply (TI-M6024) 2. Quick Reference TV-IP322WI...
-
Page 3: Hardware Installation
3. Hardware Installation ŸThe TI-F11SFP can be placed on a desktop, wall, or mounted to a DIN-rail. DIN-rail Mounting Instructions 1. Attach the DIN-rail mount bracket to the media converter. 2. Position the unit in front of the DIN-rail and hook the mount over the top of the rail. - Page 4 Wall Mounting Instructions 1. Attach the wall mount plates to the media converter. 2. Mount the unit. Safety Note ŸTurn off the power before connecting any module or wire. The correct power supply voltage (12 - 56 V DC or 18 - 36 V AC) is listed on the product label. Check the voltage of your power source to make sure that you are using the correct part.
- Page 5 Applying Power 1. Connect the power supply (sold separately) to the included terminal block (as shown below) and secure the screws. Note: Polarities must match. 2. Attach the terminal block to the unit, connect the neutral wire to the ground, and supply power to the power adapter.
- Page 6 4. Additional information 1. DIP Switch Speed ON: 100M OFF: 1000M ON: Off OFF: Auto ON: Con. Switch / Converter mode OFF: SW LFP (Link Fault Pass through) ON: LFP OFF: Off...
- Page 7 Hardened Industrial 100/1000 Base-T to SFP Media Converter TRENDnet Trade Name: TRENDnet hereby declare that the product is in compliance with the essential requirements and other relevant provisions under our sole responsibility. Safety EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 + A2: 2013...
- Page 8 Produktseite auf der Website von TRENDnet genannt. Garantía limitada TRENDnet garantiza que sus productos carecen de defectos en el material y la fabricación, en condiciones de uso y funcionamiento normales. Los periodos específicos de garantía figuran en cada una de las páginas de producto del sitio web de TRENDnet.
- Page 9 TI-F11SFP Обмежена гарантія TRENDnet надає гарантію на свою продукцію щодо відсутності дефектів матеріалів та роботи за умови її належного використання та обслуговування. Конкретні гарантійні періоди перелічені на сторінці кожного виробу на сайті компанії TRENDnet. Certifications Applies to PoE Products Only: This product is...
